ARAÇ ÜSTÜ EKİPMANLAR / JHONSTON SWEEPERS / JHONSTON YEDEK PARÇA LİSTESİ

Ürün Kodu:JHONSTON 600,605,625,700,705 MODELLERİ
Ürün Adı:JHONSTON YEDEK PARÇA LİSTESİ













SIRA

PARÇA KODU ÜRÜN AÇIKLAMASI ADET MODEL SATIŞ FİYATI PARA BİRİMİ
1 93264-2 Body - Standard 600/605 Series Current   Johnston 600/605/625/700/705
2 42100-1 Body - Standard 600/605 Series Superseded   Johnston 600/605/625/700/705
3 63700-1 Body - 600/605 LoTop   Johnston 600/605/625/700/705
4 95000-4 Body - Standard 625 Series   Johnston 600/605/625/700/705
5 95000-6 Body - 625 Series - No Wanderhose   Johnston 600/605/625/700/705
6 42890-1 Body - Standard 700/705 Series   Johnston 600/605/625/700/705
7 40139-1 Door - Locker 2 Johnston 600/605/625/700/705
8 40153-1 Bolt - Locker Door 4 Johnston 600/605/625/700/705
9 135-7 Setscrew M12c x 25mm 2 Johnston 600/605/625/700/705
10 455-12 Washer - Plain M12 2 Johnston 600/605/625/700/705
11 6817-1 Budget Lock 2 Johnston 600/605/625/700/705
12 6816 Key For Budget Lock 1 Johnston 600/605/625/700/705
13 124-102 Setscrew M6c x 16mm 4 Johnston 600/605/625/700/705
14 460-8 Washer - Spring M6 4 Johnston 600/605/625/700/705
15 420-13 Nut M6c 4 Johnston 600/605/625/700/705
16 40553-1 Pin - Cylinder Pivot 1 Johnston 600/605/625/700/705
17 425-18 Nut - M16c Nyloc 2 Johnston 600/605/625/700/705
18 265-2 Adaptor 1/4" x 3/8" BSP 1 Johnston 600/605/625/700/705
19 451-18 Washer - Sealing 3/8" BSP 2 Johnston 600/605/625/700/705
20 29170-1 Rear Door Cylinder - See Chapter 10 1 Johnston 600/605/625/700/705
21 3733-1 Check Valve Assembly comprising:- 1 Johnston 600/605/625/700/705
22 5194 Check Valve 1 Johnston 600/605/625/700/705
23 265-2 Adaptor 1/4" x 3/8" BSP 1 Johnston 600/605/625/700/705
24 263-2 Adaptor 1/4" BSP 1 Johnston 600/605/625/700/705
25 451-17 Washer - Sealing 1/4" BSP 2 Johnston 600/605/625/700/705
26 40578-1 Pin - Pivot 2 Johnston 600/605/625/700/705
27 40573-1 Pin - Pivot 1 Johnston 600/605/625/700/705
28 40572-1 Pin - Pivot 2 Johnston 600/605/625/700/705
29 124-132 Setscrew M8c x 12mm 5 Johnston 600/605/625/700/705
30 460-10 Washer - Spring M8 5 Johnston 600/605/625/700/705
31 38-1 Grease - Nipple 1/8" BSP Straight 1 Johnston 600/605/625/700/705
32 29128-3 Bush - Non Lube 6 Johnston 600/605/625/700/705
33 40462-2 Cover 1 Johnston 600/605/625/700/705
34 124-135 Setscrew M8c x 20mm 10 Johnston 600/605/625/700/705
35 460-10 Washer - Spring M8 10 Johnston 600/605/625/700/705
36 435-12 Retaining Nut M8c 10 Johnston 600/605/625/700/705
37 63379-2 Access Door 1 Johnston 600/605/625/700/705
38 9699-1 Sealing Ring 1 Johnston 600/605/625/700/705
39 40628-1 Catch - Access Door 1 Johnston 600/605/625/700/705
40 63065-2 Handle - Access Door 1 Johnston 600/605/625/700/705
41 59-1 Cotter Pin 2 Johnston 600/605/625/700/705
42 123-149 Bolt M12c x 55mm 2 Johnston 600/605/625/700/705
43 425-16 Nut M12c Nyloc 2 Johnston 600/605/625/700/705
44 9983 Drain Hose 2.4 Johnston 600/605/625/700/705
45 501-7 Hose Clip 2 Johnston 600/605/625/700/705
46 20674-1 Reflective Marker Plate ) U.K. 1 Johnston 600/605/625/700/705
47 20674-2 Reflective Marker Plate ) Machines 1 Johnston 600/605/625/700/705
48 194-9 Pan Head Screw ) Only 12 Johnston 600/605/625/700/705
49 40466-1 Shaft - Pin Actuation 1 Johnston 600/605/625/700/705
50 5010-1 Spring 1 Johnston 600/605/625/700/705
51 40471-1 Nut Locking Pin 1 Johnston 600/605/625/700/705
52 59-1 Cotter Pin 1 Johnston 600/605/625/700/705
53 40463 Pin Locking 1 Johnston 600/605/625/700/705
54 40465-2 Flange 1 Johnston 600/605/625/700/705
55 124-176 Setscrew M10c x 45mm 6 Johnston 600/605/625/700/705
56 425-15 Nut M10c Nyloc 6 Johnston 600/605/625/700/705
57 40091-1 Latch Plate 1 Johnston 600/605/625/700/705
58 124-275 Setscrew - M16c x 60mm 2 Johnston 600/605/625/700/705
59 460-14 Washer - Spring M16 2 Johnston 600/605/625/700/705
60 6439-1 Packer Plate 1 Johnston 600/605/625/700/705
61 124-212 Setscrew M12c x 65mm 1 Johnston 600/605/625/700/705
62 420-16 Nut M12c 1 Johnston 600/605/625/700/705
63 40897-1 Relay 1 Johnston 600/605/625/700/705
64 63500-1 Door - Standard 600/625/700 (less Bushes Item 17) 1 Johnston 600/605/625/700/705
65 63500-23 Door - LoTop (less Bushes Item 17) 1 Johnston 600/605/625/700/705
66 40901-1 Rubber Seal 1 Johnston 600/605/625/700/705
67 6849 Titanfast x 6m Long 6m Johnston 600/605/625/700/705
68 40650-1 Cap - 'Jobro' 4 Johnston 600/605/625/700/705
69 41776-2 Cap - 'Johnston'   Johnston 600/605/625/700/705
70 40643-1 Washer - Seal 4 Johnston 600/605/625/700/705
71 40492-1 Cover) 1 Johnston 600/605/625/700/705
72 5955 Gasket ) Not Req'd on 1 Johnston 600/605/625/700/705
73 124-199 Setscrew M12c 20mm ) Flat Top Bodies 4 Johnston 600/605/625/700/705
74 460-12 Washer - Spring M12 ) 4 Johnston 600/605/625/700/705
75 40711-1 Blanking Plate 1 Johnston 600/605/625/700/705
76 217-1 Grommet Strip x 20cm Long 1 Johnston 600/605/625/700/705
77 217-1 Grommet Strip x 26cm Long 1 Johnston 600/605/625/700/705
78 287-22 Grommet 1 Johnston 600/605/625/700/705
79 46415-1 Plate - Rear Number Plate 1 Johnston 600/605/625/700/705
80 46414-1 Mounting Angle 1 Johnston 600/605/625/700/705
81 124-100 Setscrew M6c x 12mm 3 Johnston 600/605/625/700/705
82 425-13 Nut M6c Nyloc   Johnston 600/605/625/700/705
83 40078-1 Beacon Bracket 1 Johnston 600/605/625/700/705
84 287-22 Grommet 1 Johnston 600/605/625/700/705
85 124-135 Setscrew M8c x 20mm 2 Johnston 600/605/625/700/705
86 425-14 Nut M8c Nyloc 2 Johnston 600/605/625/700/705
87 46-15-12 Beacon - 12v 1 Johnston 600/605/625/700/705
88 46-15-24 Beacon - 24v 1 Johnston 600/605/625/700/705
89 193-26 Screw Self Tapping 2 Johnston 600/605/625/700/705
90 455-7 Washer - Plain M5 2 Johnston 600/605/625/700/705
91 46-93 Rear Lamps - 24v 2 Johnston 600/605/625/700/705
92 46660-1 Beacon Bracket for Littasnatch 1/2 Johnston 600/605/625/700/705
93 63664-1 Access Plate 1 Johnston 600/605/625/700/705
94 124-137 Setscrew M8c x 25mm 10 Johnston 600/605/625/700/705
95 460-10 Washer - Spring M8 10 Johnston 600/605/625/700/705
96 600/605 625/700/705 Single Dual   Johnston 600/605/625/700/705
97 40249-1 - Wear Plate 600 Current 1/2 Johnston 600/605/625/700/705
98 63720-1 - LH Wear Plate 600 LoTop 1/1 Johnston 600/605/625/700/705
99 63720-2 - RH Wear Plate 600 Lo Top 1/1 Johnston 600/605/625/700/705
100 40223-1 < Clamp Bar 1/2 Johnston 600/605/625/700/705
101 124-167 < Setscrew M10c x 20mm 2/4 Johnston 600/605/625/700/705
102 460-11 < Washer - Spring M10 2/4 Johnston 600/605/625/700/705
103 40243-1 - Baffle Standard 600 -/1   Johnston 600/605/625/700/705
104 63745-1 - Baffle LoTop 600 -/1   Johnston 600/605/625/700/705
105 41234-1 < Ring - Locker -/2   Johnston 600/605/625/700/705
106 40072-2 - Intake Duct Ø236 x 912 Lg Current 1/2 Johnston 600/605/625/700/705
107 40072-3 < Intake Duct Ø236 x 912 Lg Nirosta 1/2 Johnston 600/605/625/700/705
108 40072-51 - Intake Duct Ø236 x 912 Lg Rubber Lined Current 1/2 Johnston 600/605/625/700/705
109 40072-1 - Intake Duct Ø236 x 872 Lg Superseded Body -   Johnston 600/605/625/700/705
110 40072-50 - Intake Duct Ø236 x 872 Lg Rubber Lined   Johnston 600/605/625/700/705
111 135-1 < Setscrew M12c x 25mm 4/8 Johnston 600/605/625/700/705
112 460-12 < Washer - Spring M12 4/8 Johnston 600/605/625/700/705
113 5028-1 < Seal - Rubber 1/2 Johnston 600/605/625/700/705
114 40214-1 41984-1 Clamp 1/2 Johnston 600/605/625/700/705
115 135-11 < Setscrew - Brass M12c x 35mm 4/8 Johnston 600/605/625/700/705
116 40222-1 41979-2 Cover 1/-   Johnston 600/605/625/700/705
117 50555-1 50554-1 Rear Mesh Std Body 2 Johnston 600/605/625/700/705
118 50554-3 - Rear Mesh - 600 Lo Top 2 Johnston 600/605/625/700/705
119 42111-1 < Eye 2 Johnston 600/605/625/700/705
120 63761-1 - Eye - 600 Lo Top 2 Johnston 600/605/625/700/705
121 124-144 < Setscrew M8c x 45mm 4 Johnston 600/605/625/700/705
122 455-10 < Washer Plain M8 As Req'd Johnston 600/605/625/700/705
123 460-10 < Washer - Spring M8 4 Johnston 600/605/625/700/705
124 420-14 < Nut M8c 4 Johnston 600/605/625/700/705
125 42581-1 N/A Cover 2 Johnston 600/605/625/700/705
126 124-109 N/A Setscrew M6c x 35mm 4 Johnston 600/605/625/700/705
127 425-13 N/A Nut M6c Nyloc 4 Johnston 600/605/625/700/705
128 60-1 < Lynch Pin With Ring 2 Johnston 600/605/625/700/705
129 40213-1 < Seal 1/2 Johnston 600/605/625/700/705
130 600/605 625/700/705 Single Dual   Johnston 600/605/625/700/705
131 135-1 < Setscrew M12c x 25mm 4/-   Johnston 600/605/625/700/705
132 460-12 < Washer - Spring M12 4/-   Johnston 600/605/625/700/705
133 41251-1 < Wear Liner Kit Comprising:-   Johnston 600/605/625/700/705
134 41249-1 < Liner 1 Johnston 600/605/625/700/705
135 41235-1 < Cleat Plate 1 Johnston 600/605/625/700/705
136 131-125 < Screw C'sk Hd. M8c x 25mm 2 Johnston 600/605/625/700/705
137 460-10 < Washer - Spring M8 2 Johnston 600/605/625/700/705
138 420-14 < Nut M8c 2 Johnston 600/605/625/700/705
139 26 - 41979-1 Seal Plate - Fits Under Item 18 1/2 Johnston 600/605/625/700/705
140 600/605 625 700/705 Johnston 600/605/625/700/705
141 28940-1 28940-3 28940-2 Body Tip Cylinder - See Chapter 10 Johnston 600/605/625/700/705
142 2 N/A 71283-1 < P.C. Flow Valve 1 Johnston 600/605/625/700/705
143 3 N/A 263-2 < Adaptor 3/8" BSP 1 Johnston 600/605/625/700/705
144 42432-1 < < Pivot Pin 1 Johnston 600/605/625/700/705
145 124-134 < < Setscrew M8c x 16mm 1 Johnston 600/605/625/700/705
146 460-10 < < Washer - Spring M8 1 Johnston 600/605/625/700/705
147 42072-1 < < Block - Trunnion 2 Johnston 600/605/625/700/705
148 38-1 < < Grease Nipple 1/8" BSP Straight 2 Johnston 600/605/625/700/705
149 41817-1 < < Sealing Plate 1 Johnston 600/605/625/700/705
150 124-203 < < Setscrew M12c x 30mm 4 Johnston 600/605/625/700/705
151 460-12 < < Washer - Spring M12 4 Johnston 600/605/625/700/705
152 28350-1 < 63245-1 Bearing LH 1 Johnston 600/605/625/700/705
153 28350-2 < 63245-1 Bearing RH 1 Johnston 600/605/625/700/705
154 38-8 < < Grease Nipple 1/8" BSP x 90° 2 Johnston 600/605/625/700/705
155 123-148 < < Bolt M12c x 50mm 6 Johnston 600/605/625/700/705
156 59-4 < < Roll pin Ø16 x 20mm 6 Johnston 600/605/625/700/705
157 455-12 < < Washer - Plain 6 Johnston 600/605/625/700/705
158 425-16 < < Nut - Nyloc M12c 6 Johnston 600/605/625/700/705
159 62875-1 < < Rear Light Bracket 2 Johnston 600/605/625/700/705
160 124-135 < < Setscrew M8c x 20mm 8 Johnston 600/605/625/700/705
161 460-10 < < Washer - Spring M8 8 Johnston 600/605/625/700/705
162 420-14 < < Nut M8c 8 Johnston 600/605/625/700/705
163 16 N/A 63251-1 < Reaction Beam 1 Johnston 600/605/625/700/705
164 600/605 625 700/705 Single/Dual   Johnston 600/605/625/700/705
165 42250-1 < < Front Valance 1 Johnston 600/605/625/700/705
166 42170-1 < < Cradle - Front 1 Johnston 600/605/625/700/705
167 42180-1 < < Cradle - Rear 1 Johnston 600/605/625/700/705
168 42252-1 < < Rear Valance 1 Johnston 600/605/625/700/705
169 42588-1 < < Flap Valance 1 Johnston 600/605/625/700/705
170 42596-2 < < Strip - Hinge 1 Johnston 600/605/625/700/705
171 42591-2 < < Latch - Flap 2 Johnston 600/605/625/700/705
172 42590-1 < < Spring - Compression 2 Johnston 600/605/625/700/705
173 134-42 < < Pozidrive Screw M4c x 12mm 2 Johnston 600/605/625/700/705
174 460-5 < < Washer M4 2 Johnston 600/605/625/700/705
175 420-11 < < Nut M4c 2 Johnston 600/605/625/700/705
176 42589-2 < < Flap Valance 1 Johnston 600/605/625/700/705
177 42596-1 < < Hinge 1 Johnston 600/605/625/700/705
178 42591-1 < < Strip - Hinge 1 Johnston 600/605/625/700/705
179 134-42 < < Pozidrive Screw M4c x 12mm 2 Johnston 600/605/625/700/705
180 460-5 < < Washer M4 2 Johnston 600/605/625/700/705
181 420-11 < < Nut M4c 2 Johnston 600/605/625/700/705
182 42189-1 < < Floor Deck 1 Johnston 600/605/625/700/705
183 93669-1 - - Engine Beam, 600 Front, Current Body 1 Johnston 600/605/625/700/705
184 42399-1 - - Engine Beam, 600 Front, Superseded Body 1 Johnston 600/605/625/700/705
185 93700-1 - < Engine Beam, 600 Rear, Current Body 1 Johnston 600/605/625/700/705
186 42398-1 Engine Beam, 600 Rear, Superseded Body 1 Johnston 600/605/625/700/705
187 93665-1 62900-1 < Mount - Body Tip Cylinder 1 Johnston 600/605/625/700/705
188 124-203 < < Setscrew M12c x 30mm 7 Johnston 600/605/625/700/705
189 425-16 < < Nut - Nyloc M12c 7 Johnston 600/605/625/700/705
190 11 - - - Body Prop - See page 1:16   Johnston 600/605/625/700/705
191 40224-1 < < Bracket - Intake Seat 1/2 Johnston 600/605/625/700/705
192 124-171 N/A N/A Setscrew M10c x 30mm 4/8 Johnston 600/605/625/700/705
193 460-11 N/A N/A Washer - Spring M10 4/8 Johnston 600/605/625/700/705
194 420-15 N/A N/A Nut M10c 4/8 Johnston 600/605/625/700/705
195 40269-1 < < Lifting Hook 1/2 Johnston 600/605/625/700/705
196 124-173 < < Setscrew M10c x 35mm 2/4 Johnston 600/605/625/700/705
197 425-15 < < Nut - Nyloc M10c 2/4 Johnston 600/605/625/700/705
198 42290-1 41998-27 41998-1 Subframe 1 Johnston 600/605/625/700/705
199 124-269 N/A Setscrew M16c x 35mm 4 Johnston 600/605/625/700/705
200 425-18 N/A Nut - Nyloc M16c 4 Johnston 600/605/625/700/705
201 123-150 < < Bolt M12c x 60mm 8 Johnston 600/605/625/700/705
202 40205-1 Shaft 2 Johnston 600/605/625/700/705
203 123-153 Bolt M12c x 75mm 2 Johnston 600/605/625/700/705
204 425-16 Nut - M12c Nyloc 2 Johnston 600/605/625/700/705
205 62903-1 Drain - Engine Oil ) 1 Johnston 600/605/625/700/705
206 124-167 Setscrew M10c x 20mm ) See Fig. 3 - 1 1 Johnston 600/605/625/700/705
207 460-11 Washer - Spring M10 ) and Fig. 3 - 5 1 Johnston 600/605/625/700/705
208 420-15 Nut M10c ) Items 22 1 Johnston 600/605/625/700/705
209 7684 Collar Plug 1/2" BSP ) 1 Johnston 600/605/625/700/705
210 451-19 Washer Sealing 1/2" BSP ) 2 Johnston 600/605/625/700/705
211 40225-1 Intake Seat 120mm Long 1/2 Johnston 600/605/625/700/705
212 40225-51 Intake Seat 120mm Long Rubber Lined 1/2 Johnston 600/605/625/700/705
213 40225-2 Intake Seat 180mm Long 1/2 Johnston 600/605/625/700/705
214 40225-52 Intake Seat 180mm Long Rubber Lined 1/2 Johnston 600/605/625/700/705
215 40225-3 Intake Seat 240mm Long 1/2 Johnston 600/605/625/700/705
216 40225-53 Intake Seat 240mm Long Rubber Lined 1/2 Johnston 600/605/625/700/705
217 40225-4 Intake Seat 300mm Long 1/2 Johnston 600/605/625/700/705
218 40225-54 Intake Seat 300mm Long Rubber Line 1/2 Johnston 600/605/625/700/705
219 10080 (JSC) Intake Seat 300mm Long 1/2 Johnston 600/605/625/700/705
220 127-139 Setscrew C/sk M8c x 30mm 3/6 Johnston 600/605/625/700/705
221 460-10 Washer - Spring M8 3/6 Johnston 600/605/625/700/705
222 420-14 Nut M8c 3/6 Johnston 600/605/625/700/705
223 47144-1 Service Information Plate 1 Johnston 600/605/625/700/705
224 193-22 Screw Pan Hd. Self Tapping 2 Johnston 600/605/625/700/705
225 40268-2 Air Reservoir 1 Johnston 600/605/625/700/705
226 124-169 Setscrew M10c x 25mm 2 Johnston 600/605/625/700/705
227 455-11 Washer - Plain M10 2 Johnston 600/605/625/700/705
228 460-11 Washer - Spring M10 2 Johnston 600/605/625/700/705
229 420-15 Nut M10c 2 Johnston 600/605/625/700/705
230 5259 Grub Screw 1 Johnston 600/605/625/700/705
231 40958-1 Drain Plug 1 Johnston 600/605/625/700/705
232 48108-1 Cable 1 Johnston 600/605/625/700/705
233 516-6 Adaptor 1/8" M/F 2 Johnston 600/605/625/700/705
234 124-269 Setscrew M16c x 35mm 4 Johnston 600/605/625/700/705
235 460-14 Washer - Spring M16 4 Johnston 600/605/625/700/705
236 124-169 Setscrew M10c x 25mm 12 Johnston 600/605/625/700/705
237 425-15 Nut - M10c Nyloc 12 Johnston 600/605/625/700/705
238 124-135 Setscrew M8c x 20mm 6 Johnston 600/605/625/700/705
239 425-14 Nut - M8c Nyloc 6 Johnston 600/605/625/700/705
240 124-137 Setscrew M8c x 25mm 2 Johnston 600/605/625/700/705
241 425-14 Nut - M8c Nyloc 2 Johnston 600/605/625/700/705
242 625/700 Single Dual   Johnston 600/605/625/700/705
243 264-2 < Adaptor 1/4" BSP Bulkhead 2 Johnston 600/605/625/700/705
244 527-3 < Tee - 6mm O/D Tube (Now Fitted on Hose)   Johnston 600/605/625/700/705
245 124-109 < Setscrew M6c x 35mm 1 Johnston 600/605/625/700/705
246 420-13 < Nut M6c Nyloc 1 Johnston 600/605/625/700/705
247 510-3 < Tubing Nut 6mm 1/5 Johnston 600/605/625/700/705
248 511-3 < Tubing Sleeve 6mm 1/5 Johnston 600/605/625/700/705
249 520-3 < Plug 1/-   Johnston 600/605/625/700/705
250 531-2 < Stem Elbow -/1   Johnston 600/605/625/700/705
251 34 - < Water Filter Assembly. - See Chapter 12 Johnston 600/605/625/700/705
252 40525-1 < Drain - Gearbox Oil ) 1 Johnston 600/605/625/700/705
253 124-167 < Setscrew M10c x 20mm ) 1 Johnston 600/605/625/700/705
254 460-11 < Washer - Spring M10 ) See Fig. 4 - 2 1 Johnston 600/605/625/700/705
255 420-15 < Nut M10c ) Item 36 1 Johnston 600/605/625/700/705
256 3823 < Collar Plug 3/8" BSP ) 1 Johnston 600/605/625/700/705
257 451-18 < Washer - Sealing 3/8" BSP ) 1 Johnston 600/605/625/700/705
258 50603-1 < Nozzle Anti-Swing Plate 1/2 Johnston 600/605/625/700/705
259 124-169 < Setscrew M10c x 25mm 2/4 Johnston 600/605/625/700/705
260 425-15 < Nut - Nyloc M10c 2/4 Johnston 600/605/625/700/705
261 50634-1 N/A Antiphon Retention Strip (Not Fitted on 700 Series) 3 Johnston 600/605/625/700/705
262 94084-1 N/A Antiphon Retaining Angle 2 Johnston 600/605/625/700/705
263 217-2 < Rubber Seal 1 Johnston 600/605/625/700/705
264 93547-1 Prop Assembly comprising:-   Johnston 600/605/625/700/705
265 93548-1 Prop 1 Johnston 600/605/625/700/705
266 93553-1 Plate 2 Johnston 600/605/625/700/705
267 93553-2 Plate 2 Johnston 600/605/625/700/705
268 93551-1 Cable 2 Johnston 600/605/625/700/705
269 40238-1 Latch 1 Johnston 600/605/625/700/705
270 41145-1 Sleeve - Plastic 2 Johnston 600/605/625/700/705
271 600/605 625/700/705   Johnston 600/605/625/700/705
272 42200-35 42895-1 Cowl Standard   Johnston 600/605/625/700/705
273 42200-350 N/A Cowl with Sound Attenuation Kit   Johnston 600/605/625/700/705
274 42663-1 61005-1 Wear plate 1 Johnston 600/605/625/700/705
275 135-60 < Setscrew M10c x 20mm 2 Johnston 600/605/625/700/705
276 420-15 < Nut M10c 2 Johnston 600/605/625/700/705
277 460-11 < Washer - Spring M10 2 Johnston 600/605/625/700/705
278 42739-1 < Cover 1 Johnston 600/605/625/700/705
279 135-56 < Setscrew M6c x 12mm 5 Johnston 600/605/625/700/705
280 18872 < Strip - Sealing 1 Johnston 600/605/625/700/705
281 15656-1 < Hose x 1500mm Long 1 Johnston 600/605/625/700/705
282 501-3 < Clip 2 Johnston 600/605/625/700/705
283 62016-1 < Silencer Assembly comprising items:-   Johnston 600/605/625/700/705
284 42378-1 < Spacer 18 Johnston 600/605/625/700/705
285 426-5 < Nut - M10c Philidas 6 Johnston 600/605/625/700/705
286 457-5 < Washer - Extra Large M10 6 Johnston 600/605/625/700/705
287 62177-1 < Hood Assembly comprising items:-   Johnston 600/605/625/700/705
288 62109-1 < Hood 1 Johnston 600/605/625/700/705
289 124-134 < Setscrew M8c x 16mm 5 Johnston 600/605/625/700/705
290 460-10 < Washer - Spring M8c 5 Johnston 600/605/625/700/705
291 434-8 < Nut - Retainer 5 Johnston 600/605/625/700/705
292 92230-1 802176-1 Shield 1 Johnston 600/605/625/700/705
293 6645-8 < ‘U’ Bolt 2 Johnston 600/605/625/700/705
294 42377-2 < Stud 6 Johnston 600/605/625/700/705
295 42633-1 < Wafer Plate 3 Johnston 600/605/625/700/705
296 41832-3 < Insulation - Lower Panel 3 Johnston 600/605/625/700/705
297 41832-4 < Insulation - Upper Panel 3 Johnston 600/605/625/700/705
298 41832-39 < Insulation - Hood 1 Johnston 600/605/625/700/705
299 434-8 < Nut - Retainer 5 Johnston 600/605/625/700/705
300 455-10 < Washer - Plain M8 4 Johnston 600/605/625/700/705
301 423-14 < Nut M8c 2 Johnston 600/605/625/700/705
302 62357-1 < Strip 1 Johnston 600/605/625/700/705
303 63063-1 < Angle 1 Johnston 600/605/625/700/705
304 124-113 < Setscrew M6c x 50mm 8 Johnston 600/605/625/700/705
305 455-8 < Washer - Plain M6 8 Johnston 600/605/625/700/705
306 62873-1 < Spacer 8 Johnston 600/605/625/700/705
307 425-13 < Nut M6c Nyloc 8 Johnston 600/605/625/700/705
308 217-7 < Sealing Strip x 950mm Long 2 Johnston 600/605/625/700/705
309 217-7 < Sealing Strip x 1120mm Long 1 Johnston 600/605/625/700/705
310 63064-1 < Strip 1 Johnston 600/605/625/700/705
311 63064-2 < Strip 2 Johnston 600/605/625/700/705
312 2 - ) See Fig. 2 - 1 Johnston 600/605/625/700/705
313 63648-1 Standard Hood Assembly comprising items marked ) Comprises   Johnston 600/605/625/700/705
314 63648-2 Chromweld Hood Assembly comprising items marked ) Items   Johnston 600/605/625/700/705
315 62648-3 Stainless Steel Hood Assembly comprising items marked ) 6 - 14 Johnston 600/605/625/700/705
316 63643-1 Cover Top/Hood - Standard 1 Johnston 600/605/625/700/705
317 63643-3 Cover Top/Hood - Chromweld 1 Johnston 600/605/625/700/705
318 63643-5 Cover Top/Hood - Stainless Steel 1 Johnston 600/605/625/700/705
319 63063-1 Angle Clamp 1 Johnston 600/605/625/700/705
320 63646-1 Clamp Strip 1 Johnston 600/605/625/700/705
321 200869-1 Clamp Strip 1 Johnston 600/605/625/700/705
322 63647-1 Insulation Panel 1 Johnston 600/605/625/700/705
323 63647-2 Insulation Panel 1 Johnston 600/605/625/700/705
324 63647-3 Insulation Panel 1 Johnston 600/605/625/700/705
325 124-112 Setscrew M6c x 45mm long 9 Johnston 600/605/625/700/705
326 455-8 Washer - Plain M6 9 Johnston 600/605/625/700/705
327 425-13 Nut - Nyloc M6c 9 Johnston 600/605/625/700/705
328 62873-1 Spacer 5 Johnston 600/605/625/700/705
329 124-134 Setscrew M8c x 16mm 2 Johnston 600/605/625/700/705
330 460-10 Washer - Spring M8 2 Johnston 600/605/625/700/705
331 455-10 Washer - Plain M8 2 Johnston 600/605/625/700/705
332 423-14 Nut M8c 2 Johnston 600/605/625/700/705
333 63642-1 Plenum Plate - Standard 1 Johnston 600/605/625/700/705
334 63642-2 Plenum Plate - Chromweld 1 Johnston 600/605/625/700/705
335 63642-3 Plenum Plate - Stainless Steel 1 Johnston 600/605/625/700/705
336 63647-4 Insulation Panel 1 Johnston 600/605/625/700/705
337 135-57 Screw Button Hd. M8c x 20mm 2 Johnston 600/605/625/700/705
338 217-7 Sealing Strip x 1120mm long 1 Johnston 600/605/625/700/705
339 217-7 Sealing Strip x 950mm long 2 Johnston 600/605/625/700/705
340 802278-1 Cowl Shield - Exhaust 1 Johnston 600/605/625/700/705
341 6645-8 ‘U’ Bolt 2 Johnston 600/605/625/700/705
342 63701-1 Cowl 1 Johnston 600/605/625/700/705
343 42663-1 Wearplate 1 Johnston 600/605/625/700/705
344 135-60 Setscrew M10c x 20mm 2 Johnston 600/605/625/700/705
345 420-15 Nut M10c 2 Johnston 600/605/625/700/705
346 460-11 Washer - Spring M10 2 Johnston 600/605/625/700/705
347 42739-1 Cover 1 Johnston 600/605/625/700/705
348 135-56 Setscrew M6c c 12mm 5 Johnston 600/605/625/700/705
349 18872 Strip - Sealing 1 Johnston 600/605/625/700/705
350 15656-1 Hose x 1500mm long 1 Johnston 600/605/625/700/705
351 501-3 Clip 2 Johnston 600/605/625/700/705
352 63648-1 Standard Hood Assembly comprising items 6 to 14 Johnston 600/605/625/700/705
353 63648-2 Chromweld Hood Assembly comprising items 6 to 14 Johnston 600/605/625/700/705
354 63648-3 Stainless Steel Hood Assembly comprising items 6 to 14 Johnston 600/605/625/700/705
355 63643-1 Cover Top/Hood - Standard 1 Johnston 600/605/625/700/705
356 63643-3 Cover Top/Hood - Chromweld 1 Johnston 600/605/625/700/705
357 63643-5 Cover Top/Hood - Stainless Steel 1 Johnston 600/605/625/700/705
358 63063-1 Angle Clamp 1 Johnston 600/605/625/700/705
359 63646-1 Clamp Strip 1 Johnston 600/605/625/700/705
360 200869-1 Clamp Strip 1 Johnston 600/605/625/700/705
361 63647-1 Insulation Panel 1 Johnston 600/605/625/700/705
362 63647-2 Insulation Panel 1 Johnston 600/605/625/700/705
363 63647-3 Insulation Panel 1 Johnston 600/605/625/700/705
364 124-112 Setscrew M6c x 45mm long 9 Johnston 600/605/625/700/705
365 455-8 Washer - Plain M6 9 Johnston 600/605/625/700/705
366 425-13 Nut - Nyloc M6c 9 Johnston 600/605/625/700/705
367 62873-1 Spacer 5 Johnston 600/605/625/700/705
368 124-134 Setscrew M8c x 16mm 5 Johnston 600/605/625/700/705
369 460-10 Washer - Spring M8 5 Johnston 600/605/625/700/705
370 434-8 Nut - Retainer 5 Johnston 600/605/625/700/705
371 124-134 Setscrew M8c x 16mm 2 Johnston 600/605/625/700/705
372 460-10 Washer - Spring M8 2 Johnston 600/605/625/700/705
373 455-10 Washer - Plain M8 2 Johnston 600/605/625/700/705
374 423-14 Nut M8c 2 Johnston 600/605/625/700/705
375 217-7 Sealing Strip x 1120mm long 1 Johnston 600/605/625/700/705
376 217-7 Sealing Strip x 950mm long 2 Johnston 600/605/625/700/705
377 802278-1 Cowl Shield - Exhaust 1 Johnston 600/605/625/700/705
378 6645-8 ‘U’ Bolt 2 Johnston 600/605/625/700/705
379 42610-1 Camp - Radiator Seal 1 Johnston 600/605/625/700/705
380 42613-1 Rubber - Radiator Seal 1 Johnston 600/605/625/700/705
381 42611-1 Clamp - Radiator Seal 1 Johnston 600/605/625/700/705
382 42612-1 Rubber - Radiator Seal 1 Johnston 600/605/625/700/705
383 42610-1 Clamp - Radiator Seal 1 Johnston 600/605/625/700/705
384 42607-1 Rubber Radiator Seal 1 Johnston 600/605/625/700/705
385 124-135 Setscrew M8c x 20mm 17 Johnston 600/605/625/700/705
386 420-14 Nut M8c 17 Johnston 600/605/625/700/705
387 460-10 Washer - Spring M8 17 Johnston 600/605/625/700/705
388 282396-1 Seal - Body Make/Brake 1 Johnston 600/605/625/700/705
389 42411-1 Seal - Cowl Make/Brake 1 Johnston 600/605/625/700/705
390 42409-2 Seal - Cowling 1 Johnston 600/605/625/700/705
391 12964-1 'T' Section 1 Johnston 600/605/625/700/705
392 124-205 Setscrew M12c x 35mm 10 Johnston 600/605/625/700/705
393 420-16 Nut M12c 6 Johnston 600/605/625/700/705
394 460-12 Washer - Spring M12c 10 Johnston 600/605/625/700/705
395 217-2 Rubber Seal x 200mm Long 2 Johnston 600/605/625/700/705
396 10270 (JSC) Adhesive   Johnston 600/605/625/700/705
397 1 13   Johnston 600/605/625/700/705
398 40458-1 Flap 1 Johnston 600/605/625/700/705
399 40516-1 Clip 2 Johnston 600/605/625/700/705
400 40442-6 Shaft 1 Johnston 600/605/625/700/705
401 63523-1 Bearing - Plastic 1 Johnston 600/605/625/700/705
402 124-139 Setscrew M8c x 30mm 4 Johnston 600/605/625/700/705
403 460-10 Washer - Spring M8 4 Johnston 600/605/625/700/705
404 135-56 Screw Button Hd. M6c x 12mm 10 Johnston 600/605/625/700/705
405 460-8 Washer - Spring M6 10 Johnston 600/605/625/700/705
406 40196-1 Lever 1 Johnston 600/605/625/700/705
407 40456-2 Bar - Lever Mounting 1 Johnston 600/605/625/700/705
408 124-179 Setscrew M10c x 60mm 2 Johnston 600/605/625/700/705
409 460-11 Washer - Spring M10 2 Johnston 600/605/625/700/705
410 29128-1 Bush - Bearing 1 Johnston 600/605/625/700/705
411 124-208 Setscrew M12c x 45mm 1 Johnston 600/605/625/700/705
412 420-16 Nut M12c 1 Johnston 600/605/625/700/705
413 460-12 Washer - Spring M12 1 Johnston 600/605/625/700/705
414 40250-1 Plate Blanking - Single Sweep Machines 1 Johnston 600/605/625/700/705
415 28901-1 Cylinder - See Chapter 11 1 Johnston 600/605/625/700/705
416 29149-1 Pin 1 Johnston 600/605/625/700/705
417 39624 Spring Retaining Cup 2 Johnston 600/605/625/700/705
418 42216-1 Bracket - Cylinder Mounting 600/605 Series 1 Johnston 600/605/625/700/705
419 61100-1 Bracket - Cylinder Mounting 625/700/705 Series 1 Johnston 600/605/625/700/705
420 124-135 Setscrew M8c x 20mm 4 Johnston 600/605/625/700/705
421 420-14 Nut M8c 4 Johnston 600/605/625/700/705
422 460-10 Washer - Spring M8 4 Johnston 600/605/625/700/705
423 12869 Tube Ø6mm Black 5m Johnston 600/605/625/700/705
424 510-3 Nut - Tubing 6mm 5 Johnston 600/605/625/700/705
425 511-3 Sleeve - Tubing 6mm 5 Johnston 600/605/625/700/705
426 19 - Control Valve Assemblies - See Fig. 2 - 7 1 Johnston 600/605/625/700/705
427 29128-2 Bush 1 Johnston 600/605/625/700/705
428 42940-1 Plate - Blanking) Single Sweep 1 Johnston 600/605/625/700/705
429 42956-1 Plug - Blanking) Machines 1 Johnston 600/605/625/700/705
430 42733-1 Bush Bearing 1 Johnston 600/605/625/700/705
431 42937-1 Assembly 12v 3 -   Johnston 600/605/625/700/705
432 42937-2 Assembly 24v - 3 Johnston 600/605/625/700/705
433 42940-2 Mounting Plate - 4 Hole 1 1 Johnston 600/605/625/700/705
434 42300-1 Valve - Pneumatic NO 12v 1 -   Johnston 600/605/625/700/705
435 42300-2 Valve - Pneumatic NC 12v 1 -   Johnston 600/605/625/700/705
436 42300-3 Valve - Pneumatic NO 24v 1 1 Johnston 600/605/625/700/705
437 42300-4 Valve - Pneumatic NC 24v 1 1 Johnston 600/605/625/700/705
438 40594-1 Adaptor - Bulkhead 2 2 Johnston 600/605/625/700/705
439 552-8 Elbow - 1/4" BSP 1 1 Johnston 600/605/625/700/705
440 552-3 Elbow - 1/8" BSP 2 2 Johnston 600/605/625/700/705
441 3162 Plug - Collar 1 1 Johnston 600/605/625/700/705
442 410-3 Back Nut 3/8" BSP 2 2 Johnston 600/605/625/700/705
443 451-17 Washer - Sealing 1/4" BSP 1 1 Johnston 600/605/625/700/705
444 451-4 Washer - Sealing 1/8" BSP 2 2 Johnston 600/605/625/700/705
445 40602-2 Valve - Block 1 1 Johnston 600/605/625/700/705
446 280080-1 Engine - To Build List AJ50824 - 24v   Johnston 600/605/625/700/705
447 280080-2 Engine - To Build List AJ50823 - 12v   Johnston 600/605/625/700/705
448 837-61 Rocker Box Gasket - Rubber 1 Johnston 600/605/625/700/705
449 653-14 Alternator - 24v 1 Johnston 600/605/625/700/705
450 653-208 Alternator - 12v 1 Johnston 600/605/625/700/705
451 653-10 Starter Motor - 24v 1 Johnston 600/605/625/700/705
452 653-207 Starter Motor - 12v 1 Johnston 600/605/625/700/705
453 124-175 Setscrew M10c x 40mm 3 Johnston 600/605/625/700/705
454 460-11 Washer - Spring M10 3 Johnston 600/605/625/700/705
455 837-11 Oil Filter Element 1 Johnston 600/605/625/700/705
456 14825 Thermostart 1 Johnston 600/605/625/700/705
457 12017 Thermostart Resistor - 24v - See Item 32 1 Johnston 600/605/625/700/705
458 838-7 Fuel Filter Element 1>   Johnston 600/605/625/700/705
459 280211-1 ESOS Valve (Amp Junior Timer Type Plug Connector 1 Johnston 600/605/625/700/705
460 8 - Cooling Fan - Perkins Part 4 Johnston 600/605/625/700/705
461 123-110 Bolt M8c x 50mm 4 Johnston 600/605/625/700/705
462 460-10 Washer - Spring M8 4 Johnston 600/605/625/700/705
463 280-5 Vee Belt - Cooling Fan 1 Johnston 600/605/625/700/705
464 837-63 Thermostat 1 Johnston 600/605/625/700/705
465 837-64 ‘O’ Ring 1 Johnston 600/605/625/700/705
466 837-65 ‘O’ Ring 1 Johnston 600/605/625/700/705
467 40619-1 Oil Pressure Switch 1 Johnston 600/605/625/700/705
468 42797-1 Water Temperature Switch 1 Johnston 600/605/625/700/705
469 41120-1 Boot - PVC 1 Johnston 600/605/625/700/705
470 42291-1 Adaptor 1 Johnston 600/605/625/700/705
471 170-35 Socket Head Csk. Screw 4 Johnston 600/605/625/700/705
472 42187-1 PTO Pulley 1 Johnston 600/605/625/700/705
473 124-135 Setscrew M8c x 20mm 3 Johnston 600/605/625/700/705
474 460-10 Washer - Spring M8 3 Johnston 600/605/625/700/705
475 42181-2 Engine Mounting Bracket - Front 1 Per Side   Johnston 600/605/625/700/705
476 21173-1 Stud 4 Per Side   Johnston 600/605/625/700/705
477 426-6 Nut M12c 4 Per Side   Johnston 600/605/625/700/705
478 460-12 Washer - Spring M12 4 Per Side   Johnston 600/605/625/700/705
479 123-154 Bolt M12c x 80mm - Front 1 Per Side   Johnston 600/605/625/700/705
480 457-6 Washer - Plain M12 2 Per Side   Johnston 600/605/625/700/705
481 460-12 Washer - Spring M12 2 Per Side   Johnston 600/605/625/700/705
482 6953 Metacone Mount - Front 1 Per Side   Johnston 600/605/625/700/705
483 124-171 Setscrew M10c x 30mm 2 Per Side   Johnston 600/605/625/700/705
484 455-11 Washer - Plain M10 2 Per Side   Johnston 600/605/625/700/705
485 425-15 Nut - Nyloc M10c 2 Per Side   Johnston 600/605/625/700/705
486 42645-2 Engine Mount (RH Rear) 1 Johnston 600/605/625/700/705
487 63536-1 Engine Mount (LH Rear) 1 Johnston 600/605/625/700/705
488 124-201 Setscrew M12c x 25mm 4 Per Side   Johnston 600/605/625/700/705
489 123-153 Bolt (Rear Mount) M12c x 75mm 1 Per Side   Johnston 600/605/625/700/705
490 457-6 Washer - Plain M12 1 Per Side   Johnston 600/605/625/700/705
491 460-12 Washer - Spring M12 1 Per Side   Johnston 600/605/625/700/705
492 22826-1 Metacone Mount (Rear) 1 Per Side   Johnston 600/605/625/700/705
493 124-171 Setscrew M10 x 30mm 2 Per Side   Johnston 600/605/625/700/705
494 455-11 Washer - Plain M10 2 Per Side   Johnston 600/605/625/700/705
495 425-15 Nut - Nyloc M10c 2 Per Side   Johnston 600/605/625/700/705
496 62908 Remote Oil Drain Kit comprising:   Johnston 600/605/625/700/705
497 62906-1 Adaptor 3/4" BSP x 3/4" UNF 1 Johnston 600/605/625/700/705
498 15656 (JSC) Hose - Remote Oil Drain 1 Johnston 600/605/625/700/705
499 10887-1 (JSC) Valve 123 Johnston 600/605/625/700/705
500 22778-1 ESOS Valve Resistor - 24v 1 Johnston 600/605/625/700/705
501 94952-1 Pipe - Inlet 1 Johnston 600/605/625/700/705
502 837-28 Gasket 1 Johnston 600/605/625/700/705
503 42657-1 Top Hose - Radiator 1 Johnston 600/605/625/700/705
504 501-6 Hose Clip 2 Johnston 600/605/625/700/705
505 42656-1 Bottom Hose - Radiator 1 Johnston 600/605/625/700/705
506 501-6 Hose Clip 2 Johnston 600/605/625/700/705
507 92105-60 Starter Cable 1 Johnston 600/605/625/700/705
508 17936-61 Starter Earth Cable 1 Johnston 600/605/625/700/705
509 48495-1 Loom Support Bracket 1 Johnston 600/605/625/700/705
510 508-4 ‘P’ Clip - Loom Support 1 Johnston 600/605/625/700/705
511 124-167 Setscrew M10c x 20mm 1 Johnston 600/605/625/700/705
512 460-11 Washer - Spring M10 1 Johnston 600/605/625/700/705
513 12017 Thermostart Resistor - 24v only 1 Johnston 600/605/625/700/705
514 280849-1 Resistor Mounting Bracket 1 Johnston 600/605/625/700/705
515 33 - Hydraulic Pump - See Chapter 10 1 Johnston 600/605/625/700/705
516 280850-1 Filter Assembly comprising items 1 to 3 Johnston 600/605/625/700/705
517 280850-2 Main Element 1 Johnston 600/605/625/700/705
518 280850-3 Safety Element 1 Johnston 600/605/625/700/705
519 280850-4 Housing 1 Johnston 600/605/625/700/705
520 904-58 Adaptor 1 Johnston 600/605/625/700/705
521 12188 Filter State Indicator (5.5kPa) 1 Johnston 600/605/625/700/705
522 12190 Mounting 1 Johnston 600/605/625/700/705
523 904-56 Hose End Connector 1 Johnston 600/605/625/700/705
524 124-103 Setscrew M6c x 20mm 2 Johnston 600/605/625/700/705
525 457-2 Washer - Plain M6 2 Johnston 600/605/625/700/705
526 425-13 Nut - Nyloc M6c 2 Johnston 600/605/625/700/705
527 12870 Plastic Tubing 1 Johnston 600/605/625/700/705
528 1 - Air Cleaner - See previous page   Johnston 600/605/625/700/705
529 124-167 Setscrew M10c x 20mm 2 Johnston 600/605/625/700/705
530 460-11 Washer - Spring M10 2 Johnston 600/605/625/700/705
531 904-8 Elbow - Rubber 2 Johnston 600/605/625/700/705
532 280848-1 Elbow - Steel 1 Johnston 600/605/625/700/705
533 501-7 Hose Clip 4 Johnston 600/605/625/700/705
534 6 - Shroud - See Fig. 3 - 4 Johnston 600/605/625/700/705
535 61028-1 Radiator 1 Johnston 600/605/625/700/705
536 69-21 Filler Cap lbf/in 2 1 Johnston 600/605/625/700/705
537 124-66 Setscrew M10c x 16mm 4 Johnston 600/605/625/700/705
538 460-11 Washer - Spring M10 4 Johnston 600/605/625/700/705
539 280845-1 Shroud 1 Johnston 600/605/625/700/705
540 124-167 Setscrew M10c x 20mm 2 Johnston 600/605/625/700/705
541 460-11 Washer - Spring M10 2 Johnston 600/605/625/700/705
542 124-167 Setscrew M10c x 20mm 2 Johnston 600/605/625/700/705
543 425-15 Nut - Nyloc M10c 2 Johnston 600/605/625/700/705
544 288-25 Blind Grommet 2 Johnston 600/605/625/700/705
545 280184-1 Cooling Fan Adaptor 1 Johnston 600/605/625/700/705
546 124-103 Setscrew M6c x 20mm 8 Johnston 600/605/625/700/705
547 460-8 Washer - Spring M6 8 Johnston 600/605/625/700/705
548 433-7 Rivet Nut M6c 8 Johnston 600/605/625/700/705
549 11 - Walkway and Locker - See Chapter 9 Johnston 600/605/625/700/705
550 94110-1 Actuator Motor - 24v 1 Johnston 600/605/625/700/705
551 94190-1 Throttle Cable 1 Johnston 600/605/625/700/705
552 38-32 Nipple - Solderless 3 Johnston 600/605/625/700/705
553 802403-1 Throttle Cable Bracket 1 Johnston 600/605/625/700/705
554 280046-1 Mounting Plate 2 Johnston 600/605/625/700/705
555 280047-1 Cable Support 1 Johnston 600/605/625/700/705
556 124-102 Setscrew M6c x 16mm 3 Johnston 600/605/625/700/705
557 42774-1 Spacer 1 Johnston 600/605/625/700/705
558 124-99 Setscrew M6c x 10mm 1 Johnston 600/605/625/700/705
559 124-114 Setscrew M6c x 15mm 1 Johnston 600/605/625/700/705
560 425-13 Nut - Nyloc M6c 1 Johnston 600/605/625/700/705
561 94581-1 Engine - To Build List AK50603 - 24v   Johnston 600/605/625/700/705
562 94581-2 Engine - To Build List AK50723 - 12v   Johnston 600/605/625/700/705
563 837-61 Rocker Box Gasket - Rubber 1 Johnston 600/605/625/700/705
564 653-14 Alternator - 24v 1 Johnston 600/605/625/700/705
565 653-23 Starter Motor - 24v 1 Johnston 600/605/625/700/705
566 837-29 Oil Filter Element 1 Johnston 600/605/625/700/705
567 14825 Thermostart 1 Johnston 600/605/625/700/705
568 838-7 Fuel Filter Element 1 Johnston 600/605/625/700/705
569 837-67 ESOS Valve (Spade Connector) 1 Johnston 600/605/625/700/705
570 8 - Cooling Fan 4 Johnston 600/605/625/700/705
571 123-110 Bolt M8c x 50mm 4 Johnston 600/605/625/700/705
572 460-10 Washer - Spring M8 4 Johnston 600/605/625/700/705
573 280-5 Vee Belt - Cooling Fan 1 Johnston 600/605/625/700/705
574 837-63 Thermostat 1 Johnston 600/605/625/700/705
575 837-64 ‘O’ Ring 1 Johnston 600/605/625/700/705
576 837-65 ‘O’ Ring 1 Johnston 600/605/625/700/705
577 40619-1 Oil Pressure Switch 1 Johnston 600/605/625/700/705
578 42797-1 Water Temperature Switch 1 Johnston 600/605/625/700/705
579 41120-1 Boot - PVC 1 Johnston 600/605/625/700/705
580 42291-1 Adaptor 1 Johnston 600/605/625/700/705
581 170-35 Socket Head Csk. Screw 4 Johnston 600/605/625/700/705
582 42187-1 PTO Pulley 1 Johnston 600/605/625/700/705
583 124-135 Setscrew M8c x 20mm 3 Johnston 600/605/625/700/705
584 460-10 Washer - Spring M8 3 Johnston 600/605/625/700/705
585 42181-2 Engine Mounting Bracket - Front 1 Per Side   Johnston 600/605/625/700/705
586 21173-1 Stud 4 Per Side   Johnston 600/605/625/700/705
587 426-6 Nut M12c 4 Per Side   Johnston 600/605/625/700/705
588 460-12 Washer - Spring M12 4 Per Side   Johnston 600/605/625/700/705
589 123-154 Bolt M12c x 80mm - Front 1 Per Side   Johnston 600/605/625/700/705
590 457-6 Washer - Plain M12 4 Per Side   Johnston 600/605/625/700/705
591 460-12 Washer - Spring M12 4 Per Side   Johnston 600/605/625/700/705
592 6953 Metacone Mount - Front 1 Per Side   Johnston 600/605/625/700/705
593 124-171 Setscrew M10c x 30mm 2 Per Side   Johnston 600/605/625/700/705
594 455-11 Washer - Plain M10 2 Per Side   Johnston 600/605/625/700/705
595 425-15 Nut - Nyloc M10c 2 Per Side   Johnston 600/605/625/700/705
596 42645-2 Engine Mount (RH Rear) 1 Johnston 600/605/625/700/705
597 63536-1 Engine Mount (LH Rear) 1 Johnston 600/605/625/700/705
598 124-201 Setscrew M12c x 25mm 4 Per Side   Johnston 600/605/625/700/705
599 123-153 Bolt (Rear Mount) M12c x 75mm 1 Per Side   Johnston 600/605/625/700/705
600 457-6 Washer - Plaint M12 1 Per Side   Johnston 600/605/625/700/705
601 460-12 Washer - Spring M12 1 Per Side   Johnston 600/605/625/700/705
602 22826-1 Metacone Mount (Rear) 1 Per Side   Johnston 600/605/625/700/705
603 124-171 Setscrew M10 x 30mm 4 Per Side   Johnston 600/605/625/700/705
604 455-11 Washer - Plain M10 4 Per Side   Johnston 600/605/625/700/705
605 425-15 Nut - Nyloc M10c 4 Per Side   Johnston 600/605/625/700/705
606 62908 Remote Oil Drain Kit comprising:   Johnston 600/605/625/700/705
607 62906-1 Adaptor 3/4" BSP x 3/4" UNF 1 Johnston 600/605/625/700/705
608 15656 (JSC) Hose - Remote Oil Drain 1 Johnston 600/605/625/700/705
609 10887-1 (JSC) Valve 1 Johnston 600/605/625/700/705
610 22778-1 ESOS Valve Resistor - 24v 1 Johnston 600/605/625/700/705
611 61025-1 Pipe - Inlet 1 Johnston 600/605/625/700/705
612 837-28 Gasket 1 Johnston 600/605/625/700/705
613 42657-1 Top Hose - Radiator 1 Johnston 600/605/625/700/705
614 501-6 Hose Clip 2 Johnston 600/605/625/700/705
615 42656-1 Bottom Hose - Radiator 1 Johnston 600/605/625/700/705
616 501-6 Hose Clip 2 Johnston 600/605/625/700/705
617 92105-60 Starter Cable 1 Johnston 600/605/625/700/705
618 17936-61 Starter Earth Cable 1 Johnston 600/605/625/700/705
619 48495-1 Loom Support Bracket 1 Johnston 600/605/625/700/705
620 31 - Oil Cooler Hoses - See Fig. 3 - 10 Johnston 600/605/625/700/705
621 32 - Engine Loom - See Chapter 13 Johnston 600/605/625/700/705
622 33 - Hydraulic Pump - See Chapter 10 Johnston 600/605/625/700/705
623 94954-1 Air Cleaner Assembly - Comprising Items 2 and 3 Johnston 600/605/625/700/705
624 94954-2 Main Element 1 Johnston 600/605/625/700/705
625 94954-3 Safety Element 1 Johnston 600/605/625/700/705
626 904-58 Adaptor 1 Johnston 600/605/625/700/705
627 904-55 Filter State Indicator (7.5 kPa) 1 Johnston 600/605/625/700/705
628 12190 Mounting 1 Johnston 600/605/625/700/705
629 904-56 Hose End Connector 1 Johnston 600/605/625/700/705
630 124-103 Setscrew M6c x 20mm 2 Johnston 600/605/625/700/705
631 457-2 Washer - Plain M6 2 Johnston 600/605/625/700/705
632 425-13 Nut - Nyloc M6c 2 Johnston 600/605/625/700/705
633 12870 Plastic Tubing x 900mm Long 1 Johnston 600/605/625/700/705
634 94954-1 Air Cleaner Assembly - See this chapter 1 Johnston 600/605/625/700/705
635 97962-1 Mounting Bracket 1 Johnston 600/605/625/700/705
636 124-169 Setscrew M10 x 25mm 4 Johnston 600/605/625/700/705
637 460-11 Washer - Spring M10 4 Johnston 600/605/625/700/705
638 420-15 Nut M10c 4 Johnston 600/605/625/700/705
639 97965-1 Pivot Bracket 1 Johnston 600/605/625/700/705
640 124-135 Setscrew M8c x 20mm 4 Johnston 600/605/625/700/705
641 460-10 Washer - Spring M8 4 Johnston 600/605/625/700/705
642 420-14 Nut M8c 4 Johnston 600/605/625/700/705
643 97966-1 Pivot 2 Johnston 600/605/625/700/705
644 123-126 Bolt M10c x 35mm 2 Johnston 600/605/625/700/705
645 436-1 Retaining Catch 1 Johnston 600/605/625/700/705
646 95359-1 Duct Support 1 Johnston 600/605/625/700/705
647 124-103 Setscrew M6c x 20mm 2 Johnston 600/605/625/700/705
648 460-8 Washer - Spring M6 2 Johnston 600/605/625/700/705
649 420-13 Nut M6 2 Johnston 600/605/625/700/705
650 276-10 Flexible Ducting 1 Johnston 600/605/625/700/705
651 501-7 Clip 2 Johnston 600/605/625/700/705
652 62328-1 Mount 1 Johnston 600/605/625/700/705
653 124-143 Setscrew M8c x 40mm 4 Johnston 600/605/625/700/705
654 17008-1 Spacer 4 Johnston 600/605/625/700/705
655 460-10 Washer - Spring M8 4 Johnston 600/605/625/700/705
656 420-14 Nut M8c 4 Johnston 600/605/625/700/705
657 904-20 Pre-Cleaner 1 Johnston 600/605/625/700/705
658 17 - Clip - Supplied with Pre-Cleaner 1 Johnston 600/605/625/700/705
659 63201-1 Shroud - See this chapter 1 Johnston 600/605/625/700/705
660 904-8 Rubber Elbow 1 Johnston 600/605/625/700/705
661 501-7 Clip Ø90 5 Johnston 600/605/625/700/705
662 501-6 Clip 1 Johnston 600/605/625/700/705
663 46578-7 Tube 1 Johnston 600/605/625/700/705
664 271-24 Convoluted Hose 1 Johnston 600/605/625/700/705
665 46578-3 Tube 1 Johnston 600/605/625/700/705
666 271-25 Reducing Elbow 1 Johnston 600/605/625/700/705
667 280850-1 Filter Assembly comprising items 1 to 3 Johnston 600/605/625/700/705
668 280850-2 Main Element 1 Johnston 600/605/625/700/705
669 280850-3 Safety Element 1 Johnston 600/605/625/700/705
670 280850-4 Housing 1 Johnston 600/605/625/700/705
671 904-58 Adaptor 1 Johnston 600/605/625/700/705
672 904-55 Filter State Indicator (7.5 kPa) 1 Johnston 600/605/625/700/705
673 12190 Mounting 1 Johnston 600/605/625/700/705
674 904-56 Hose End Connector 1 Johnston 600/605/625/700/705
675 124-103 Setscrew M6c x 20mm 2 Johnston 600/605/625/700/705
676 457-2 Washer - Plain M6 2 Johnston 600/605/625/700/705
677 425-13 Nut - Nyloc M6c 2 Johnston 600/605/625/700/705
678 12870 Plastic Tubing 1 Johnston 600/605/625/700/705
679 1 - Air Cleaner - See previous page   Johnston 600/605/625/700/705
680 124-167 Setscrew M10c x 20mm 2 Johnston 600/605/625/700/705
681 460-11 Washer - Spring M10 2 Johnston 600/605/625/700/705
682 904-9 Hump Hose 1 Johnston 600/605/625/700/705
683 281025-1 Induction Pipe 1 Johnston 600/605/625/700/705
684 271-25 Reduction Elbow 1 Johnston 600/605/625/700/705
685 501-7 Hose Clip 4 Johnston 600/605/625/700/705
686 12017 Thermostart Resistor 24v only 1 Johnston 600/605/625/700/705
687 280849-1 Resistor Mounting Bracket 1 Johnston 600/605/625/700/705
688 8 - Shroud - See Fig. 3 - 11 Johnston 600/605/625/700/705
689 62478-1 Oil Cooler Adaptor Manifold 1 Johnston 600/605/625/700/705
690 837-36 Gasket 1 Johnston 600/605/625/700/705
691 124-143 Setscrew ) Perkins 3 Johnston 600/605/625/700/705
692 455-10 Washer Spring ) Parts 3 Johnston 600/605/625/700/705
693 4 HF12022-116-225 Hydraulic Hose 2 Johnston 600/605/625/700/705
694 40619-1 Oil Pressure Switch 1 Johnston 600/605/625/700/705
695 499-3 Adaptor G3/4" x SAE Ø7/8" 2 Johnston 600/605/625/700/705
696 451-20 Washer - Sealing Ø7/8" 2 Johnston 600/605/625/700/705
697 837-11 Filter Element 1 Johnston 600/605/625/700/705
698 61028-1 < Radiator 1 Johnston 600/605/625/700/705
699 69-21 < Filler Cap 10lbf/in 2 Johnston 600/605/625/700/705
700 124-166 < Setscrew M10c x 16mm 4 Johnston 600/605/625/700/705
701 460-11 < Washer - Spring M10 4 Johnston 600/605/625/700/705
702 280310-1 280845-1 Shroud 1 Johnston 600/605/625/700/705
703 124-167 < Setscrew M10c x 20mm 2 Johnston 600/605/625/700/705
704 460-11 < Washer - Spring M10 2 Johnston 600/605/625/700/705
705 124-167 < Setscrew M10c x 20mm 2 Johnston 600/605/625/700/705
706 425-15 < Nut - Nyloc M10c 2 Johnston 600/605/625/700/705
707 288-25 < Blind Grommet 2 Johnston 600/605/625/700/705
708 8 - - Walkway and Locker - See Chapter 9>   Johnston 600/605/625/700/705
709 94797-1 Actuator Box 1 Johnston 600/605/625/700/705
710 94110-1 Electrical Actuator Motor 24v   Johnston 600/605/625/700/705
711 94110-2 Electrical Actuator Motor 12v   Johnston 600/605/625/700/705
712 94190-1 Throttle Cable 1 Johnston 600/605/625/700/705
713 200414-1 Throttle Cable Bracket 1 Johnston 600/605/625/700/705
714 201203-1 Top Plate 1 Johnston 600/605/625/700/705
715 124-99 Setscrew M6c x 10mm 3 Johnston 600/605/625/700/705
716 42774-1 Spacer 1 Johnston 600/605/625/700/705
717 129-38 Socket Hd. Cap Screw M4c x 25mm 4 Johnston 600/605/625/700/705
718 425-11 Nut - Nyloc M4c 4 Johnston 600/605/625/700/705
719 94110-1 Actuator Motor - 24v 1 Johnston 600/605/625/700/705
720 94110-2 Actuator Motor - 12v 1 Johnston 600/605/625/700/705
721 94190-1 Throttle Cable 1 Johnston 600/605/625/700/705
722 38-32 Nipple - Solderless 3 Johnston 600/605/625/700/705
723 200414-1 Throttle Cable Bracket 1 Johnston 600/605/625/700/705
724 280046-1 Mounting Plate 2 Johnston 600/605/625/700/705
725 280047-1 Cable Support 1 Johnston 600/605/625/700/705
726 124-102 Setscrew M6c x 16mm 3 Johnston 600/605/625/700/705
727 42774-1 Spacer 1 Johnston 600/605/625/700/705
728 124-99 Setscrew M6c x 10mm 1 Johnston 600/605/625/700/705
729 124-114 Setscrew M6c x 15mm 1 Johnston 600/605/625/700/705
730 425-13 Nut - Nyloc M6c 1 Johnston 600/605/625/700/705
731 42649-1 Tailpipe - 600 Series 1 Johnston 600/605/625/700/705
732 63154-1 Tailpipe - 625, 700 Series 1 Johnston 600/605/625/700/705
733 63169-1 Support - Tailpipe - 625, 700 Series Only 1 Johnston 600/605/625/700/705
734 124-167 Setscrew M10c x 20mm ) 2 Johnston 600/605/625/700/705
735 460-11 Washer - Spring M10 ) 625, 700 Series Only 2 Johnston 600/605/625/700/705
736 420-15 Nut - Nyloc M10c )   Johnston 600/605/625/700/705
737 455-88 Washer - Plain M6 ) 600 Series Only 2 Johnston 600/605/625/700/705
738 460-8 Washer - Spring M6 ) 2 Johnston 600/605/625/700/705
739 6645-13 Pipe Clamp Ø66mm 1 Johnston 600/605/625/700/705
740 6645-14 Pipe Clamp Ø69mm 1 Johnston 600/605/625/700/705
741 42647-1 Heat Shield 1 Johnston 600/605/625/700/705
742 124-100 Setscrew M6c x 12mm 3 Johnston 600/605/625/700/705
743 460-8 Washer - Spring M6 3 Johnston 600/605/625/700/705
744 61024-1 Silencer 1 Johnston 600/605/625/700/705
745 61022-1 Exhaust Bracket 1 Johnston 600/605/625/700/705
746 124-135 Setscrew M8c x 20mm 2 Johnston 600/605/625/700/705
747 460-10 Washer - Spring M8 2 Johnston 600/605/625/700/705
748 420-14 Nut M8c 2 Johnston 600/605/625/700/705
749 61017-2 Clamp 1 Johnston 600/605/625/700/705
750 124-135 Setscrew M8c x 20mm 2 Johnston 600/605/625/700/705
751 426-4 Nut - Philidas M8c 2 Johnston 600/605/625/700/705
752 13 - Fan Case - See Chapter 4 Johnston 600/605/625/700/705
753 600/605 625/700/705   Johnston 600/605/625/700/705
754 42201-25 41920-23 Fuel Tank - Standard 1 Johnston 600/605/625/700/705
755 62682-1 62683-1 Fuel Tank - High Capacity 1 Johnston 600/605/625/700/705
756 12367 < Fuel Cap - Up to 04-00 1 Johnston 600/605/625/700/705
757 69-6 < Lockable Fuel Cap - From 04-00 1 Johnston 600/605/625/700/705
758 15314-1 < Pre-Filter Assembly. 1 Johnston 600/605/625/700/705
759 15314-2 < Filter Bowl   Johnston 600/605/625/700/705
760 15314-3 < Gasket   Johnston 600/605/625/700/705
761 15314-4 < Gauze   Johnston 600/605/625/700/705
762 42295-1 < Mounting Plate 1 Johnston 600/605/625/700/705
763 124-135 < Setscrew M8c x 20mm 4 Johnston 600/605/625/700/705
764 460-10 < Washer - Spring M8 4 Johnston 600/605/625/700/705
765 420-14 < Nut M8c 4 Johnston 600/605/625/700/705
766 25977-1 < Nut - Tubing 8mm 2 Johnston 600/605/625/700/705
767 511-4 < Sleeve - Tubing 8mm 2 Johnston 600/605/625/700/705
768 42683-1 42683-2 Fuel Pipe 1 Johnston 600/605/625/700/705
769 40448-1 < Adaptor 1 Johnston 600/605/625/700/705
770 451-17 < Washer - Sealing 1/4" BSP 1 Johnston 600/605/625/700/705
771 510-4 < Nut - Tubing 8mm 1 Johnston 600/605/625/700/705
772 511-4 < Sleeve - Tubing 8mm 1 Johnston 600/605/625/700/705
773 518-7 < Adaptor 6mm 1 Johnston 600/605/625/700/705
774 451-17 < Washer - Sealing 1/2" BSP 1 Johnston 600/605/625/700/705
775 39024 < Tubing - Nylon 8mm 1 Johnston 600/605/625/700/705
776 521-8 < Adaptor Elbow 2 Johnston 600/605/625/700/705
777 510-4 < Nut - Tubing 8mm 2 Johnston 600/605/625/700/705
778 511-4 < Sleeve - Tubing 8mm 2 Johnston 600/605/625/700/705
779 42608-1 < Walkway 1 Johnston 600/605/625/700/705
780 135-57 < Screw Button Hd. M8c x 20mm 5 Johnston 600/605/625/700/705
781 460-10 < Washer - Spring M8 5 Johnston 600/605/625/700/705
782 420-14 < Nut M8c 5 Johnston 600/605/625/700/705
783 50618-1 N/A Ladder - Standard (Aluminium) 1 Johnston 600/605/625/700/705
784 50618-2 < Ladder - Long (Aluminium) 1 Johnston 600/605/625/700/705
785 136-22 < Coach Bolt M8c x 40mm 4 Johnston 600/605/625/700/705
786 460-10 < Washer - Spring M8 4 Johnston 600/605/625/700/705
787 420-14 < Nut M8c 4 Johnston 600/605/625/700/705
788 124-137 < Setscrew M8c x 25mm 4 Johnston 600/605/625/700/705
789 420-14 < Nut M8c 4 Johnston 600/605/625/700/705
790 460-10 < Washer - Spring M8 4 Johnston 600/605/625/700/705
791 99925-4 < Blanking Plate 1 Johnston 600/605/625/700/705
792 66136-1 < Gasket 1 Johnston 600/605/625/700/705
793 124-103 < Setscrew M6c x 20mm 5 Johnston 600/605/625/700/705
794 460-8 < Washer - Spring M6 5 Johnston 600/605/625/700/705
795 600/605 625/700/705   Johnston 600/605/625/700/705
796 48-33 < Fuel Level Sender - VDO (5 Hole Fixing) 1 Johnston 600/605/625/700/705
797 99925-1 < Adaptor Plate 1 Johnston 600/605/625/700/705
798 66136-1 < Gasket 1 Johnston 600/605/625/700/705
799 124-103 < Setscrew M6c x 20mm 4 Johnston 600/605/625/700/705
800 460-8 < Washer - Spring M6 4 Johnston 600/605/625/700/705
801 92647-1 < Support LH 1 Johnston 600/605/625/700/705
802 92647-2 < Support RH 1 Johnston 600/605/625/700/705
803 533-54 < Braided Hose - To Lift Pump 1 Johnston 600/605/625/700/705
804 533-53 < Braided Hose - To Fuel Filter 1 Johnston 600/605/625/700/705
805 531-2 < Stem Elbow 1 Johnston 600/605/625/700/705
806 510-3 - Tubing Nut 2 Johnston 600/605/625/700/705
807 511-3 - Tubing Sleeve 2 Johnston 600/605/625/700/705
808 136-23 < Coach Bolt M8c x 45mm 2 Johnston 600/605/625/700/705
809 425-14 < Nut - Nyloc M8c 2 Johnston 600/605/625/700/705
810 42201-37 N/A Fuel Tank - with External Filler Port   Johnston 600/605/625/700/705
811 69-27 N/A Fuel Cap - Current, for Ø80mm )   Johnston 600/605/625/700/705
812 69-6 N/A Fuel Cap - Superseded, for Ø65mm ) Below   Johnston 600/605/625/700/705
813 837-19 Flywheel 1 Johnston 600/605/625/700/705
814 42501-3 Fluid Coupling 1 Johnston 600/605/625/700/705
815 42270-1 Gearbox See Fig. 4 - 2 1 Johnston 600/605/625/700/705
816 4 [ 104-54 Screw 3/8" UNC x 1 1/4" 6 Johnston 600/605/625/700/705
817 14-7 Pilot Bearing 1 Johnston 600/605/625/700/705
818 77-39 Rotary Seal 1 Johnston 600/605/625/700/705
819 129-127 Setscrew - Soc. Hd.M8c x 30mm 20 Johnston 600/605/625/700/705
820 455-10 Washer - Plain M8 20 Johnston 600/605/625/700/705
821 221-3 End Cover 6 Johnston 600/605/625/700/705
822 656-1 'O' Ring 1 Johnston 600/605/625/700/705
823 656-2 'O' Ring 1 Johnston 600/605/625/700/705
824 656-3 Fusible Plug 1 Johnston 600/605/625/700/705
825 656-4 Circlip - External 2 Johnston 600/605/625/700/705
826 656-5 Circlip - External 1 Johnston 600/605/625/700/705
827 656-6 Circlip - Internal 1 Johnston 600/605/625/700/705
828 656-7 Bearing 1 Johnston 600/605/625/700/705
829 656-8 Oil Seal 1 Johnston 600/605/625/700/705
830 656-9 Gasket 1 Johnston 600/605/625/700/705
831 42299-1 Cover 2 Johnston 600/605/625/700/705
832 40377-1 Spacer 4 Johnston 600/605/625/700/705
833 124-177 Setscrew M10c x 50mm 4 Johnston 600/605/625/700/705
834 460-11 Washer - Spring M10 4 Johnston 600/605/625/700/705
835 656-10 Impeller Inner 1 Johnston 600/605/625/700/705
836 656-12 Centre Hub 1 Johnston 600/605/625/700/705
837 656-13 Bearing Carrier 1 Johnston 600/605/625/700/705
838 656-14 Screw 12 Johnston 600/605/625/700/705
839 16 and 17 Johnston 600/605/625/700/705
840 42270-1 42271-1

Gearbox Comprising:- Fan Şanzuman Dişli kutusu Dolu



1 Johnston 600/605/625/700/705  4500  USD
841 42271-2 Casing - Gearbox Fan Şanzuman Gövdesi Boş 1 Johnston 600/605/625/700/705  3500 USD
842 42272-2 Housing - Bearing 1 Johnston 600/605/625/700/705
843 42466-1 Shaft - Input 1 Johnston 600/605/625/700/705
844 42274-19 Shaft - Output 1 Johnston 600/605/625/700/705
845 42275-34 Gear 1 Johnston 600/605/625/700/705
846 42255-1 Cap - Bearing 1 Johnston 600/605/625/700/705
847 42277-1 Plate - Cover 1 Johnston 600/605/625/700/705
848 42278-1 Spacer 1 Johnston 600/605/625/700/705
849 42279-1 Gasket 1 Johnston 600/605/625/700/705
850 42280-1 Washer 1 Johnston 600/605/625/700/705
851 42281-1 Spacer 1 Johnston 600/605/625/700/705
852 42282-2 Plate - Clamp 2 Johnston 600/605/625/700/705
853 42283-1 Spacer 1 Johnston 600/605/625/700/705
854 10-21 Bearing 1 Johnston 600/605/625/700/705
855 10-22 Bearing 1 Johnston 600/605/625/700/705
856 14-46 Bearing 1 Johnston 600/605/625/700/705
857 77-21 Seal - Rotary 2 Johnston 600/605/625/700/705
858 80-95 Seal - 'O' Ring 1 Johnston 600/605/625/700/705
859 80-100 Seal - 'O' Ring 1 Johnston 600/605/625/700/705
860 451-22 Washer - Seal 1" BSP 2 Johnston 600/605/625/700/705
861 19084-1 Plug - Special 2 Johnston 600/605/625/700/705
862 6611 Plug - Collar 3 Johnston 600/605/625/700/705
863 13109 Plug - Magnetic 1 Johnston 600/605/625/700/705
864 451-126 Washer - Copper 1 Johnston 600/605/625/700/705
865 121-41 Setscrew M10F x 25mm 6 Johnston 600/605/625/700/705
866 124-137 Setscrew M8c x 25mm 10 Johnston 600/605/625/700/705
867 460-10 Washer - Spring M8 16 Johnston 600/605/625/700/705
868 124-143 Setscrew M8c x 40mm 6 Johnston 600/605/625/700/705
869 457-4 Washer - Extra Large M8 2 Johnston 600/605/625/700/705
870 42659-1 Tab Washer 2 Johnston 600/605/625/700/705
871 16978-1 Breather 1 Johnston 600/605/625/700/705
872 87-7 Oil Level Indicator 1 Johnston 600/605/625/700/705
873 263-4 Adaptor 1/2" BSP 2 Johnston 600/605/625/700/705
874 451-19 Washer - Sealing 1/2" BSP 2 Johnston 600/605/625/700/705
875 37 HC08001-48 1/2" BSP Female Straight/45° 1 Johnston 600/605/625/700/705
876 65-4 Adaptor 1/2" x 3/8" BSP 1 Johnston 600/605/625/700/705
877 451-18 Washer - Sealing 3/8" BSP 1 Johnston 600/605/625/700/705
878 93870-1 Fan Case - 1004 .40 and 1004.40T Engine 1 Johnston 600/605/625/700/705
879 93880-1 Fan Impeller 800mm Diameter - 1004 .40T Engine 1 Johnston 600/605/625/700/705
880 280730-1 Fan Impeller 760mm Diameter - 1004 .40 Engine 1 Johnston 600/605/625/700/705
881 42238-1 Cover - Access 1 Johnston 600/605/625/700/705
882 42284-1 Mask - Fan Case 1 Johnston 600/605/625/700/705
883 837-37 Screw - Special M8c x 20mm 4 Johnston 600/605/625/700/705
884 42270-1 Gearbox Assembly 1 Johnston 600/605/625/700/705
885 93875-1 Cover - 1004 Johnston 600/605/625/700/705
886 42282-2 Plate - Clamp 1 Johnston 600/605/625/700/705
887 42659-1 Tab Washer 2 Johnston 600/605/625/700/705
888 121-41 Setscrew M10c x 25mm 3 Johnston 600/605/625/700/705
889 42401-1 Ring - Transition 1 Johnston 600/605/625/700/705
890 285-2 Spring - Compression - Inner 3 Johnston 600/605/625/700/705
891 62770-1 Sleeve 3 Johnston 600/605/625/700/705
892 457-5 Washer 3 Johnston 600/605/625/700/705
893 425-15 Nut - Nyloc M10c 3 Johnston 600/605/625/700/705
894 455-11 Washer - Plain M10 3 Johnston 600/605/625/700/705
895 124-135 Setscrew M8c x 20mm 10 Johnston 600/605/625/700/705
896 460-10 Washer - Spring M8 10 Johnston 600/605/625/700/705
897 457-4 Washer - Extra Large M8 10 Johnston 600/605/625/700/705
898 42382-1 Diaphragm 1 Johnston 600/605/625/700/705
899 124-137 Setscrew M8c x 25mm 12 Johnston 600/605/625/700/705
900 425-14 Nut - Nyloc M8c 12 Johnston 600/605/625/700/705
901 42239-1 Flange 1 Johnston 600/605/625/700/705
902 460-10 Washer - Spring M8 5 Johnston 600/605/625/700/705
903 124-134 Setscrew M8c x 16mm 5 Johnston 600/605/625/700/705
904 62025-1 Spinner 1 Johnston 600/605/625/700/705
905 42587-1 Cover Plate 1 Johnston 600/605/625/700/705
906 124-134 Setscrew M8c x 16mm 1 Johnston 600/605/625/700/705
907 460-10 Washer - Spring M8 1 Johnston 600/605/625/700/705
908 62407-1 Grab Handle 1 Johnston 600/605/625/700/705
909 124-135 Setscrew M8c x 20mm 4 Johnston 600/605/625/700/705
910 460-10 Washer - Spring M8 4 Johnston 600/605/625/700/705
911 423-14 Nut M8c 2 Johnston 600/605/625/700/705
912 94246-1 Label 1 Johnston 600/605/625/700/705
913 42729-1 Pivot Rod 1 Johnston 600/605/625/700/705
914 29128-1 Bush 2 Johnston 600/605/625/700/705
915 42723-1 Tab Washer 2 Johnston 600/605/625/700/705
916 124-134 Setscrew M8c x 16mm 4 Johnston 600/605/625/700/705
917 42582-1 Flap 1 Johnston 600/605/625/700/705
918 42952-1 Flap Actuator 1 Johnston 600/605/625/700/705
919 289-4 Yoke End 1 Johnston 600/605/625/700/705
920 289-21 Spring Bolt 1 Johnston 600/605/625/700/705
921 421-15 Lock Nut M10c 1 Johnston 600/605/625/700/705
922 42990-5 Rod Actuation 1 Johnston 600/605/625/700/705
923 42986-1 Sleeve 1 Johnston 600/605/625/700/705
924 42988-1 Clevis 1 Johnston 600/605/625/700/705
925 29145-2 Clevis Pin 1 Johnston 600/605/625/700/705
926 39624 Spring Retaining Clip 1 Johnston 600/605/625/700/705
927 42947-1 Flap Actuator 1 Johnston 600/605/625/700/705
928 42993-1 Rod 1 Johnston 600/605/625/700/705
929 42992-1 U-Bolt 2 Johnston 600/605/625/700/705
930 460-8 Washer-Spring M6 4 Johnston 600/605/625/700/705
931 420-13 Nut M6c 4 Johnston 600/605/625/700/705
932 80766-1 Spring 1 Johnston 600/605/625/700/705
933 42586-1 Boss 1 Johnston 600/605/625/700/705
934 123-108 Bolt M8c x 40mm 1 Johnston 600/605/625/700/705
935 457-4 Washer - Plain M8 1 Johnston 600/605/625/700/705
936 425-14 Nut - Nyloc M8c 1 Johnston 600/605/625/700/705
937 42728-1 Spacer 2 Johnston 600/605/625/700/705
938 62000-8 LH Assembly   Johnston 600/605/625/700/705
939 62000-9 RH Assembly   Johnston 600/605/625/700/705
940 41999-3 Nozzle - Non-Handed 1 Johnston 600/605/625/700/705
941 62260-2 Nozzle Rubber Set - Comprising Items 2-4   Johnston 600/605/625/700/705
942 62005-1 Front/Back Rubbers 2 Johnston 600/605/625/700/705
943 62005-2 End Rubber - Long (Outer End) 1 Johnston 600/605/625/700/705
944 62005-3 End Rubber - Short (Inner End) 1 Johnston 600/605/625/700/705
945 62260-3 Retaining Strip Set Comprising Items 5-7   Johnston 600/605/625/700/705
946 63665-1 Front/Back Retaining Strip 2 Johnston 600/605/625/700/705
947 63666-1 End Retaining Strip - Long (Outer End) 1 Johnston 600/605/625/700/705
948 63667-1 End Retaining Strip - Short (Inner End) 1 Johnston 600/605/625/700/705
949 136-24 Carriage Bolt M8c x 50mm 16 Johnston 600/605/625/700/705
950 455-10 Washer - Plain M8 16 Johnston 600/605/625/700/705
951 410-30 Nut - Brass M8c 16 Johnston 600/605/625/700/705
952 40364-1 Bumper 1 Johnston 600/605/625/700/705
953 104-100 Setscrew 1/2" UNC x 1 1/4"2   Johnston 600/605/625/700/705
954 450-31 Washer - Spring 1/2" 2 Johnston 600/605/625/700/705
955 40406-1 Bolt - Nozzle Adjuster 1 Johnston 600/605/625/700/705
956 63338-1 Hook - Nozzle Adjuster 1 Johnston 600/605/625/700/705
957 425-15 Nut - Nyloc M10 1 Johnston 600/605/625/700/705
958 62353-3 Link - Nozzle Adjuster 1 Johnston 600/605/625/700/705
959 281305-1 Handle 1 Johnston 600/605/625/700/705
960 450-11 Washer - Plain 1 Johnston 600/605/625/700/705
961 45014-8 Spacer 1 Johnston 600/605/625/700/705
962 62331-1 Spacer 1 Johnston 600/605/625/700/705
963 39444 Hose 3/8" Bore x 1350mm 1 Johnston 600/605/625/700/705
964 501-1 Hose Clip 6 Johnston 600/605/625/700/705
965 180-13 Bolt 1/2" UNC x 2 Johnston 600/605/625/700/705
966 455-12 Washer - Plain 1 Johnston 600/605/625/700/705
967 460-12 Washer - Spring 1 Johnston 600/605/625/700/705
968 400-21 Nut 1/2" UNC 1 Johnston 600/605/625/700/705
969 5894-1 Water Jet 1 Johnston 600/605/625/700/705
970 5894-2 Water Jet 3mm Bore - Optional 2 Johnston 600/605/625/700/705
971 5894-3 Water Jet 2mm Bore - Optional 2 Johnston 600/605/625/700/705
972 453-1 Washer - Fibre 20mm 4 Johnston 600/605/625/700/705
973 407-47 Locknut 1/2" BSW - Brass 2 Johnston 600/605/625/700/705
974 408-47 Nut - Domed 1/2" BSW 2 Johnston 600/605/625/700/705
975 63530-1 Drawbar 1 Johnston 600/605/625/700/705
976 62248-1 Cradle 1 Johnston 600/605/625/700/705
977 62246-1 Heel 1 Johnston 600/605/625/700/705
978 124-173 Setscrew M10c x 35mm 4 Johnston 600/605/625/700/705
979 457-5 Washer - Plain Extra Large M10 8 Johnston 600/605/625/700/705
980 425-15 Nut - Nyloc M10c 4 Johnston 600/605/625/700/705
981 40414-1 Pivot 2 Johnston 600/605/625/700/705
982 40404-1 Clamp Washer 1 Johnston 600/605/625/700/705
983 40405-1 Lifting Eye 1 Johnston 600/605/625/700/705
984 63345-1 Clamp Block 1 Johnston 600/605/625/700/705
985 124-178 Setscrew M10c x 55mm 2 Johnston 600/605/625/700/705
986 425-15 Nut - Nyloc M10c 2 Johnston 600/605/625/700/705
987 28903 Lift Cylinder - See Chapter 11 1 Johnston 600/605/625/700/705
988 12869 Tubing - Nylon Ø6mm As Req’d   Johnston 600/605/625/700/705
989 60-1 Linch Pin Assembly 1 Johnston 600/605/625/700/705
990 40295-1 Tow Pin 1 Johnston 600/605/625/700/705
991 63001-1 Nozzle Trunking 1 Johnston 600/605/625/700/705
992 504-54 Hose Clip 2 Johnston 600/605/625/700/705
993 10883-1(JSC) Over Centre Buckle Clamp 2 Johnston 600/605/625/700/705
994 38 - Wheel Assembly - See Fig. 5 - 2 2 Johnston 600/605/625/700/705
995 40798-1 Adaptor Plate ] Required on 1 Johnston 600/605/625/700/705
996 124-171 Setscrew M10c x 30mm ] High Ground 4 Johnston 600/605/625/700/705
997 455-11 Washer M10 ] Clearance 4 Johnston 600/605/625/700/705
998 425-15 Nut - Nyloc M10c ] Chassis 4 Johnston 600/605/625/700/705
999 124-203 Setscrew M12c x 30mm ] Blanking 2 Johnston 600/605/625/700/705
1000 455-12 Washer - Plain M12 ] Rear Spray 2 Johnston 600/605/625/700/705
1001 425-16 Nut - Nyloc M12c ] Positions 2 Johnston 600/605/625/700/705
1002 40269-1 Lifting Hook 1 Johnston 600/605/625/700/705
1003 124-173 Setscrew M10c x 35mm 2 Johnston 600/605/625/700/705
1004 425-15 Nut - Nyloc M10c 2 Johnston 600/605/625/700/705
1005 43 N/A Cylinder Lift Bracket - Type ‘A’   Johnston 600/605/625/700/705
1006 50603-1 Cylinder Lift Bracket - Type ‘B’   Johnston 600/605/625/700/705
1007 6148-1 Pricker for Jets 1 Johnston 600/605/625/700/705
1008 281412-1 Branch Assembly comprising items 46 to 49 Johnston 600/605/625/700/705
1009 26997-1 Banjo 2 Johnston 600/605/625/700/705
1010 46382-3 Pipe - Hose Adaptor 2 Johnston 600/605/625/700/705
1011 38444 Hose 3/8" Bore x 335mm 1 Johnston 600/605/625/700/705
1012 501-1 Hose Clip 5 Johnston 600/605/625/700/705
1013 90696-1 ‘T’ Piece 1 Johnston 600/605/625/700/705
1014 63491-1 Nozzle Wheel comprising:   Johnston 600/605/625/700/705
1015 16752 Tyre 1 Johnston 600/605/625/700/705
1016 63493-1 Hub 1 Johnston 600/605/625/700/705
1017 16750-1 Backplate - Tyre 1 Johnston 600/605/625/700/705
1018 124-134 Setscrew M8c x 16mm 5 Johnston 600/605/625/700/705
1019 460-10 Washer - Spring M8 5 Johnston 600/605/625/700/705
1020 124-102 Setscrew M6c x 16mm 3 Johnston 600/605/625/700/705
1021 460-8 Washer - Spring M6 3 Johnston 600/605/625/700/705
1022 63495-1 Retainer Plate 1 Johnston 600/605/625/700/705
1023 63492-1 Spindle 1 Johnston 600/605/625/700/705
1024 14-52 Bearing 1 Johnston 600/605/625/700/705
1025 63494-1 Collar 1 Johnston 600/605/625/700/705
1026 9114-2 Washer - Special 2 Johnston 600/605/625/700/705
1027 425-18 Nut - Nyloc M16c 2 Johnston 600/605/625/700/705
1028 38-1 Grease Nipple 1/8" BSP Straight 1 Johnston 600/605/625/700/705
1029 62246-1 Heel - Cylinder Mounting 1 Johnston 600/605/625/700/705
1030 124-171 Setscrew M10c x 30mm 2 Johnston 600/605/625/700/705
1031 460-11 Washer - Spring M10 2 Johnston 600/605/625/700/705
1032 29149-1 Clevis Pin   Johnston 600/605/625/700/705
1033 39624 Spring Retaining Clip   Johnston 600/605/625/700/705
1034 28904 Pneumatic Cylinder See Chapter 11 1 Johnston 600/605/625/700/705
1035 180-13 Bolt 1/2" UNC x 2 1/2"1   Johnston 600/605/625/700/705
1036 400-21 Nut 1/2" UNC 1 Johnston 600/605/625/700/705
1037 510-3 Nut - Tubing 6mm 2 Johnston 600/605/625/700/705
1038 511-3 Sleeve - Tubing 6mm 2 Johnston 600/605/625/700/705
1039 41041-1 Sleeve - Tube Support 2 Johnston 600/605/625/700/705
1040 12869 Tubing Ø6mm Black As Req'd Johnston 600/605/625/700/705
1041 12353 Support 1 Johnston 600/605/625/700/705
1042 12354 Bushing 1 Johnston 600/605/625/700/705
1043 40275-16 Pivot Frame 1 Johnston 600/605/625/700/705
1044 63524-1 Stop - Fitted to lower face of pivot frame only 1 Johnston 600/605/625/700/705
1045 127-171 Setscrew M10c x 35mm 2 Johnston 600/605/625/700/705
1046 460-11 Washer - Spring M10 2 Johnston 600/605/625/700/705
1047 63518-1 Fork (Gives soft kickback) 1 Johnston 600/605/625/700/705
1048 41873-1 Spacer - Spring Location 1 Johnston 600/605/625/700/705
1049 41911-1 Nut - Spring Retaining 1 Johnston 600/605/625/700/705
1050 425-18 Nut - Nyloc M16 1 Johnston 600/605/625/700/705
1051 41895-2 Spring - Compression 1 Johnston 600/605/625/700/705
1052 29463-30 Lift Cylinder - Ø54 OD 1 Johnston 600/605/625/700/705
1053 90624-1 Spacer 2 Johnston 600/605/625/700/705
1054 40420-1 Pin 1 Johnston 600/605/625/700/705
1055 40421-1 Spacer 2 Johnston 600/605/625/700/705
1056 63377-1 Button 1 Johnston 600/605/625/700/705
1057 123-112 Bolt M8c x 60mm 1 Johnston 600/605/625/700/705
1058 93238-1 Lift Cable 1 Johnston 600/605/625/700/705
1059 62420-1 Guide - Lift Cable 1 Johnston 600/605/625/700/705
1060 501-6 Clip 1 Johnston 600/605/625/700/705
1061 40295-1 Nozzle Tow Pin 1 Johnston 600/605/625/700/705
1062 124-209 Setscrew M12c x 50mm 2 Johnston 600/605/625/700/705
1063 425-16 Nut - Nyloc M12 2 Johnston 600/605/625/700/705
1064 40272-1 Head - Pivot 1 Johnston 600/605/625/700/705
1065 40296-1 Lever - Pivot Head 1 Johnston 600/605/625/700/705
1066 40380-2 Pulley 1 Johnston 600/605/625/700/705
1067 40377-1 Bush 2 Johnston 600/605/625/700/705
1068 124-178 Setscrew M10c x 55mm 2 Johnston 600/605/625/700/705
1069 19 * 40360-1 Pin - Pivot 1 Johnston 600/605/625/700/705
1070 20 * 40292-1 Bush 2 Johnston 600/605/625/700/705
1071 21 * 38-1 Nipple - Grease 1/8" BSP Straight 4 Johnston 600/605/625/700/705
1072 38-8 Nipple - Grease 1/8" BSP x 90° 1 Johnston 600/605/625/700/705
1073 62805-1 Arm - Brush Upper (Including Item 42) 1 Johnston 600/605/625/700/705
1074 24 * 40361-1 Pin - Pivot 1 Johnston 600/605/625/700/705
1075 63370-1 Arm - Channel Brush 1 Johnston 600/605/625/700/705
1076 26 * 40910-1 Pin - Pivot 1 Johnston 600/605/625/700/705
1077 124-135 Setscrew M8c x 20mm 1 Johnston 600/605/625/700/705
1078 26726-1 Angle 2 Johnston 600/605/625/700/705
1079 460-8 Washer - Spring M6 4 Johnston 600/605/625/700/705
1080 420-13 Nut M6 4 Johnston 600/605/625/700/705
1081 42545-1 Connector 1 Johnston 600/605/625/700/705
1082 60690-1 Water Jet - Fan Spray 1 Johnston 600/605/625/700/705
1083 60688-1 Water Jet - Fan Spray 1 Johnston 600/605/625/700/705
1084 6148-1 Pricker for Spray Jets 1 Johnston 600/605/625/700/705
1085 60689-1 Nut - Nipple 2 Johnston 600/605/625/700/705
1086 88-4 Ball Valve 1/4" BSP 1 Johnston 600/605/625/700/705
1087 48682-1 Connector 1 Johnston 600/605/625/700/705
1088 90696-1 Tee Adaptor 1 Johnston 600/605/625/700/705
1089 40286-1 Mounting - Brush Motor 1 Johnston 600/605/625/700/705
1090 38 * 40389-1 Pin - Pivot 1 Johnston 600/605/625/700/705
1091 39 * 40362-1 Bush 1 Johnston 600/605/625/700/705
1092 40 * 40363-1 Spacer 2 Johnston 600/605/625/700/705
1093 41 * 123-159 Bolt M12c x 110mm 1 Johnston 600/605/625/700/705
1094 9331-1 Washer 1 Johnston 600/605/625/700/705
1095 425-16 Nut - Nyloc M12 1 Johnston 600/605/625/700/705
1096 42 * 29128-4 Bush - Non Lube 4 Johnston 600/605/625/700/705
1097 60138-1 Cable Adjuster 1 Johnston 600/605/625/700/705
1098 13566 Anti-vibration Mounting 1 Johnston 600/605/625/700/705
1099 41914-1 Washer - Extra Large 2 Johnston 600/605/625/700/705
1100 420-15 Nut M10 2 Johnston 600/605/625/700/705
1101 40963-1 Retainer - Cable 1 Johnston 600/605/625/700/705
1102 124-103 Setscrew M6c x 25mm 2 Johnston 600/605/625/700/705
1103 460-8 Washer - Spring M6 2 Johnston 600/605/625/700/705
1104 420-13 Nut M8 2 Johnston 600/605/625/700/705
1105 46 - Brush and Motor Assembly - See Fig. 6 - 2 Johnston 600/605/625/700/705
1106 124-171 Setscrew M10c x 30mm 2 Johnston 600/605/625/700/705
1107 124-173 Setscrew M10c x 35mm 2 Johnston 600/605/625/700/705
1108 49 * 124-178 Setscrew M10c x 55mm 1 Johnston 600/605/625/700/705
1109 460-11 Washer - Spring M10 6 Johnston 600/605/625/700/705
1110 420-15 Nut M10 7 Johnston 600/605/625/700/705
1111 52 * 124-146 Setscrew M8c x 55mm 1 Johnston 600/605/625/700/705
1112 460-10 Washer - Spring M8 1 Johnston 600/605/625/700/705
1113 420-14 Nut M8 1 Johnston 600/605/625/700/705
1114 124-207 Setscrew M12c x 40mm 3 Johnston 600/605/625/700/705
1115 9331-1 Washer 3 Johnston 600/605/625/700/705
1116 425-16 Nut - Nyloc M12 3 Johnston 600/605/625/700/705
1117 124-205 Setscrew M12c x 35mm 1 Johnston 600/605/625/700/705
1118 460-12 Washer - Spring M12 1 Johnston 600/605/625/700/705
1119 420-16 Nut M12 1 Johnston 600/605/625/700/705
1120 288-12 Grommet 2 Johnston 600/605/625/700/705
1121 51-42 Hose Clamp 1 Johnston 600/605/625/700/705
1122 51-43 Top Plate 1 Johnston 600/605/625/700/705
1123 124-148 Setscrew M8 x 65mm 1 Johnston 600/605/625/700/705
1124 425-1 Nut - Nyloc 1 Johnston 600/605/625/700/705
1125 42534-1 61109-1 Motor Assembly LH ] Comprising   Johnston 600/605/625/700/705
1126 42534-2 61109-2 Motor Assembly RH ] Items 1-7   Johnston 600/605/625/700/705
1127 40550-1 61108-1 Motor - Hydraulic 1 Johnston 600/605/625/700/705
1128 11880 < Motor Seal Kit   Johnston 600/605/625/700/705
1129 263-4 < Adaptor 1/2" BSP 2 Johnston 600/605/625/700/705
1130 451-126 < Washer 2 Johnston 600/605/625/700/705
1131 42533-1 < Mounting 1 Johnston 600/605/625/700/705
1132 124-208 < Setscrew M12c x 45mm 2 Johnston 600/605/625/700/705
1133 460-12 < Washer - Spring M12 2 Johnston 600/605/625/700/705
1134 420-16 < Nut M12c 2 Johnston 600/605/625/700/705
1135 93969-1 93970-1 Drive Adaptor Plate 1 Johnston 600/605/625/700/705
1136 135-58 < Setscrew M8c x 25mm ‘Eslok’ 1 Johnston 600/605/625/700/705
1137 136-24 < Coach Bolt M8c x 50mm 4 Johnston 600/605/625/700/705
1138 460-10 < Washer - Spring M8 4 Johnston 600/605/625/700/705
1139 420-14 < Nut M8c 4 Johnston 600/605/625/700/705
1140 40585-1 - Brush - Normal Duty Ø500 Black Top   Johnston 600/605/625/700/705
1141 40585-1(JSC) - Brush - Normal Duty Ø12"   Johnston 600/605/625/700/705
1142 40585-2 - Brush - Heavy Duty Ø500 Green Top   Johnston 600/605/625/700/705
1143 40585-2(JSC) - Brush - Heavy Duty Ø12"   Johnston 600/605/625/700/705
1144 835-20 - Weedrip Ø560   Johnston 600/605/625/700/705
1145 40275-14 Pivot Frame 1 Johnston 600/605/625/700/705
1146 40302-1 Lever - Brush Curtain 1 Johnston 600/605/625/700/705
1147 40384-1 Catch 1 Johnston 600/605/625/700/705
1148 124-102 Setscrew M6c x 16mm 1 Johnston 600/605/625/700/705
1149 460-8 Washer - Spring M6 1 Johnston 600/605/625/700/705
1150 420-13 Nut M6 1 Johnston 600/605/625/700/705
1151 40304-1 Hinge Plate 2 Johnston 600/605/625/700/705
1152 127-139 Setscrew - Csk M8c x 30mm 4 Johnston 600/605/625/700/705
1153 40382-1 Link 1 Johnston 600/605/625/700/705
1154 40383-1 Bush 1 Johnston 600/605/625/700/705
1155 124-143 Setscrew M8c x 40mm 1 Johnston 600/605/625/700/705
1156 62831-1 Jib - Brush Curtain 1 Johnston 600/605/625/700/705
1157 40385-1 Pin - Retaining 1 Johnston 600/605/625/700/705
1158 124-141 Setscrew M8c x 35mm 1 Johnston 600/605/625/700/705
1159 460-10 Washer - Spring M8 1 Johnston 600/605/625/700/705
1160 420-14 Nut M8c 1 Johnston 600/605/625/700/705
1161 62823-1 Brush Curtain 1 Johnston 600/605/625/700/705
1162 63334-1 Rubber Curtain 1 Johnston 600/605/625/700/705
1163 62454-1 Clamp Strip 1 Johnston 600/605/625/700/705
1164 124-167 Setscrew M10c x 20mm 5 Johnston 600/605/625/700/705
1165 57-5 Washer - Plain Large M10 5 Johnston 600/605/625/700/705
1166 62822-1 Bracket - Mudflap Mounting 1 Johnston 600/605/625/700/705
1167 62819-1 Mounting 1 Johnston 600/605/625/700/705
1168 50594-1 Mounting (JSC) 1 Johnston 600/605/625/700/705
1169 124-212 Setscrew M12c x 65mm 2 Johnston 600/605/625/700/705
1170 63178-1 Plate - Mudflap - 600 Series 1 Johnston 600/605/625/700/705
1171 62821-1 Plate - Mudflap - 625, 700 Series 1 Johnston 600/605/625/700/705
1172 40435-2 Rubber - Mudflap - 600 Series 1 Johnston 600/605/625/700/705
1173 62817-1 Rubber - Mudflap - 625, 700 Series (570mm long) 1 Johnston 600/605/625/700/705
1174 63178-1 Plate - Mudflap - 600 Series (460mm long) 1 Johnston 600/605/625/700/705
1175 62816-1 Clamp - Mudflap - 625, 700 Series 1 Johnston 600/605/625/700/705
1176 457-4 Washer - Plain Large M8 5 Johnston 600/605/625/700/705
1177 425-14 Nut - Nyloc M8 5 Johnston 600/605/625/700/705
1178 460-10 Washer - Spring M8 8 Johnston 600/605/625/700/705
1179 420-14 Nut M8 8 Johnston 600/605/625/700/705
1180 460-12 Washer - Spring M12 3 Johnston 600/605/625/700/705
1181 420-16 Nut M12 3 Johnston 600/605/625/700/705
1182 124-169 Setscrew M8c x 25mm 4 Johnston 600/605/625/700/705
1183 63582-1 Pin 2 Johnston 600/605/625/700/705
1184 289-27 Spring - Cotter 2 Johnston 600/605/625/700/705
1185 124-201 Setscrew M12c x 25mm 1 Johnston 600/605/625/700/705
1186 48843-1 Hose Guide ) 1 Johnston 600/605/625/700/705
1187 425-16 Nut - Nyloc M12 ) 1 Johnston 600/605/625/700/705
1188 42515-1 Hose Clamp ) 1 Johnston 600/605/625/700/705
1189 40545-1 Hose Clamp ) If Fitted 2 Johnston 600/605/625/700/705
1190 45014-9 Spacer ) 1 Johnston 600/605/625/700/705
1191 124-147 Setscrew M8c x 60mm ) 1 Johnston 600/605/625/700/705
1192 24-1 Cable Tie ) 2 Johnston 600/605/625/700/705
1193 40970-1 Mast 1 2 Johnston 600/605/625/700/705
1194 59-3 Pin - Tension 1 2 Johnston 600/605/625/700/705
1195 28905-1 Pneumatic Cylinder See Chapter 11 1 2 Johnston 600/605/625/700/705
1196 12869 Tubing Ø6mm Black As Req'd Johnston 600/605/625/700/705
1197 63088-6 Air Regulator Assembly. Comprising Items 6-9 1 1 Johnston 600/605/625/700/705
1198 72-14 Air Regulator (Seal Kit 72-16) 1 1 Johnston 600/605/625/700/705
1199 5259 Pipe Plug 1 1 Johnston 600/605/625/700/705
1200 72-15 Mounting Ring 1 1 Johnston 600/605/625/700/705
1201 5259 Plug 1/8" BSPT Male 1 -   Johnston 600/605/625/700/705
1202 552-3 Elbow 1/8" BSPT Male 2 3 Johnston 600/605/625/700/705
1203 48016-1 Pod Base 1 1 Johnston 600/605/625/700/705
1204 124-109 Setscrew M6c x 35mm 4 4 Johnston 600/605/625/700/705
1205 460-8 Washer - Spring M6 4 4 Johnston 600/605/625/700/705
1206 420-16 Nut M6c 4 4 Johnston 600/605/625/700/705
1207 48014-1 Shroud 1 1 Johnston 600/605/625/700/705
1208 181-1 Screw Pan Hd. M5c x 10mm 4 4 Johnston 600/605/625/700/705
1209 288-10 Grommet 1 1 Johnston 600/605/625/700/705
1210 63423-1 Pin 1 2 Johnston 600/605/625/700/705
1211 455-16 Washer Ø20 1 2 Johnston 600/605/625/700/705
1212 460-10 Washer - Spring M8 2 4 Johnston 600/605/625/700/705
1213 41267-3 ‘Save Wear’ Compensator Kit - Single 3 Johnston 600/605/625/700/705
1214 41267-4 ‘Save Wear’ Compensator Kit - Dual 3 Johnston 600/605/625/700/705
1215 41270-1 Compensator 1 2 Johnston 600/605/625/700/705
1216 41271-1 Mast 1 2 Johnston 600/605/625/700/705
1217 41272-1 Boss 1 2 Johnston 600/605/625/700/705
1218 41273-1 Spacer 3 6 Johnston 600/605/625/700/705
1219 425-16 Nut - Nyloc M12 1 2 Johnston 600/605/625/700/705
1220 3637-1 Spring 1 2 Johnston 600/605/625/700/705
1221 500-166 Split Cotter Pin 1 2 Johnston 600/605/625/700/705
1222 63424-1 Pin 1 2 Johnston 600/605/625/700/705
1223 41241-2 Bush 2 4 Johnston 600/605/625/700/705
1224 124-171 Setscrew M10c x 30mm 2 4 Johnston 600/605/625/700/705
1225 460-11 Washer - Spring M10 2 4 Johnston 600/605/625/700/705
1226 11 * 124-139 Setscrew M8c x 30mm 2 4 Johnston 600/605/625/700/705
1227 460-10 Washer - Spring M8   Johnston 600/605/625/700/705
1228 62100-1 Single Sweep Assembly - Ø380 3 -   Johnston 600/605/625/700/705
1229 62100-2 Dual Sweep Assembly - Ø380 - 3 Johnston 600/605/625/700/705
1230 62100-23 Dual Sweep Assembly - Ø400   Johnston 600/605/625/700/705
1231 94897-1 Carriage 1 1 Johnston 600/605/625/700/705
1232 801406-1 Bracket 1 1 Johnston 600/605/625/700/705
1233 124-135 Setscrew M8c x 20mm 2 2 Johnston 600/605/625/700/705
1234 425-14 Nut - Nyloc M8c 2 2 Johnston 600/605/625/700/705
1235 532-4 Adaptor 1 1 Johnston 600/605/625/700/705
1236 510-4 Tubing Nut Ø8mm 2 2 Johnston 600/605/625/700/705
1237 511-4 Tubing Sleeve Ø8mm X 650mm 2 2 Johnston 600/605/625/700/705
1238 6 - See Chapter 10 Johnston 600/605/625/700/705
1239 521-8 Elbow 1/4" BSP x Ø8mm 1 1 Johnston 600/605/625/700/705
1240 62097-1 Pin - Anchor 2 2 Johnston 600/605/625/700/705
1241 62101-1 End Plate - Bearing Ø380 1 1 Johnston 600/605/625/700/705
1242 93370-1 End Plate - Bearing Ø400 - 1 Johnston 600/605/625/700/705
1243 27-2 Circlip 4 4 Johnston 600/605/625/700/705
1244 62102-1 End Plate - Motor Ø380 1 1 Johnston 600/605/625/700/705
1245 93369-1 End Plate - Motor Ø400 - 1 Johnston 600/605/625/700/705
1246 124-167 Setscrew M10c x 20mm 8 8 Johnston 600/605/625/700/705
1247 460-11 Washer - Spring M10 6 6 Johnston 600/605/625/700/705
1248 62054-1 Bearing Housing 1 1 Johnston 600/605/625/700/705
1249 62053-1 Labyrinth - Bearing 1 1 Johnston 600/605/625/700/705
1250 62051-1 Adaptor - Bearing 1 1 Johnston 600/605/625/700/705
1251 14-47 Bearing 1 1 Johnston 600/605/625/700/705
1252 80-94 'O' Ring 1 1 Johnston 600/605/625/700/705
1253 27-15 Circlip 1 1 Johnston 600/605/625/700/705
1254 38-30 Grease Nipple 2 2 Johnston 600/605/625/700/705
1255 124-139 Setscrew M8c x 30mm 4 4 Johnston 600/605/625/700/705
1256 425-14 Nut M8c Nyloc 4 4 Johnston 600/605/625/700/705
1257 72250-2 Hydraulic Motor (Incorporates Labyrinth) 1 1 Johnston 600/605/625/700/705
1258 244-500 Motor Seal Kit 1 1 Johnston 600/605/625/700/705
1259 263-4 Adaptor 1/2" BSP 2 2 Johnston 600/605/625/700/705
1260 451-126 Washer - Sealing 1/2" BSP 2 2 Johnston 600/605/625/700/705
1261 62050-1 Drive Adaptor 1 1 Johnston 600/605/625/700/705
1262 62064-1 Washer - Special 1 1 Johnston 600/605/625/700/705
1263 124-136 Setscrew M8c x 22mm 1 1 Johnston 600/605/625/700/705
1264 460-10 Washer - Spring M8 1 1 Johnston 600/605/625/700/705
1265 124-171 Setscrew M10c x 30mm 4 4 Johnston 600/605/625/700/705
1266 460-11 Washer - Spring M10 4 4 Johnston 600/605/625/700/705
1267 62080-1 Compensator 1 1 Johnston 600/605/625/700/705
1268 62095-1 Keeper Plate 1 1 Johnston 600/605/625/700/705
1269 124 -135 Setscrew M8c x 20mm 1 1 Johnston 600/605/625/700/705
1270 460-10 Washer - Spring M8 1 1 Johnston 600/605/625/700/705
1271 29395-2 Bearing 1 1 Johnston 600/605/625/700/705
1272 62065-1 Retaining Strip 1 -   Johnston 600/605/625/700/705
1273 62075-1 Retaining Strip - 1 Johnston 600/605/625/700/705
1274 123-213 Setscrew M12c x 70mm 2 2 Johnston 600/605/625/700/705
1275 425-16 Nut - Nyloc M12c 2 2 Johnston 600/605/625/700/705
1276 62074-1 Spacer - 2 Johnston 600/605/625/700/705
1277 29160-1 Hydraulic Cylinder - See Chapter 10 - 1 Johnston 600/605/625/700/705
1278 124-199 Setscrew M12c x 20mm - 1 Johnston 600/605/625/700/705
1279 457-6 Washer - Plain M12 - 1 Johnston 600/605/625/700/705
1280 62076-1 Plate Cylinder Mount - 1 Johnston 600/605/625/700/705
1281 124-169 Setscrew M10c x 25mm 6 8 Johnston 600/605/625/700/705
1282 425-15 Nut - Nyloc M10c 6 8 Johnston 600/605/625/700/705
1283 62078-1 Boss - Cylinder Mount - 1 Johnston 600/605/625/700/705
1284 124-185 Setscrew M10c x 90mm - 1 Johnston 600/605/625/700/705
1285 425-15 Nut - Nyloc M10c - 1 Johnston 600/605/625/700/705
1286 92820-1 Curtain 1 1 Johnston 600/605/625/700/705
1287 42486-1 Curtain Rubber 1 1 Johnston 600/605/625/700/705
1288 42487-1 Retaining Strip 1 1 Johnston 600/605/625/700/705
1289 124-137 Setscrew M8c x 25mm 6 6 Johnston 600/605/625/700/705
1290 455-10 Washer - Plain M8 6 6 Johnston 600/605/625/700/705
1291 425-14 Nut - Nyloc M8c 6 6 Johnston 600/605/625/700/705
1292 62103-1 Mount 2 2 Johnston 600/605/625/700/705
1293 46 - Hose - See Chapter 10 Johnston 600/605/625/700/705
1294 47 - Hose - See Chapter 10 Johnston 600/605/625/700/705
1295 48 - Hose - See Chapter 10 Johnston 600/605/625/700/705
1296 49 - Hose - See Chapter 10 Johnston 600/605/625/700/705
1297 40075-2 Clamp - 2 Johnston 600/605/625/700/705
1298 124-121 Setscrew M8c x 35mm - 4 Johnston 600/605/625/700/705
1299 124-167 Setscrew M10c x 20mm 6 6 Johnston 600/605/625/700/705
1300 425-15 Nut - Nyloc M10c 6 6 Johnston 600/605/625/700/705
1301 62070-1 Tow Bar 1 1 Johnston 600/605/625/700/705
1302 62073-1 Shaft 1 1 Johnston 600/605/625/700/705
1303 62077-1 Bolt Special 2 2 Johnston 600/605/625/700/705
1304 62099-2 Mounting Bush 1 2 Johnston 600/605/625/700/705
1305 124-215 Setscrew M12c x 80mm 1 2 Johnston 600/605/625/700/705
1306 457-6 Washer M12 Plain 1 2 Johnston 600/605/625/700/705
1307 64 - Mounting - See Fig. 6 - 3, Item 13 1 2 Johnston 600/605/625/700/705
1308 65 - Tow Plate - See Chapter 15 1 -   Johnston 600/605/625/700/705
1309 62099-1 Bush 1 -   Johnston 600/605/625/700/705
1310 425-16 Nut - Nyloc M12c 2 2 Johnston 600/605/625/700/705
1311 457-6 Washer - Large M12 1 -   Johnston 600/605/625/700/705
1312 51-43 Top Plate 1 1 Johnston 600/605/625/700/705
1313 51-44 Hose Clamp 2 2 Johnston 600/605/625/700/705
1314 124-148 Setscrew M8c x 65mm 1 1 Johnston 600/605/625/700/705
1315 425-13 Nut - Nyloc M8c 1 1 Johnston 600/605/625/700/705
1316 11879 Drive Key 1 1 Johnston 600/605/625/700/705
1317 H704-75 Hydraulic Hose 1 1 Johnston 600/605/625/700/705
1318 265-1 Adaptor 1 1 Johnston 600/605/625/700/705
1319 451-4 Washer Sealing 1 1 Johnston 600/605/625/700/705
1320 5104 Collar Plug 1 1 Johnston 600/605/625/700/705
1321 38-11 Grease Nipple 90° 1 1 Johnston 600/605/625/700/705
1322 76 * 200449-1 Tab Washer 2 2 Johnston 600/605/625/700/705
1323 45013-3 Spacer - Shouldered 1 -   Johnston 600/605/625/700/705
1324 45014-15 Spacer - Plain 1 -   Johnston 600/605/625/700/705
1325 123-159 Bolt M12c x 110mm 1 -   Johnston 600/605/625/700/705
1326 45013-2 Spacer - Shouldered 1 -   Johnston 600/605/625/700/705
1327 123-154 Bolt M12c x 80mm 1 -   Johnston 600/605/625/700/705
1328 45013-1 Spacer - Shouldered 1 -   Johnston 600/605/625/700/705
1329 123-155 Bolt M12c x 85mm 1 -   Johnston 600/605/625/700/705
1330 45013/4 Spacer - Shouldered 1 -   Johnston 600/605/625/700/705
1331 123-158 Bolt M12c x 100mm 1 -   Johnston 600/605/625/700/705
1332 76 61   Johnston 600/605/625/700/705
1333 42546-3 Core Assembly with Poly Segments Ø380 3 --   Johnston 600/605/625/700/705
1334 42546-5 Core Assembly with Poly Segments Ø400 - - 3 Johnston 600/605/625/700/705
1335 10269-6 JSC Core Assembly with Poly Segments Ø380 3 --   Johnston 600/605/625/700/705
1336 10269-7 JSC Core Assembly with Wire Segments Ø380 - 3 -   Johnston 600/605/625/700/705
1337 42546-4 Core Assembly with Poly and Wire Segments - 33 Johnston 600/605/625/700/705
1338 0269-10 JSC Core Assembly with Poly and Wire Segments - 33 Johnston 600/605/625/700/705
1339 62061-1 Stock 1 1 1 Johnston 600/605/625/700/705
1340 62055-1 Drive Plate 1 1 1 Johnston 600/605/625/700/705
1341 129-154 Cap Screw M10c x 25mm 4 4 4 Johnston 600/605/625/700/705
1342 460-11 Washer - Spring 4 4 4 Johnston 600/605/625/700/705
1343 13514 Brush Segment - Polypropylene Ø380 43 - 22 Johnston 600/605/625/700/705
1344 39040 Brush Segment - Wire Ø380 - 43 21 Johnston 600/605/625/700/705
1345 834-1 Brush Segment - Polypropylene Ø406 - - 42 Johnston 600/605/625/700/705
1346 13515 Spacer 42 42 42 Johnston 600/605/625/700/705
1347 124-171 Setscrew M10c x 30mm 8 Johnston 600/605/625/700/705
1348 124-175 Setscrew M10c x 40mm 4 Johnston 600/605/625/700/705
1349 455-11 Washer - Plain M10 4 Johnston 600/605/625/700/705
1350 425-15 Nut - Nyloc M10c 12 Johnston 600/605/625/700/705
1351 42541-1 Plate 2 Johnston 600/605/625/700/705
1352 40405-1 Lifting Eye 2 Johnston 600/605/625/700/705
1353 40404-1 Clamp Plate 2 Johnston 600/605/625/700/705
1354 8 - Lift Cylinder - See page 2 Johnston 600/605/625/700/705
1355 40798-1 Adaptor Plate - If required * 2 Johnston 600/605/625/700/705
1356 72-45 Regulator   Johnston 600/605/625/700/705
1357 1 N.S.S. Diaphragm Assembly 1 Johnston 600/605/625/700/705
1358 2 N.S.S. Valve Assembly 1 Johnston 600/605/625/700/705
1359 3 N.S.S. Valve Spring 1 Johnston 600/605/625/700/705
1360 4 N.S.S. ‘O' Ring 1 Johnston 600/605/625/700/705
1361 25890-4 Spring 1 Johnston 600/605/625/700/705
1362 41240-1 Locking Nut 1 Johnston 600/605/625/700/705
1363 72-36 Repair Kit Comprising:- Item No’s 1, 2, 3 & 4 Johnston 600/605/625/700/705
1364 41966-2 LH Air Regulator Assembly LH -   Johnston 600/605/625/700/705
1365 41966-1 RH Air Regulator Assembly - RH   Johnston 600/605/625/700/705
1366 552-3 Elbow 1/8" BSP x 6mm Tube 1 2 Johnston 600/605/625/700/705
1367 72-4 Non Return Valve 1 1 Johnston 600/605/625/700/705
1368 532-7 Adaptor 2 2 Johnston 600/605/625/700/705
1369 9756 Plug 1 1 Johnston 600/605/625/700/705
1370 72-45 Regulator See Fig. 7 - 4 1 1 Johnston 600/605/625/700/705
1371 72-1 Shuttle Valve 1 1 Johnston 600/605/625/700/705
1372 42652-1 Adaptor 1 1 Johnston 600/605/625/700/705
1373 544-3 Tee 1/8" BSP x 6mm Tube 1 1 Johnston 600/605/625/700/705
1374 12869 Nylon Tube As Req'd Johnston 600/605/625/700/705
1375 537-3 Straight Adaptor 1/8" BSP 2 1 Johnston 600/605/625/700/705
1376 6 5 8 1 2 38 5 6 7 4 3 Johnston 600/605/625/700/705
1377 9 12 12 9 10 11 Johnston 600/605/625/700/705
1378 53043-1 53043-9 Wanderhose Assembly - 600/605 Series   Johnston 600/605/625/700/705
1379 53043-22 53043-31 Wanderhose Assembly - 625 Series   Johnston 600/605/625/700/705
1380 53043-11 53043-10 Wanderhose Assembly - 700/705 Series   Johnston 600/605/625/700/705
1381 41803-1 < Turret 1 Johnston 600/605/625/700/705
1382 5955-1 < Seal 2 Johnston 600/605/625/700/705
1383 124-167 < Setscrew M10c x 20mm 6 Johnston 600/605/625/700/705
1384 460-11 < Washer - Spring M10 6 Johnston 600/605/625/700/705
1385 40912-2 < Turn Table Assembly Comprising: Items 4 - 7 Johnston 600/605/625/700/705
1386 40722-1 < Outer Race 1 Johnston 600/605/625/700/705
1387 38-3 < Grease Nipple 1/4" BSP Straight 2 Johnston 600/605/625/700/705
1388 22-8 < Steel Ball 105 Johnston 600/605/625/700/705
1389 40721-1 < Inner Race 1 Johnston 600/605/625/700/705
1390 40723-1 < Seal Plate 1 Johnston 600/605/625/700/705
1391 124-169 < Setscrew M10c x 25mm 8 Johnston 600/605/625/700/705
1392 460-11 < Washer - Spring M10 8 Johnston 600/605/625/700/705
1393 40420-1 < Pin 1 Johnston 600/605/625/700/705
1394 40746-1 41814-1 Claw 1 Johnston 600/605/625/700/705
1395 124-137 < Setscrew M8c x 25mm 1 Johnston 600/605/625/700/705
1396 460-10 < Washer - Spring M8 1 Johnston 600/605/625/700/705
1397 40691-1 N/A Spring - 600/605/625 Series 4 Johnston 600/605/625/700/705
1398 40691-1 N/A Spring - 700/705 Series 5 Johnston 600/605/625/700/705
1399 40746-2 41814-2 Claw 1 Johnston 600/605/625/700/705
1400 41836-1 < Nut - Special M16c 2 Johnston 600/605/625/700/705
1401 455-16 < Washer - Plain M20 2 Johnston 600/605/625/700/705
1402 41833-1 40728-1 Pivot Block 2 Johnston 600/605/625/700/705
1403 123-131 < Bolt M10c x 55mm 4 Johnston 600/605/625/700/705
1404 460-11 < Washer - Spring M10 4 Johnston 600/605/625/700/705
1405 62978-1 41801-1 Boom - 600/605 Series 1 Johnston 600/605/625/700/705
1406 95031-1 96215-1 Boom - 625 Series 1 Johnston 600/605/625/700/705
1407 62980-1 41850-1 Boom - 700/705 Series 1 Johnston 600/605/625/700/705
1408 40780-1 < Flexible Joint 1 Johnston 600/605/625/700/705
1409 503-8 503-11 Hose Clip 1 Johnston 600/605/625/700/705
1410 504-55 < Hose Clip 1 Johnston 600/605/625/700/705
1411 39382 < Rubber Stop 1 Johnston 600/605/625/700/705
1412 129-65 < Cap Screw M5c x 20mm 2 Johnston 600/605/625/700/705
1413 455-7 < Washer - Plain M5 2 Johnston 600/605/625/700/705
1414 425-12 < Nut - Nyloc M5c 2 Johnston 600/605/625/700/705
1415 39444 < Hose 6m Johnston 600/605/625/700/705
1416 501-1 < Hose Clip 2 Johnston 600/605/625/700/705
1417 40755-1 < Water Jet 1 Johnston 600/605/625/700/705
1418 453-1 < Washer - Fibre 3 Johnston 600/605/625/700/705
1419 26997-1 < Banjo 1 Johnston 600/605/625/700/705
1420 46382-3 < Hose Adaptor 1 Johnston 600/605/625/700/705
1421 410-32 < Nut - Domed M12c 1 Johnston 600/605/625/700/705
1422 40207-1 < Hook 1 Johnston 600/605/625/700/705
1423 420-18 < Nut M16c 2 Johnston 600/605/625/700/705
1424 40741-1 41802-1 Jib 1 Johnston 600/605/625/700/705
1425 124-199 < Setscrew M12c x 20mm 4 Johnston 600/605/625/700/705
1426 460-12 < Washer - Spring M12 4 Johnston 600/605/625/700/705
1427 6004-1 15916-1 Hose 1 Johnston 600/605/625/700/705
1428 6005-1 15917-1 Hose 1 Johnston 600/605/625/700/705
1429 504-51 503-11 Hose Clip 5 Johnston 600/605/625/700/705
1430 6003-1 6003-8 Coupling - Female - 600/605 Series 1 Johnston 600/605/625/700/705
1431 61045-2 61045-1 Coupling - Female - 625/700/705 Series 1 Johnston 600/605/625/700/705
1432 5992-1 15895-1 Sleeve - 600/605 Series 1 Johnston 600/605/625/700/705
1433 61063-1 61046-1 Sleeve - 625/700/705 Series 1 Johnston 600/605/625/700/705
1434 193-8 < Screw Rd. Hd. Self Tapping 6 Johnston 600/605/625/700/705
1435 6002-1 < Spring 2 Johnston 600/605/625/700/705
1436 58-6 < Pin - Spring Tension 2 Johnston 600/605/625/700/705
1437 5999-1 < Catch 2 Johnston 600/605/625/700/705
1438 6027-1 15899-1 Hose End Fitting 1 Johnston 600/605/625/700/705
1439 6212-1 15920-1 Handle 1 Johnston 600/605/625/700/705
1440 5996-1 5996-4 Coupling - Male 1 Johnston 600/605/625/700/705
1441 6216-1 < Spring Clip 2 Johnston 600/605/625/700/705
1442 40784-1 16319-1 Extension Assembly - Includes Item 41 1 Johnston 600/605/625/700/705
1443 42463-1 < Anchorage Bracket - 600/605 Series 1 Johnston 600/605/625/700/705
1444 61044-1 < Anchorage Bracket - 625/700/705 Series 1 Johnston 600/605/625/700/705
1445 42462-1 42738-1 Anchorage 1 Johnston 600/605/625/700/705
1446 6043-1 < Plate - Rubber Retaining 1 Johnston 600/605/625/700/705
1447 5688-1 5688-2 Rubber Disc 1 Johnston 600/605/625/700/705
1448 124-103 < Setscrew M6c x 20mm 1 Johnston 600/605/625/700/705
1449 460-8 < Washer - Spring M6 1 Johnston 600/605/625/700/705
1450 420-13 < Nut M6c 1 Johnston 600/605/625/700/705
1451 135-57 < Socket Button Hd. Screw M8c x 20mm 2 Johnston 600/605/625/700/705
1452 460-10 < Washer - Spring M8 2 Johnston 600/605/625/700/705
1453 420-14 < Nut M8c 2 Johnston 600/605/625/700/705
1454 124-169 < Setscrew M10c x 25mm 2 Johnston 600/605/625/700/705
1455 460-11 < Washer - Spring M10 2 Johnston 600/605/625/700/705
1456 62952-1 49051-1 Pivot 1 Johnston 600/605/625/700/705
1457 49053-1 49052-1 Pivot Pin 2 Johnston 600/605/625/700/705
1458 455-14 < Washer - Plain M16 2 Johnston 600/605/625/700/705
1459 425-18 < Nut M16c Nyloc 2 Johnston 600/605/625/700/705
1460 40781-1 < Grab 1 Johnston 600/605/625/700/705
1461 54 N/A 135-1 Setscrew - Brass M12c x 25mm 1 Johnston 600/605/625/700/705
1462 27303-1 27303-2 Hose Extension Assembly   Johnston 600/605/625/700/705
1463 61065-1 Extension Tray 1 Johnston 600/605/625/700/705
1464 46518-3 Spacer 4 Johnston 600/605/625/700/705
1465 123-129 Bolt M10c x 45mm 4 Johnston 600/605/625/700/705
1466 425-15 Nut M10c Nyloc 4 Johnston 600/605/625/700/705
1467 61067-1 Handle 4 Johnston 600/605/625/700/705
1468 59-26 Cotter Pin 4 Johnston 600/605/625/700/705
1469 60744-2 > Plastic Duct 6m Johnston 600/605/625/700/705
1470 63039-1 57074-1 Coupling 1 Johnston 600/605/625/700/705
1471 504-51 > Hose Clip 2 Johnston 600/605/625/700/705
1472 63500-11 > Door (less Bushes 29128-3) 1 Johnston 600/605/625/700/705
1473 63047-1 57076-1 Rubber Flap 1 Johnston 600/605/625/700/705
1474 60739-1 > Suction Tube - Plastic 1 Johnston 600/605/625/700/705
1475 50236-1 > Suction Tube - Steel (Alternative) 1 Johnston 600/605/625/700/705
1476 63349-1 > Holster 1 Johnston 600/605/625/700/705
1477 60716-1 > Handle And Clamp 1 Johnston 600/605/625/700/705
1478 123-86 > Bolt M6c x 40mm 1 Johnston 600/605/625/700/705
1479 425-13 > Nut M6c Nyloc 1 Johnston 600/605/625/700/705
1480 181-3 > Screw - Pozidriv M5c x 16mm 2 Johnston 600/605/625/700/705
1481 455-7 > Washer - Plain M5 2 Johnston 600/605/625/700/705
1482 460-7 > Washer - Spring M5 2 Johnston 600/605/625/700/705
1483 420-12 > Nut M5c 2 Johnston 600/605/625/700/705
1484 60718-1 > Hook - Hose 1 Johnston 600/605/625/700/705
1485 63051-1 > Double Hook - Hose 1 Johnston 600/605/625/700/705
1486 63350-1 > Bracket 4 Johnston 600/605/625/700/705
1487 63045-1 > Lug - Hose Stowage Bracket 1 Johnston 600/605/625/700/705
1488 124-102 > Setscrew M6c x 16mm 4 Johnston 600/605/625/700/705
1489 455-8 > Washer - Plain M6 4 Johnston 600/605/625/700/705
1490 460-8 > Washer - Spring M6 4 Johnston 600/605/625/700/705
1491 420-13 > Nut M6c 4 Johnston 600/605/625/700/705
1492 60709-1 > Trough 2 Johnston 600/605/625/700/705
1493 6849 > Titanfast As Req'd Johnston 600/605/625/700/705
1494 17 & 18 20674-3 > Reflective Plate (Pair) 1 Johnston 600/605/625/700/705
1495 194-9 > Screw - Pan Hd. No. 6 x 16mm 12 Johnston 600/605/625/700/705
1496 62984-1 > Cover 1 Johnston 600/605/625/700/705
1497 124-167 > Setscrew M10c x 20mm 6 Johnston 600/605/625/700/705
1498 124-135 > Setscrew M8c x 20mm 24 Johnston 600/605/625/700/705
1499 460-10 > Washer - Spring M8 32 Johnston 600/605/625/700/705
1500 420-14 > Nut M8c 32 Johnston 600/605/625/700/705
1501 124-135 > Setscrew M8c x 65mm 14 Johnston 600/605/625/700/705
1502 460-10 > Washer - Spring M8 6 Johnston 600/605/625/700/705
1503 435-12 > Retaining Nut M8c 6 Johnston 600/605/625/700/705
1504 455-11 > Washer - Plain M10 6 Johnston 600/605/625/700/705
1505 460-11 > Washer - Spring M10 6 Johnston 600/605/625/700/705
1506 420-15 > Nut M10c 6 Johnston 600/605/625/700/705
1507 63043-1 > Hook - Short 1 Johnston 600/605/625/700/705
1508 63048-1 > Plate - Retainer 1 Johnston 600/605/625/700/705
1509 124-111 > Bolt M8c x 55mm 3 Johnston 600/605/625/700/705
1510 425-14 > Nut - Nyloc M8c 3 Johnston 600/605/625/700/705
1511 57077-1 > Spacer 1 Johnston 600/605/625/700/705
1512 62990-1 Body - 600/605 Series 1 Johnston 600/605/625/700/705
1513 60708-4 Side Plate - 600/605 Series 1 Johnston 600/605/625/700/705
1514 60707-1 Face Plate 1 Johnston 600/605/625/700/705
1515 60706-1 Gate 1 Johnston 600/605/625/700/705
1516 60704-1 Packing 2 Johnston 600/605/625/700/705
1517 60302-1 Davit Mounting 1 Johnston 600/605/625/700/705
1518 29128-1 Non Lube Bush (2 per end) 4 Johnston 600/605/625/700/705
1519 60721-1 Davit   Johnston 600/605/625/700/705
1520 60309-1 Joint - Universal 1 Johnston 600/605/625/700/705
1521 60303-1 Pin - Pivot 1 Johnston 600/605/625/700/705
1522 60317-1 Pin - Pivot 1 Johnston 600/605/625/700/705
1523 60326-1 Pin - Spring Location 1 Johnston 600/605/625/700/705
1524 3637-1 Spring - Tension 3 Johnston 600/605/625/700/705
1525 59-8 Pin - Tension 2 Johnston 600/605/625/700/705
1526 63500-3 Door - Less Non-Lube Bushes 29128-3   Johnston 600/605/625/700/705
1527 60697-1 Tube - Connection 1 Johnston 600/605/625/700/705
1528 60724-1 Link - Tube Suspension 2 Johnston 600/605/625/700/705
1529 123-131 Bolt M10c x 55mm 2 Johnston 600/605/625/700/705
1530 60734-1 Spacer 2 Johnston 600/605/625/700/705
1531 425-15 Nut - Nyloc M10c 2 Johnston 600/605/625/700/705
1532 60718-1 Hook - Hose 2 Johnston 600/605/625/700/705
1533 63349-1 Holster 1 Johnston 600/605/625/700/705
1534 60739-1 Suction Tube - Plastic 1 Johnston 600/605/625/700/705
1535 50236-1 Suction Tube - Steel (Alternative) 1 Johnston 600/605/625/700/705
1536 60744-1 Plastic Duct 0.75m   Johnston 600/605/625/700/705
1537 60744-2 Plastic Duct 6m Johnston 600/605/625/700/705
1538 504-51 Hose Clip 3 Johnston 600/605/625/700/705
1539 60709-1 Trough 2 Johnston 600/605/625/700/705
1540 63350-1 Bracket 4 Johnston 600/605/625/700/705
1541 60716-1 Handle And Clamp 1 Johnston 600/605/625/700/705
1542 6849 Titanfast As Req'd Johnston 600/605/625/700/705
1543 63043-1 Hook - Short 1 Johnston 600/605/625/700/705
1544 60736-1 Handle - Manual Gate 1 Johnston 600/605/625/700/705
1545 60357-1 Bracket 4 Johnston 600/605/625/700/705
1546 455-14 Washer - Spring M16 4 Johnston 600/605/625/700/705
1547 425-18 Nut - Nyloc M16c 4 Johnston 600/605/625/700/705
1548 60725-1 Adaptor 1 Johnston 600/605/625/700/705
1549 39444 Hose - Water 3/8" Bore 1 Johnston 600/605/625/700/705
1550 501-1 Clip - Hose 2 Johnston 600/605/625/700/705
1551 20674-1 Reflective Plate 1 Johnston 600/605/625/700/705
1552 20674-2 Reflective Plate 1 Johnston 600/605/625/700/705
1553 287-20 Grommet 2 Johnston 600/605/625/700/705
1554 24-1 Cable Tie 5 Johnston 600/605/625/700/705
1555 123-131 Bolt M10c x 55mm 2 Johnston 600/605/625/700/705
1556 60734-1 Spacer 2 Johnston 600/605/625/700/705
1557 425-15 Nut - Nyloc M10c 2 Johnston 600/605/625/700/705
1558 124-167 Setscrew M10c x 20mm 6 Johnston 600/605/625/700/705
1559 124-171 Setscrew M10c x 30mm 6 Johnston 600/605/625/700/705
1560 425-2 Nut - Nyloc M10c 6 Johnston 600/605/625/700/705
1561 124-169 Setscrew M10c x 25mm 3 Johnston 600/605/625/700/705
1562 455-11 Washer - Plain M10 15 Johnston 600/605/625/700/705
1563 460-11 Washer - Spring M10 15 Johnston 600/605/625/700/705
1564 420-15 Nut M10c 15 Johnston 600/605/625/700/705
1565 124-135 Setscrew M8c x 20mm 14 Johnston 600/605/625/700/705
1566 455-10 Washer - Plain M8 24 Johnston 600/605/625/700/705
1567 460-10 Washer - Spring M8 32 Johnston 600/605/625/700/705
1568 420-14 Nut M8c 32 Johnston 600/605/625/700/705
1569 124-177 Setscrew M10c x 50mm 2 Johnston 600/605/625/700/705
1570 425-15 Nut - Nyloc M10c 2 Johnston 600/605/625/700/705
1571 123-86 Bolt M6c x 40mm 1 Johnston 600/605/625/700/705
1572 425-13 Nut - Nyloc M6c 1 Johnston 600/605/625/700/705
1573 181-3 Screw - Pozidriv M5c x 16mm 2 Johnston 600/605/625/700/705
1574 455-7 Washer - Plain M5 2 Johnston 600/605/625/700/705
1575 460-7 Washer - Spring M5 2 Johnston 600/605/625/700/705
1576 420-12 Nut - Nyloc M5c 2 Johnston 600/605/625/700/705
1577 194-9 Screw - Pan Hd. No 6 x 16mm 12 Johnston 600/605/625/700/705
1578 60380-1 Hook 1 Johnston 600/605/625/700/705
1579 803151-1 Rear Mesh LH (Current) 1 Johnston 600/605/625/700/705
1580 803152-2 Rear Mesh RH (Current) 1 Johnston 600/605/625/700/705
1581 90329-1 Rear Mesh - One Piece (Superseded) 1 Johnston 600/605/625/700/705
1582 62984-1 Cover 1 Johnston 600/605/625/700/705
1583 460-10 Washer - Spring M8 6 Johnston 600/605/625/700/705
1584 435-12 Retaining Nut M8c 6 Johnston 600/605/625/700/705
1585 124-135 Setscrew M8c x 20mm 24 Johnston 600/605/625/700/705
1586 60717-1 Bracket - Number Plate 1 Johnston 600/605/625/700/705
1587 124-102 Setscrew M6c x 16mm 2 Johnston 600/605/625/700/705
1588 460-8 Washer - Spring M6 2 Johnston 600/605/625/700/705
1589 420-13 Nut M6c 2 Johnston 600/605/625/700/705
1590 63439-1 Face Plate 1 Johnston 600/605/625/700/705
1591 60708-8 Slide Plate - 600/605 Series 1 Johnston 600/605/625/700/705
1592 60708-10 Slide Plate - 625, 700 Series 1 Johnston 600/605/625/700/705
1593 63440-1 Gate 1 Johnston 600/605/625/700/705
1594 123-128 Bolt M10c x 40mm 6 Johnston 600/605/625/700/705
1595 425-2 Nut - Nyloc M10c 6 Johnston 600/605/625/700/705
1596 63436-1 Bracket 1 Johnston 600/605/625/700/705
1597 124-135 Setscrew M8c x 20mm 2 Johnston 600/605/625/700/705
1598 425-1 Nut - Nyloc M8c 2 Johnston 600/605/625/700/705
1599 63449-1 Cylinder - Pneumatic - See next page 1 Johnston 600/605/625/700/705
1600 12869 Tubing Ø6mm Black As Req’d   Johnston 600/605/625/700/705
1601 6746 Rotary Valve 1 Johnston 600/605/625/700/705
1602 63449-1 Cylinder Assembly comprising:   Johnston 600/605/625/700/705
1603 28921-245 Barrel 1 Johnston 600/605/625/700/705
1604 28923-246 Rod 1 Johnston 600/605/625/700/705
1605 28924-1 Head 1 Johnston 600/605/625/700/705
1606 28925-1 Gland 1 Johnston 600/605/625/700/705
1607 28927-1 Bolt - Piston Retaining 1 Johnston 600/605/625/700/705
1608 28929-1 Eye - Fork 1 Johnston 600/605/625/700/705
1609 28926-1 Spacer - Piston 1 Johnston 600/605/625/700/705
1610 29149-1 Clevis Pin 1 Johnston 600/605/625/700/705
1611 39624 Spring Retaining Clip 1 Johnston 600/605/625/700/705
1612 10 * N.S.S. Piston Seal 1 Johnston 600/605/625/700/705
1613 11 * N.S.S. Rod Seal 1 Johnston 600/605/625/700/705
1614 12 * N.S.S. Wiper Seal 1 Johnston 600/605/625/700/705
1615 13 * N.S.S. ‘O’ Ring 2 Johnston 600/605/625/700/705
1616 552-3 Elbow Adaptor 2 Johnston 600/605/625/700/705
1617 801732-1 Clevis Pin 1 Johnston 600/605/625/700/705
1618 283-26 Spring Retaining Clip 1 Johnston 600/605/625/700/705
1619 1 - Rotary Valve - See Fig. 8-4 1 Johnston 600/605/625/700/705
1620 537-3 Male Stud Adaptor 1/8" BSP x Ø6mm 4 Johnston 600/605/625/700/705
1621 541-3 Adaptor 1/8" BSP x Ø6mm 1 Johnston 600/605/625/700/705
1622 72-17 Exhaust Silencer 1 Johnston 600/605/625/700/705
1623 540-3 Swivel Side Tee Adaptor 1/8" BSP x Ø6mm 1 Johnston 600/605/625/700/705
1624 551-1 Stem Elbow Connector x Ø6mm 1 Johnston 600/605/625/700/705
1625 12869 Tubing Ø6mm Black As Req’d   Johnston 600/605/625/700/705
1626 60744-2 Plastic Duct 6m Johnston 600/605/625/700/705
1627 63743-1 Coupling 1 Johnston 600/605/625/700/705
1628 504-51 Hose Clip 2 Johnston 600/605/625/700/705
1629 63500-23 Door (less Bushes 29128-3) 1 Johnston 600/605/625/700/705
1630 63047-1 Rubber Flap 1 Johnston 600/605/625/700/705
1631 60739-1 Suction Tube - Plastic 1 Johnston 600/605/625/700/705
1632 50236-1 Suction Tube - Steel (Alternative) 1 Johnston 600/605/625/700/705
1633 63349-1 Holster 1 Johnston 600/605/625/700/705
1634 60716-1 Handle And Clamp 1 Johnston 600/605/625/700/705
1635 123-86 Bolt M6c x 40mm 1 Johnston 600/605/625/700/705
1636 425-13 Nut M6c Nyloc 1 Johnston 600/605/625/700/705
1637 181-3 Screw - Pozidriv M5c x 16mm 2 Johnston 600/605/625/700/705
1638 455-7 Washer - Plain M5 2 Johnston 600/605/625/700/705
1639 460-7 Washer - Spring M5 2 Johnston 600/605/625/700/705
1640 420-12 Nut M5c 2 Johnston 600/605/625/700/705
1641 60718-1 Hook - Hose 1 Johnston 600/605/625/700/705
1642 63051-1 Double Hook - Hose 1 Johnston 600/605/625/700/705
1643 63350-1 Bracket 4 Johnston 600/605/625/700/705
1644 63045-1 Lug - Hose Stowage Bracket 1 Johnston 600/605/625/700/705
1645 124-102 Setscrew M6c x 16mm 4 Johnston 600/605/625/700/705
1646 455-8 Washer - Plain M6 4 Johnston 600/605/625/700/705
1647 460-8 Washer - Spring M6 4 Johnston 600/605/625/700/705
1648 420-13 Nut M6c 4 Johnston 600/605/625/700/705
1649 60709-1 Trough 2 Johnston 600/605/625/700/705
1650 6849 Titanfast As Req'd Johnston 600/605/625/700/705
1651 20674-1 Reflective Plate 1 Johnston 600/605/625/700/705
1652 20674-2 Reflective Plate 1 Johnston 600/605/625/700/705
1653 194-9 Screw - Pan Hd. No. 6 x 16mm 12 Johnston 600/605/625/700/705
1654 62984-1 Cover 1 Johnston 600/605/625/700/705
1655 124-167 Setscrew M10c x 20mm 6 Johnston 600/605/625/700/705
1656 124-135 Setscrew M8c x 20mm 24 Johnston 600/605/625/700/705
1657 460-10 Washer - Spring M8 32 Johnston 600/605/625/700/705
1658 420-14 Nut M8c 32 Johnston 600/605/625/700/705
1659 124-135 Setscrew M8c x 65mm 14 Johnston 600/605/625/700/705
1660 460-10 Washer - Spring M8 6 Johnston 600/605/625/700/705
1661 435-12 Retaining Nut M8c 6 Johnston 600/605/625/700/705
1662 455-11 Washer - Plain M10 6 Johnston 600/605/625/700/705
1663 460-11 Washer - Spring M10 6 Johnston 600/605/625/700/705
1664 420-15 Nut M10c 6 Johnston 600/605/625/700/705
1665 63043-1 Hook - Short 1 Johnston 600/605/625/700/705
1666 63048-1 Plate - Retainer 1 Johnston 600/605/625/700/705
1667 124-139 Setscrew M8c x 30mm 3 Johnston 600/605/625/700/705
1668 425-14 Nut - Nyloc M8c 3 Johnston 600/605/625/700/705
1669 63740-1 Back Plate 1 Johnston 600/605/625/700/705
1670 63738-1 Shutter 1 Johnston 600/605/625/700/705
1671 41145-1 Handle Cover 1 Johnston 600/605/625/700/705
1672 63737-1 Carrier 1 Johnston 600/605/625/700/705
1673 63739-1 Spacer 3 Johnston 600/605/625/700/705
1674 124-169 Screw 3 Johnston 600/605/625/700/705
1675 455-1 Plain Washer 3 Johnston 600/605/625/700/705
1676 426-5 Nut 3 Johnston 600/605/625/700/705
1677 63741-1 Rubber Flap 1 Johnston 600/605/625/700/705
1678 63742-1 Strip 1 Johnston 600/605/625/700/705
1679 420-14 Nut 2 Johnston 600/605/625/700/705
1680 455-10 Plain Washer 2 Johnston 600/605/625/700/705
1681 1 - Wafer Tray 9 - 2 Johnston 600/605/625/700/705
1682 2 - Sweep Gear Pneumatic Valve Block Assembly 11 - 1 Johnston 600/605/625/700/705
1683 3 - Sweep Gear Hydraulic Valve Bank Assembly 10 - 5 Johnston 600/605/625/700/705
1684 4 - Water Spray Valve Manifold 12 - 4 Johnston 600/605/625/700/705
1685 5 - Wiring Looms 13 - 1 Johnston 600/605/625/700/705
1686 6 - Pneumatic System Vitaliser Unit 11 - 8 Johnston 600/605/625/700/705
1687 7 - Throttle Actuator - 600 Series shown - See Chapter 3 Johnston 600/605/625/700/705
1688 8 - PTO Valve Group - See Chapter 11 Johnston 600/605/625/700/705
1689 9 - Fused Link - See Chapter 13 Johnston 600/605/625/700/705
1690 42702-1 Spacer 4 Johnston 600/605/625/700/705
1691 124-113 Setscrew M6c x 50mm 4 Johnston 600/605/625/700/705
1692 124-143 Setscrew M8c x 40mm 2 Johnston 600/605/625/700/705
1693 420-14 Nut M8c 4 Johnston 600/605/625/700/705
1694 72-2 Air Silencer 1 Johnston 600/605/625/700/705
1695 42407-1 Block - Air Exhaust 1 Johnston 600/605/625/700/705
1696 546-12 Straight Adaptor 1 Johnston 600/605/625/700/705
1697 12870 Tubing Ø8mm x 150mm long 1 Johnston 600/605/625/700/705
1698 288-12 Grommet 2 Johnston 600/605/625/700/705
1699 264-4 Bulkhead Adaptor and Locknut 1/2" BSP 1 Johnston 600/605/625/700/705
1700 555-4 Bulkhead Connector 2 Johnston 600/605/625/700/705
1701 12870 Tubing Ø8mm As Req’d   Johnston 600/605/625/700/705
1702 92502-1 Pipe 1 Johnston 600/605/625/700/705
1703 497/H12 Hose (Water) x 100mm long 2 Johnston 600/605/625/700/705
1704 501-3 Hose Clip 4 Johnston 600/605/625/700/705
1705 42726-1 Water Manifold 1 Johnston 600/605/625/700/705
1706 124-134 Setscrew M8c x 16mm 1 Johnston 600/605/625/700/705
1707 460-10 Washer - Spring M8 1 Johnston 600/605/625/700/705
1708 665-18 Test Point Valve 1 Johnston 600/605/625/700/705
1709 30-50 Terminal Block 1 Johnston 600/605/625/700/705
1710 29668-1 Terminal Number Plate 1 Johnston 600/605/625/700/705
1711 90641-2 Insulation Pad 1 Johnston 600/605/625/700/705
1712 134-14 Screw Pan Hd. M3c x 16mm 2 Johnston 600/605/625/700/705
1713 460-3 Washer - Spring M3 2 Johnston 600/605/625/700/705
1714 420-10 Nut M3c 2 Johnston 600/605/625/700/705
1715 29-1 Conduit x 270mm long 1 Johnston 600/605/625/700/705
1716 42358-1 < Wafer Tray 1 Johnston 600/605/625/700/705
1717 124-135 < Setscrew M8c x 20mm 2 Johnston 600/605/625/700/705
1718 425-14 < Nut - Nyloc M8c 2 Johnston 600/605/625/700/705
1719 42350-1 49088-1 Frame 1 Johnston 600/605/625/700/705
1720 124-141 < Setscrew M8c x 35mm 6 Johnston 600/605/625/700/705
1721 425-14 < Nut - Nyloc M8c 4 Johnston 600/605/625/700/705
1722 6817-1 < Budget Lock 1 Johnston 600/605/625/700/705
1723 124-102 < Setscrew M6c x 16mm 2 Johnston 600/605/625/700/705
1724 460-8 < Washer - Spring M6 2 Johnston 600/605/625/700/705
1725 420-13 < Nut M6c 2 Johnston 600/605/625/700/705
1726 6816 < Key As Req'd Johnston 600/605/625/700/705
1727 42359-1 50125-1 Door 1 Johnston 600/605/625/700/705
1728 42597-1 < Hinge 1 Johnston 600/605/625/700/705
1729 134-41 < Setscrew Poz.Hd. M4c x 10mm 22 Johnston 600/605/625/700/705
1730 425-11 < Nut M4c Nyloc 22 Johnston 600/605/625/700/705
1731 39435 < Gas Spring 2 Johnston 600/605/625/700/705
1732 460-7 < Washer - Spring M5 4 Johnston 600/605/625/700/705
1733 420-12 < Nut M5c 4 Johnston 600/605/625/700/705
1734 42363-1 < Top Panel 1 Johnston 600/605/625/700/705
1735 124-134 < Setscrew M8c x 16mm 4 Johnston 600/605/625/700/705
1736 460-10 < Washer - Spring M8 4 Johnston 600/605/625/700/705
1737 420-14 < Nut M8c 4 Johnston 600/605/625/700/705
1738 217-2 < Rubber Seal x 350mm 2 Johnston 600/605/625/700/705
1739 13 - 217-2 Rubber Seal x 1020mm 1 Johnston 600/605/625/700/705
1740 14 - 217-5 Rubber Lipped Seal x 2800mm 1 Johnston 600/605/625/700/705
1741 67091-1 < Ancillary Valance 1 Johnston 600/605/625/700/705
1742 42615-1 < Seal Plate - Walkway 1 Johnston 600/605/625/700/705
1743 135-57 < Screw-Button Hd. M8c x 20mm long 4 Johnston 600/605/625/700/705
1744 433-2 < Clufix Fitting M6 4 Johnston 600/605/625/700/705
1745 273-15 < Low Pressure Hose 11/4")   Johnston 600/605/625/700/705
1746 273-15 < Low Pressure Hose 1 1/4" ) As Required Johnston 600/605/625/700/705
1747 273-15 < Low Pressure Hose 1 1/4")   Johnston 600/605/625/700/705
1748 04 HC08063-180-90 < 1/2" 90°c x 90°c   Johnston 600/605/625/700/705
1749 05 HC08002-74 < 1/2" Straight x 45°s   Johnston 600/605/625/700/705
1750 06 HC08023-63-350 < 1/2" 45°s x 90°s   Johnston 600/605/625/700/705
1751 07 HC06045-75 < 3/8" 90°s x Straight/B/head   Johnston 600/605/625/700/705
1752 08 HC06044-340 < 3/8" 90°s x 90°c   Johnston 600/605/625/700/705
1753 09 HC04001-114 1/4" Straight x 45°s   Johnston 600/605/625/700/705
1754 10 HC04001-114 1/4" Straight x 45°s   Johnston 600/605/625/700/705
1755 11 HC04003-105 < 1/4" Straight x 90°c   Johnston 600/605/625/700/705
1756 12 HC04003-119 < 1/4" Straight x 90°c   Johnston 600/605/625/700/705
1757 13 HC08001-110 1/2" Straight x 45°s   Johnston 600/605/625/700/705
1758 14 HC08001-110 1/2" Straight x 45°s   Johnston 600/605/625/700/705
1759 03 :- Denotes 3/16" Hose. 12 :- Denotes 3/4" Hose.   Johnston 600/605/625/700/705
1760 04 :- Denotes 1/4" Hose. 16 :- Denotes 1" Hose.   Johnston 600/605/625/700/705
1761 05 :- Denotes 5/16" Hose. 20 :- Denotes 1¼" Hose.   Johnston 600/605/625/700/705
1762 06 :- Denotes 3/8" Hose. 24 :- Denotes 1½" Hose.   Johnston 600/605/625/700/705
1763 08 :- Denotes 1/2" Hose. 32 :- Denotes 2" Hose.   Johnston 600/605/625/700/705
1764 15 HC08001-73 < 1/2" Straight x 45°s   Johnston 600/605/625/700/705
1765 16 HC08001-76 < 1/2" Straight x 45°s   Johnston 600/605/625/700/705
1766 17 HC04023-160-90 < 1/4" 45°s x 90°s   Johnston 600/605/625/700/705
1767 18 HC08003-148 < 1/2" Straight x 90°c   Johnston 600/605/625/700/705
1768 19 HC08001-131 < 1/2" Straight x 45°s   Johnston 600/605/625/700/705
1769 20 HC04022-80-180 1/4" 45°s x 45°s   Johnston 600/605/625/700/705
1770 21 HC04045-65 < 1/4" 90°s x Straight B/Head   Johnston 600/605/625/700/705
1771 22 HC08022-80-180 1/2" 45°s x 45°s   Johnston 600/605/625/700/705
1772 23 HC08004-62 < 1/2" Straight x Straight B/Head   Johnston 600/605/625/700/705
1773 24 HC08022-80-180 1/2" 45°s x 45°s   Johnston 600/605/625/700/705
1774 25 HC08045-181 < 1/2" 90°s x Straight B/Head   Johnston 600/605/625/700/705
1775 26 HC08002-170 < 1/2" Straight x 90°s   Johnston 600/605/625/700/705
1776 27 HC04022-80-180 1/4" 45°s x 45°s   Johnston 600/605/625/700/705
1777 28 HC04045-65 < 1/4" 90°s x Straight B/Head   Johnston 600/605/625/700/705
1778 29 HC08022-80-180 1/2" 45°s x 45°s   Johnston 600/605/625/700/705
1779 30 HC08004-62 < 1/2" Straight x Straight B/Head   Johnston 600/605/625/700/705
1780 31 HC08022-80-180 1/2" 45°s x 45°s   Johnston 600/605/625/700/705
1781 32 HC08045-181 < 1/2" 90°s x Straight B/Head   Johnston 600/605/625/700/705
1782 33 HC08002-170 < 1/2" 90°s x Straight B/Head   Johnston 600/605/625/700/705
1783 34 HC06023-480-180 < Flow Valve 3/8" 45°s x 90°s   Johnston 600/605/625/700/705
1784 35 HC06023-480-180 < Flow Valve 3/8" 45°s x 90°s   Johnston 600/605/625/700/705
1785 36 HC04002-160 Body Tip 1/4" Straight x 90°s   Johnston 600/605/625/700/705
1786 37 HC06002-110 Body Tip 3/8" Straight x 90°s   Johnston 600/605/625/700/705
1787 38 HC04025-265 Rear Door 1/4" 45°s x Straight B/Head   Johnston 600/605/625/700/705
1788 39 HC04002-378 Rear Door 1/4" Straight x 90°s   Johnston 600/605/625/700/705
1789 40 HC04002-265 Rear Door 1/4" Straight x 90°s   Johnston 600/605/625/700/705
1790 41 HC04025-378 Rear Door 1/4" 45°s x Straight B/Head   Johnston 600/605/625/700/705
1791 43 HC08063-44-180 1/2" 90°c x 90°c   Johnston 600/605/625/700/705
1792 44 HC06063-38-180 3/8" 90°c x 90°c   Johnston 600/605/625/700/705
1793 45 HC08024-325 1/2" 45°s x 90°c   Johnston 600/605/625/700/705
1794 46 HC08063-320 1/2" 90°c x 90°c   Johnston 600/605/625/700/705
1795 47 HE12003-36 Return to Tank 3/4" Straight x 90°c   Johnston 600/605/625/700/705
1796 48 HE12063-110-270 Return to Tank 3/4" 90°c x 90°c   Johnston 600/605/625/700/705
1797 49 HE12063-53-40 3/4" 90°c x 90°c   Johnston 600/605/625/700/705
1798 533-51 8mm Braided Hose   Johnston 600/605/625/700/705
1799 12870 8mm Nylon Tube (3000mm long)   Johnston 600/605/625/700/705
1800 39444 10mm Water Hose (800mm long)   Johnston 600/605/625/700/705
1801 39444 10mm Water Hose (800mm long)   Johnston 600/605/625/700/705
1802 497-H12 3/4" Red Water Hose (870mm long)   Johnston 600/605/625/700/705
1803 12870 Ø8 Nylon   Johnston 600/605/625/700/705
1804 56 HC06063-82-315 Hand Pump 3/8" 90°c x 90°c   Johnston 600/605/625/700/705
1805 57 HC04024-90-90 Hand Pump 1/4" 45°s x 90°c   Johnston 600/605/625/700/705
1806 58 HC04003-183 Hand Pump 1/4" Straight x 90°c   Johnston 600/605/625/700/705
1807 59 HC04003-183 Hand Pump 1/4" Straight x 90°c   Johnston 600/605/625/700/705
1808 60 HC04002-31 Variabrush 1/4" Straight x 90°s   Johnston 600/605/625/700/705
1809 61 HC04002-40 Variabrush 1/4" Straight x 90°s   Johnston 600/605/625/700/705
1810 42982-1 Valve 1 Johnston 600/605/625/700/705
1811 40656-1 Elbow 1 Johnston 600/605/625/700/705
1812 260-14 Hose 3/4" Bore 2m Johnston 600/605/625/700/705
1813 501-3 Hose Clip 2 Johnston 600/605/625/700/705
1814 420-9 Nut M24F 1 Johnston 600/605/625/700/705
1815 455-18 Washer - Plain M24 2 Johnston 600/605/625/700/705
1816 62317-1 Bulkhead Adaptor 1 Johnston 600/605/625/700/705
1817 29148-1 Adaptor 4 Johnston 600/605/625/700/705
1818 39444 Hose 3/8" Bore As Req'd Johnston 600/605/625/700/705
1819 501-1 Hose Clip 4 Johnston 600/605/625/700/705
1820 521-8 Elbow 1 Johnston 600/605/625/700/705
1821 511-4 Tubing Sleeve 8mm 2 Johnston 600/605/625/700/705
1822 510-4 Tubing Nut 8mm 2 Johnston 600/605/625/700/705
1823 12870 Tubing Black Ø8mm 4m Johnston 600/605/625/700/705
1824 41038-1 Tubing Support Sleeve 2 Johnston 600/605/625/700/705
1825 515-7 Adaptor 1 Johnston 600/605/625/700/705
1826 7684-1 Collar Plug 1 Johnston 600/605/625/700/705
1827 451-19 Seal - Dowty 1/2" BSP 1 Johnston 600/605/625/700/705
1828 421-9 Locknut M24F 1 Johnston 600/605/625/700/705
1829 5259 Taper Plug 1/8" BSP 1 Johnston 600/605/625/700/705
1830 200102-1 Valve Bank Assembly with 12v Solenoids   Johnston 600/605/625/700/705
1831 200102-2 Valve Bank Assembly with 24v Solenoids   Johnston 600/605/625/700/705
1832 200102-3 Valve Bank Less Solenoids   Johnston 600/605/625/700/705
1833 241-152 Relief Valve (110 Bar) ) Seal Kit 241-164 1 Johnston 600/605/625/700/705
1834 241-152 Relief Valve (180 Bar) ) 1 Johnston 600/605/625/700/705
1835 241-154 Valve - Cartridge (NC - S2A00) Seal Kit 241-164 2 Johnston 600/605/625/700/705
1836 241-01 Coil 12v As Req’d   Johnston 600/605/625/700/705
1837 241-02 Coil 24v As Req’d   Johnston 600/605/625/700/705
1838 241-153 Valve - Cartridge (NO - S2600) Seal Kit 241-164 2 Johnston 600/605/625/700/705
1839 241-161 Coil 12v As Req’d   Johnston 600/605/625/700/705
1840 241-162 Coil 24v As Req’d   Johnston 600/605/625/700/705
1841 241-151 Relief Sequence Valve - Seal Kit 241-163 1 Johnston 600/605/625/700/705
1842 241-155 Valve Cartridge (3/2 Spool - S3A00) Seal Kit 241-163 4 Johnston 600/605/625/700/705
1843 241-01 Coil 12v   Johnston 600/605/625/700/705
1844 241-02 Coil 24v   Johnston 600/605/625/700/705
1845 800587-1 Mounting Plate 1 Johnston 600/605/625/700/705
1846 124-134 Setscrew M8c x 16mm 3 Johnston 600/605/625/700/705
1847 460-10 Washer - Spring M8 3 Johnston 600/605/625/700/705
1848 124-134 Setscrew M8c x 16mm 4 Johnston 600/605/625/700/705
1849 460-10 Washer - Spring M8 4 Johnston 600/605/625/700/705
1850 420-14 Nut M8   Johnston 600/605/625/700/705
1851 241-160 Valve Flow Control 1 Johnston 600/605/625/700/705
1852 A1 15,21 15,21 15 R 16,19,20 16,19,20 16,19,20   Johnston 600/605/625/700/705
1853 15 15 15 T 16,19,20 16,19,19,20 16,19,19,20   Johnston 600/605/625/700/705
1854 B1 15,21 15,21 15 W 16 16 16 Johnston 600/605/625/700/705
1855 B2 15,21 15,21 15 Y 16 16 16 Johnston 600/605/625/700/705
1856 16 16 16 Z 17,22 17,22 17 Johnston 600/605/625/700/705
1857 P2 16,22 16,22 16,22 T7 18 18 18 Johnston 600/605/625/700/705
1858 263-2 Adaptor 1/4" BSP   Johnston 600/605/625/700/705
1859 451-17 Washer - Sealing 1/4" BSP   Johnston 600/605/625/700/705
1860 263-4 Adaptor 1/2" BSP   Johnston 600/605/625/700/705
1861 451-19 Washer - Sealing 1/2" BSP   Johnston 600/605/625/700/705
1862 264-4 Bulkhead Adaptor 1/2" BSP   Johnston 600/605/625/700/705
1863 451-19 Washer - Sealing 1/2" BSP   Johnston 600/605/625/700/705
1864 665-18 Test Point 1/4" BSP (T7)   Johnston 600/605/625/700/705
1865 255-13 Tee 1/2" BSP   Johnston 600/605/625/700/705
1866 252-2 Swivel Nut Adaptor 1/2" x 3/8" BSP   Johnston 600/605/625/700/705
1867 68-19 Blanking Cap 1/4" BSP   Johnston 600/605/625/700/705
1868 68-17 Blanking Cap 1/2" BSP   Johnston 600/605/625/700/705
1869 200103-1 Valve Bank Assembly with 12v Solenoids   Johnston 600/605/625/700/705
1870 200103-2 Valve Bank Assembly with 24v Solenoids   Johnston 600/605/625/700/705
1871 200103-3 Valve Bank Less Coils   Johnston 600/605/625/700/705
1872 241-165 Relief Valve (150 Bar) Seal Kit 241-164 1 Johnston 600/605/625/700/705
1873 241-236 Relief Valve (80 Bar) Seal Kit 241-168 1 Johnston 600/605/625/700/705
1874 241-158 Valve - Cartridge (NC/Lock - S2100) 2 Johnston 600/605/625/700/705
1875 241-01 Coil 12v As Req’d   Johnston 600/605/625/700/705
1876 241-02 Coil 24v As Req’d   Johnston 600/605/625/700/705
1877 241-154 Valve - Cartridge (NC - S4D00) Seal Kit 241-164 1 Johnston 600/605/625/700/705
1878 241-01 Coil 12v As Req’d   Johnston 600/605/625/700/705
1879 241-02 Coil 24v As Req’d   Johnston 600/605/625/700/705
1880 800560-1 Mounting Plate 1 Johnston 600/605/625/700/705
1881 124-132 Setscrew M8c x 12mm 3 Johnston 600/605/625/700/705
1882 460-10 Washer - Spring M8 3 Johnston 600/605/625/700/705
1883 124-134 Setscrew M8c x 16mm 4 Johnston 600/605/625/700/705
1884 460-10 Washer - Spring M8 4 Johnston 600/605/625/700/705
1885 420-14 Nut M8C 4 Johnston 600/605/625/700/705
1886 241-166 Valve Cartridge (4/2 Spool - S4A00) Seal Kit 241-167 3 Johnston 600/605/625/700/705
1887 241-01 Coil 12v As Req’d   Johnston 600/605/625/700/705
1888 241-02 Coil 24v As Req’d   Johnston 600/605/625/700/705
1889 241-153 Valve Cartridge (NO - S2C00) Seal Kit 241-164 1 Johnston 600/605/625/700/705
1890 241-161 Coil 12v As Req’d   Johnston 600/605/625/700/705
1891 241-162 Coil 24v As Req’d   Johnston 600/605/625/700/705
1892 T2 17, 23, 26 Johnston 600/605/625/700/705
1893 T1 18, 27 Johnston 600/605/625/700/705
1894 263-2 Adaptor 1/4" BSP   Johnston 600/605/625/700/705
1895 263-3 Adaptor 3/8" BSP   Johnston 600/605/625/700/705
1896 263-4 Adaptor 1/2" BSP   Johnston 600/605/625/700/705
1897 263-6 Adaptor 3/4" BSP   Johnston 600/605/625/700/705
1898 265-3 Adaptor 1/2" x 1/4" BSP   Johnston 600/605/625/700/705
1899 265-4 Adaptor 3/8" x 1/2" BSP   Johnston 600/605/625/700/705
1900 665-18 Test Point 1/4" BSP (T1)   Johnston 600/605/625/700/705
1901 3162 Blanking Plug   Johnston 600/605/625/700/705
1902 68-17 Cap 1/2" BSP   Johnston 600/605/625/700/705
1903 451-17 Washer - Sealing 1/4" BSP   Johnston 600/605/625/700/705
1904 451-18 Washer - Sealing 3/8" BSP   Johnston 600/605/625/700/705
1905 451-19 Washer - Sealing 1/2" BSP   Johnston 600/605/625/700/705
1906 451-19 Washer - Sealing 3/4" BSP   Johnston 600/605/625/700/705
1907 239-2 Cassapa Pump Assembly comprising items 1 - 9 Johnston 600/605/625/700/705
1908 239-25 Pump 1 Johnston 600/605/625/700/705
1909 53-8 Key 1 Johnston 600/605/625/700/705
1910 3 N.S.S. ‘O’ Ring in Seal Kit 1 Johnston 600/605/625/700/705
1911 239-600 Elbow 1 Johnston 600/605/625/700/705
1912 79-34 ‘O’ Ring 1 Johnston 600/605/625/700/705
1913 129-123 Soc. Hd. Cap Screw M8c x 45mm See Note Below   Johnston 600/605/625/700/705
1914 460-10 Washer - Spring M8 See Note Below   Johnston 600/605/625/700/705
1915 12785-1 Gear 1 Johnston 600/605/625/700/705
1916 239-601 Nut 1 Johnston 600/605/625/700/705
1917 239-602 Tab Washer 1 Johnston 600/605/625/700/705
1918 40764-1 Elbow - Special 1 Johnston 600/605/625/700/705
1919 80-76 ‘O’ Ring 2 Johnston 600/605/625/700/705
1920 265-4 Adaptor 3/8" x 1/2" -   Johnston 600/605/625/700/705
1921 451-18 Washer - Sealing 3/8" BSP 1 Johnston 600/605/625/700/705
1922 123-104 Bolt M8c x 30mm 5 Johnston 600/605/625/700/705
1923 123-114 Bolt M8c x 70mm 1 Johnston 600/605/625/700/705
1924 460-10 Washer - Spring M8 6 Johnston 600/605/625/700/705
1925 239-501 Seal Kit - Comprising Items 3 + Pump Internal Seals)   Johnston 600/605/625/700/705
1926 273-17 Hose 1 1/4" Bore Oil resistant 270mm   Johnston 600/605/625/700/705
1927 501-5 Hose Clip 2 Johnston 600/605/625/700/705
1928 3 Hydraulic Hose (Item 5, Fig. 10 - 1)   Johnston 600/605/625/700/705
1929 264-4 Bulkhead Adaptor and Locknut 1/2" BSP 1 Johnston 600/605/625/700/705
1930 239-1 Cassapa Pump Assembly comprising items 1 - 9 Johnston 600/605/625/700/705
1931 239-1 Pump 1 Johnston 600/605/625/700/705
1932 53-8 Key 1 Johnston 600/605/625/700/705
1933 3 N.S.S. ‘O’ Ring 1 Johnston 600/605/625/700/705
1934 239-600 Elbow 1 Johnston 600/605/625/700/705
1935 129-123 Capscrew M8c x 45mm See Note Below   Johnston 600/605/625/700/705
1936 460-10 Washer - Spring M8 See Note Below   Johnston 600/605/625/700/705
1937 12785-1 Gear 1 Johnston 600/605/625/700/705
1938 239-601 Nut 1 Johnston 600/605/625/700/705
1939 239-602 Tab Washer 1 Johnston 600/605/625/700/705
1940 40764-1 Elbow - Special 1 Johnston 600/605/625/700/705
1941 80-76 ‘O’ Ring 2 Johnston 600/605/625/700/705
1942 265-4 Adaptor 3/8" x 1/2" BSP -   Johnston 600/605/625/700/705
1943 451-19 Washer - Sealing 1/2" BSP 1 Johnston 600/605/625/700/705
1944 123-104 Bolt M8c x 30mm 5 Johnston 600/605/625/700/705
1945 123-111 Bolt M8c x 70mm 1 Johnston 600/605/625/700/705
1946 455-10 Washer - Plain M8 6 Johnston 600/605/625/700/705
1947 239-601 Elbow 1 Johnston 600/605/625/700/705
1948 79-34 ‘O’ Ring 1 Johnston 600/605/625/700/705
1949 129-123 Capscrew M8c x 20mm See Note Below   Johnston 600/605/625/700/705
1950 460-10 Washer - Spring M8 See Note Below   Johnston 600/605/625/700/705
1951 265-4 Adaptor 3/8" x 1/2" BSP 1 Johnston 600/605/625/700/705
1952 451-18 Washer - Sealing 3/8" BSP 1 Johnston 600/605/625/700/705
1953 239-501 Seal Kit - Comprising Items 3 + Pump Internal Seals)   Johnston 600/605/625/700/705
1954 62269-1 Suction Pipe 1 Johnston 600/605/625/700/705
1955 124-132 Setscrew M8c x 12mm 4 Johnston 600/605/625/700/705
1956 460-10 Washer - Spring 4 Johnston 600/605/625/700/705
1957 80-143 'O' Ring 1 Johnston 600/605/625/700/705
1958 15411 Suction Element 1 Johnston 600/605/625/700/705
1959 62836-1 Block - Return Manifold 1 Johnston 600/605/625/700/705
1960 263-4 Adaptor 3/8" x 1/2" BSP 2 Johnston 600/605/625/700/705
1961 451-19 Seal - Dowty 2 Johnston 600/605/625/700/705
1962 124-134 Setscrew M8c x 16mm 2 Johnston 600/605/625/700/705
1963 460-10 Washer - Spring 2 Johnston 600/605/625/700/705
1964 62835-1 Return Pipe 1 Johnston 600/605/625/700/705
1965 H362-53-320S Hose 1 Johnston 600/605/625/700/705
1966 273-17 Hose - 1 1/4" Bore Oil Resistant 0.8m Johnston 600/605/625/700/705
1967 501-5 Hose Clip 4 Johnston 600/605/625/700/705
1968 H678-75 3/8" BSP Hydraulic Hose 1 Johnston 600/605/625/700/705
1969 410-3 Back Nut 1 Johnston 600/605/625/700/705
1970 14 HM354-75S 1/2" BSP Hydraulic Hose 1 Johnston 600/605/625/700/705
1971 7684 Collar Plug 1/2" BSP 1 Johnston 600/605/625/700/705
1972 451-19 Washer - Sealing 1/2" BSP 1 Johnston 600/605/625/700/705
1973 42317-1 Hydraulic Tank - Standard 1 Johnston 600/605/625/700/705
1974 42317-30 Hydraulic Tank - Optional (Accepts level switch item 26)   Johnston 600/605/625/700/705
1975 39398 Multiflow Filter Assembly 1 Johnston 600/605/625/700/705
1976 224-1 Filter Element 1 Johnston 600/605/625/700/705
1977 42206-1 Pipe 1 Johnston 600/605/625/700/705
1978 69-1 Filler/Breather Assembly 1 Johnston 600/605/625/700/705
1979 15411 Suction Element 1 Johnston 600/605/625/700/705
1980 12866 Nipple - Hex. 1 Johnston 600/605/625/700/705
1981 89-15 Valve 1 Johnston 600/605/625/700/705
1982 42982-1 Valve 1 Johnston 600/605/625/700/705
1983 40656-1 Elbow 1 Johnston 600/605/625/700/705
1984 80-143 'O' Ring 1 Johnston 600/605/625/700/705
1985 124-132 Setscrew M8c x 12mm 4 Johnston 600/605/625/700/705
1986 460-10 Washer - Spring M8 4 Johnston 600/605/625/700/705
1987 87-1 Level Gauge 1 Johnston 600/605/625/700/705
1988 266-6 Adaptor 3/4" BSP x 3/4" BSPT 1 Johnston 600/605/625/700/705
1989 124-100 Setscrew M6c x 12mm 4 Johnston 600/605/625/700/705
1990 460-8 Washer - Spring M6 4 Johnston 600/605/625/700/705
1991 124-169 Setscrew M10c x 25mm 4 Johnston 600/605/625/700/705
1992 425-15 Nut - Nyloc M10c 3 Johnston 600/605/625/700/705
1993 277-80 Elbow 90° 1/2" BSP With Tail 1 Johnston 600/605/625/700/705
1994 62273-2 Blanking Plate 1 Johnston 600/605/625/700/705
1995 18736 Taper Plug 1 Johnston 600/605/625/700/705
1996 48-117 Level Switch - used with tank 42317-30.   Johnston 600/605/625/700/705
1997 600/605 625 700/705 Johnston 600/605/625/700/705
1998 28940-1 28940-3 28940-2 Body Tip Cylinder Assembly 1 Johnston 600/605/625/700/705
1999 29100-7 < < Spherical Bearing 1 Johnston 600/605/625/700/705
2000 38-1 < < Grease Nipple 1/8" BSP Straight 1 Johnston 600/605/625/700/705
2001 263-2 < < Adaptor 1/4" BSP 1 Johnston 600/605/625/700/705
2002 263-3 < < Adaptor 3/8" BSP 1 Johnston 600/605/625/700/705
2003 451-17 < < Washer - Sealing 1 Johnston 600/605/625/700/705
2004 451-18 < < Washer - Sealing 1 Johnston 600/605/625/700/705
2005 8 * N/A 263-3 263-3 Adaptor 3/8" BSP 1 Johnston 600/605/625/700/705
2006 9 * N/A 451-18 451-18 Seal - Dowty 1 Johnston 600/605/625/700/705
2007 10 * N/A 29424-1 N/A Washer - Sealing 1 Johnston 600/605/625/700/705
2008 11 Seal - 2nd Stage Rod 1 Johnston 600/605/625/700/705
2009 12 Seal - 1st Stage Rod 1 Johnston 600/605/625/700/705
2010 13 Wiper Seal - 2nd Stage Rod 1 Johnston 600/605/625/700/705
2011 14 Wiper Seal - 1st Stage Rod 1 Johnston 600/605/625/700/705
2012 15 ‘O’ Ring 1 Johnston 600/605/625/700/705
2013 16 ‘O’ Ring 1 Johnston 600/605/625/700/705
2014 17 ‘O’ Ring 1 Johnston 600/605/625/700/705
2015 18 Spirol Back-up Ring 1 Johnston 600/605/625/700/705
2016 19 Spirol Back-up Ring 1 Johnston 600/605/625/700/705
2017 20 Spirol Back-up Ring 2 Johnston 600/605/625/700/705
2018 21 Seal - 2nd Stage Piston 1 Johnston 600/605/625/700/705
2019 22 Grub Screw 1 Johnston 600/605/625/700/705
2020 29463-30 Cylinder Assembly 1 Johnston 600/605/625/700/705
2021 28928-1 Eye 1 Johnston 600/605/625/700/705
2022 29128-1 Bush 1 Johnston 600/605/625/700/705
2023 265-4 Adaptor 3/8" 1 Johnston 600/605/625/700/705
2024 451-18 Washer - Sealing 3/8" BSP 2 Johnston 600/605/625/700/705
2025 263-2 Adaptor - Sealing 1/4" BSP 1 Johnston 600/605/625/700/705
2026 451-17 Washer - Sealing 1/4" BSP 1 Johnston 600/605/625/700/705
2027 8 Ball 8 Johnston 600/605/625/700/705
2028 9 ‘O’ Ring - High Pressure 1 Johnston 600/605/625/700/705
2029 10 ‘O’ Ring 1 Johnston 600/605/625/700/705
2030 11 Circlip 1 Johnston 600/605/625/700/705
2031 12 Spring - Compression 1 Johnston 600/605/625/700/705
2032 13 Rod Seal 1 Johnston 600/605/625/700/705
2033 14 Wiper Seal 1 Johnston 600/605/625/700/705
2034 15 ‘O’ Ring 1 Johnston 600/605/625/700/705
2035 16 Back-up Ring 1 Johnston 600/605/625/700/705
2036 29160-1 Wide Sweep Brush Slew Cylinder   Johnston 600/605/625/700/705
2037 28928-1 Eye 1 Johnston 600/605/625/700/705
2038 29128-1 Bush 1 Johnston 600/605/625/700/705
2039 263-2 Adaptor 1/4" BSP 2 Johnston 600/605/625/700/705
2040 451-17 Washer - Sealing 1/4" BSP 2 Johnston 600/605/625/700/705
2041 6 Wiper Seal - Rod 1 Johnston 600/605/625/700/705
2042 7 Seal - Rod 1 Johnston 600/605/625/700/705
2043 8 Spirol Back-up Ring 1 Johnston 600/605/625/700/705
2044 9 ‘O’ Ring 1 Johnston 600/605/625/700/705
2045 10 Seal - Piston 1 Johnston 600/605/625/700/705
2046 29170-1 Rear Door Cylinder 2 Johnston 600/605/625/700/705
2047 29128-1 Bush 2 Johnston 600/605/625/700/705
2048 135-2 Grubscrew M6c x 6mm 1 Johnston 600/605/625/700/705
2049 265-2 Adaptor 1/4" x 3/8" BSP 2 Johnston 600/605/625/700/705
2050 451-18 Seal - Sealing 3/8" BSP 2 Johnston 600/605/625/700/705
2051 6 Wiper Seal - Rod 1 Johnston 600/605/625/700/705
2052 7 Seal Rod 1 Johnston 600/605/625/700/705
2053 8 ‘O’ Ring 1 Johnston 600/605/625/700/705
2054 9 Spirol Back-up Ring 1 Johnston 600/605/625/700/705
2055 10 Seal Piston 1 Johnston 600/605/625/700/705
2056 42300-2 Pneumatic Valve 12v NC ]   Johnston 600/605/625/700/705
2057 42300-4 Pneumatic Valve 24v NC ]   Johnston 600/605/625/700/705
2058 42300-1 Pneumatic Valve 12v NO ]   Johnston 600/605/625/700/705
2059 42300-3 Pneumatic Valve 24v NO ] See   Johnston 600/605/625/700/705
2060 42412-1 Pneumatic Valve Block ] Valve   Johnston 600/605/625/700/705
2061 42300-5 Blanking Plate Assembly. Comp. ] Table Below   Johnston 600/605/625/700/705
2062 42300-523 Bolt ]   Johnston 600/605/625/700/705
2063 42300-524 Blanking Plate ]   Johnston 600/605/625/700/705
2064 42300-525 Gasket ]   Johnston 600/605/625/700/705
2065 9756 Taper Plug 3 Johnston 600/605/625/700/705
2066 665-18 Test Point Valve 1 Johnston 600/605/625/700/705
2067 537-8 Adaptor 1/4" BSP x Ø6mm 1 Johnston 600/605/625/700/705
2068 562-9 Elbow 1/4" BSP x Ø8mm 1 Johnston 600/605/625/700/705
2069 537-9 Adaptor 1/4" BSP x Ø8mm 1 Johnston 600/605/625/700/705
2070 12869 Tubing Ø6mm Black As Req’d   Johnston 600/605/625/700/705
2071 12870 Tubing Ø8mm Black As Req’d   Johnston 600/605/625/700/705
2072 41038-1 Tubing Support Sleeve 2 Johnston 600/605/625/700/705
2073 540-7 Swivel Side Stem -   Johnston 600/605/625/700/705
2074 551-1 Stem Elbow -   Johnston 600/605/625/700/705
2075 5259 Taper Plug 1/8" BSP -   Johnston 600/605/625/700/705
2076 P1 C C C V1 2 2 2 Johnston 600/605/625/700/705
2077 P2 C C C V2 1 1 1 Johnston 600/605/625/700/705
2078 P3 B B A V3 4 4 2 Johnston 600/605/625/700/705
2079 P4 B B A V4 4 4 1 Johnston 600/605/625/700/705
2080 P5 B B A V5 4 4 4 Johnston 600/605/625/700/705
2081 P6 A A A V6 2 2 2 Johnston 600/605/625/700/705
2082 P7 A A A V7 1 1 1 Johnston 600/605/625/700/705
2083 P8 B B B V8 4 4 4 Johnston 600/605/625/700/705
2084 P9 B B B   Johnston 600/605/625/700/705
2085 P10 B B A   Johnston 600/605/625/700/705
2086 P11 B B A   Johnston 600/605/625/700/705
2087 P12 B B B   Johnston 600/605/625/700/705
2088 P13 A A A   Johnston 600/605/625/700/705
2089 P14 A A A   Johnston 600/605/625/700/705
2090 P15 B B B   Johnston 600/605/625/700/705
2091 42300-2 Pneumatic Valve 12v NC 1 Johnston 600/605/625/700/705
2092 42300-4 Pneumatic Valve 24v NC 1 Johnston 600/605/625/700/705
2093 40602-2 Valve Block 1 Johnston 600/605/625/700/705
2094 537-9 Adaptor 1/4" BSP x Ø8mm 4 Johnston 600/605/625/700/705
2095 40594-1 Adaptor - Bulkhead 2 Johnston 600/605/625/700/705
2096 410-3 Backnut 3/8" BSP 2 Johnston 600/605/625/700/705
2097 451-4 Washer - Sealing 1/8" BSP 2 Johnston 600/605/625/700/705
2098 42300-5 Blanking Plate Assembly comprising:   Johnston 600/605/625/700/705
2099 42300-523 Bolt 2 Johnston 600/605/625/700/705
2100 42300-524 Blanking Plate 1 Johnston 600/605/625/700/705
2101 42300-525 Gasket 1 Johnston 600/605/625/700/705
2102 12869 Tubing Ø6mm Black As Req’d   Johnston 600/605/625/700/705
2103 12870 Tubing Ø8mm Black As Req’d   Johnston 600/605/625/700/705
2104 537-3 Adaptor 1/8" BSP x Ø6mm 1 Johnston 600/605/625/700/705
2105 42300-1 Valve Assembly 12v Normally Open (NO)   Johnston 600/605/625/700/705
2106 42300-2 Valve Assembly 12v Normally Closed (NC)   Johnston 600/605/625/700/705
2107 42300-3 Valve Assembly 24v Normally Open (NO)   Johnston 600/605/625/700/705
2108 42300-4 Valve Assembly 24v Normally Closed (NC)   Johnston 600/605/625/700/705
2109 1 N.S.S. Base 1 Johnston 600/605/625/700/705
2110 42300-112 Solenoid 12v 1 Johnston 600/605/625/700/705
2111 42300-212 Solenoid 24v 1 Johnston 600/605/625/700/705
2112 3 N.S.S. Top Cap 1 Johnston 600/605/625/700/705
2113 135-8 Screw Ch. Hd. M4c x 70mm 2 Johnston 600/605/625/700/705
2114 135-30 Screw Ch. Hd. M3c x 53mm 1 Johnston 600/605/625/700/705
2115 6 N.S.S. Armature 1 Johnston 600/605/625/700/705
2116 79-13 'O' Ring 1 Johnston 600/605/625/700/705
2117 79-58 'O' Ring 3 Johnston 600/605/625/700/705
2118 79-52 'O' Ring 1 Johnston 600/605/625/700/705
2119 79-59 'O' Ring 1 Johnston 600/605/625/700/705
2120 79-53 'O' Ring 1 Johnston 600/605/625/700/705
2121 42300-127 Spare Parts Kit (NO)   Johnston 600/605/625/700/705
2122 42300-227 Spare Parts Kit (NC)   Johnston 600/605/625/700/705
2123 72-24 Vitaliser Unit 1 Johnston 600/605/625/700/705
2124 72-32 Mounting Bracket 2 Johnston 600/605/625/700/705
2125 552-9 Elbow 1/4" BSP x Ø8mm 2 Johnston 600/605/625/700/705
2126 12870 Tubing Ø8mm Black 2 Johnston 600/605/625/700/705
2127 72-27 Gasket Kit ] Lubricator As Req’d   Johnston 600/605/625/700/705
2128 72-33 Replacement Bowl ] Section   Johnston 600/605/625/700/705
2129 72-29 Gasket Kit ] Air Filter As Req’d   Johnston 600/605/625/700/705
2130 72-30 Replacement Bowl ] Section   Johnston 600/605/625/700/705
2131 201029-1 Switch - Pressure 1 Johnston 600/605/625/700/705
2132 41247-1 Boot PVC 1 Johnston 600/605/625/700/705
2133 28906-1 Cylinder Assembly   Johnston 600/605/625/700/705
2134 552-3 Adaptor - Elbow 3 Johnston 600/605/625/700/705
2135 29149-1 Clevis Pin 1 Johnston 600/605/625/700/705
2136 39624 Spring Retaining Clip 1 Johnston 600/605/625/700/705
2137 28906-501 Seal Kit comprising items 4 - 10 Johnston 600/605/625/700/705
2138 4 N.S.S. Seal - Rod 1 Johnston 600/605/625/700/705
2139 5 N.S.S. Seal - Wiper 1 Johnston 600/605/625/700/705
2140 6 N.S.S. Nylon Locking Slug 2 Johnston 600/605/625/700/705
2141 7 N.S.S. Seal - Piston 2 Johnston 600/605/625/700/705
2142 8 N.S.S. Seal - Piston 1 Johnston 600/605/625/700/705
2143 9 N.S.S. ‘O’ Ring 1 Johnston 600/605/625/700/705
2144 10 N.S.S. ‘O’ Ring 2 Johnston 600/605/625/700/705
2145 28901-1 Intake Flap *   Johnston 600/605/625/700/705
2146 28902-1 Wide Sweep Brush Lift, pre ‘Lo Pro’ *   Johnston 600/605/625/700/705
2147 28903-1 Nozzle Lift *   Johnston 600/605/625/700/705
2148 28904-1 Nozzle Maxigap *   Johnston 600/605/625/700/705
2149 28905-1 Channel Brush Powathrust/Powasave *   Johnston 600/605/625/700/705
2150 29284-1 ‘Lo Pro’ Wide Sweep Brush Lift *   Johnston 600/605/625/700/705
2151 29362-1 Combivac Nozzle *   Johnston 600/605/625/700/705
2152 29283-1 Combivac Nozzle Lift *   Johnston 600/605/625/700/705
2153 29128-1 Bush 1 ---1 -1 -   Johnston 600/605/625/700/705
2154 29145-1 Clevis Pin - 1 1 -----   Johnston 600/605/625/700/705
2155 39624 Spring Retaining Clip 1 - - 1 1 - 1 -   Johnston 600/605/625/700/705
2156 29113-1 Bolt - Special -----1 --   Johnston 600/605/625/700/705
2157 421-16 Locknut -----1 --   Johnston 600/605/625/700/705
2158 552-3 Adaptor - Elbow 21222122 Johnston 600/605/625/700/705
2159 29148-1 Adaptor - 1 ---1 --   Johnston 600/605/625/700/705
2160 29149-1 Clevis Pin 11111- - -   Johnston 600/605/625/700/705
2161 29149-2 Clevis Pin ------1 -   Johnston 600/605/625/700/705
2162 28901-501 Seal Kit comprising items 10 - 14 Johnston 600/605/625/700/705
2163 10 N.S.S. Seal - Piston 11111111 Johnston 600/605/625/700/705
2164 11 N.S.S. Seal - Rod 11111111 Johnston 600/605/625/700/705
2165 12 N.S.S. Seal - Wiper 11111111 Johnston 600/605/625/700/705
2166 13 N.S.S. ‘O’ Ring 22222222 Johnston 600/605/625/700/705
2167 14 N.S.S. Nylon Locking Slug 22222222 Johnston 600/605/625/700/705
2168 22599-1 Water Pump 1 Johnston 600/605/625/700/705
2169 42227-1 Pulley 1 Johnston 600/605/625/700/705
2170 22651-1 Key 1 Johnston 600/605/625/700/705
2171 135-52 Grub Screw M8c x 10mm 2 Johnston 600/605/625/700/705
2172 40656-1 Elbow 1 Johnston 600/605/625/700/705
2173 13164 Bush 1 Johnston 600/605/625/700/705
2174 40600 Elbow 1 Johnston 600/605/625/700/705
2175 42527-1 Plate 1 Johnston 600/605/625/700/705
2176 42525-1 Spacer 2 Johnston 600/605/625/700/705
2177 42526-1 Plate 1 Johnston 600/605/625/700/705
2178 110-52 Setscrew 3/8" BSW x 1" 4 Johnston 600/605/625/700/705
2179 450-29 Spring Washer 3/8" 4 Johnston 600/605/625/700/705
2180 124-171 Setscrew M10c x 30mm 3 Johnston 600/605/625/700/705
2181 457-5 Washer - Large M10 3 Johnston 600/605/625/700/705
2182 425-15 Nut - Nyloc M10c 3 Johnston 600/605/625/700/705
2183 497-H12 Hose 3/4" Bore x 750mm Long 1 Johnston 600/605/625/700/705
2184 501-3 Clip 2 Johnston 600/605/625/700/705
2185 6117 Hose 1" Bore x 750mm Long 1 Johnston 600/605/625/700/705
2186 501-4 Clip 2 Johnston 600/605/625/700/705
2187 280-3 Belt 1 >   Johnston 600/605/625/700/705
2188 22599-1 Water Pump Assembly.Comp:- 1 Johnston 600/605/625/700/705
2189 15824-2 Bolt 4 Johnston 600/605/625/700/705
2190 15824-3 Valve Assembly. 4 Johnston 600/605/625/700/705
2191 15824-4 'O' Ring 4 Johnston 600/605/625/700/705
2192 15824-5 Diaphragm 2 Johnston 600/605/625/700/705
2193 15824-7 Cylinder Head 2 Johnston 600/605/625/700/705
2194 15824-8 Crankcase 1 Pair   Johnston 600/605/625/700/705
2195 15824-9 Connecting Rod 2 Johnston 600/605/625/700/705
2196 15824-10 Tension Pad 2 Johnston 600/605/625/700/705
2197 22599-2 Crankshaft 1 Johnston 600/605/625/700/705
2198 15824-12 Felt Ring 2 Johnston 600/605/625/700/705
2199 15824-13 Manifold 1 Johnston 600/605/625/700/705
2200 14-18 Bearing - Connecting Rod 2 Johnston 600/605/625/700/705
2201 14-32 Bearing - Crankshaft 2 Johnston 600/605/625/700/705
2202 15824-16 Dust Cover 2 Johnston 600/605/625/700/705
2203 15824-17 Bolt - Tension Pad 2 Johnston 600/605/625/700/705
2204 15824-18 Washer 2 Johnston 600/605/625/700/705
2205 15824-19 'O' Ring 2 Johnston 600/605/625/700/705
2206 15824-20 Bolt 8 Johnston 600/605/625/700/705
2207 21 N/R Adaptor 1 Johnston 600/605/625/700/705
2208 38-9 Grease Nipple 1/4” BSP x 90° 1 Johnston 600/605/625/700/705
2209 15824-6 Repair Kit Comprising Items:- 3, 4, & 5 Johnston 600/605/625/700/705
2210 42400-1 Manifold - Water 1 Johnston 600/605/625/700/705
2211 2 - Water Valve See Fig. 12 - 5 ]   Johnston 600/605/625/700/705
2212 40256-2 Banjo Bolt ] See   Johnston 600/605/625/700/705
2213 4 453-1Fibre Washer ] Above   Johnston 600/605/625/700/705
2214 135-11 Screw M12c x 35mm ]   Johnston 600/605/625/700/705
2215 410-32 Domed Nut M12 ]   Johnston 600/605/625/700/705
2216 124-134 Screw M8c x 16mm 2 Johnston 600/605/625/700/705
2217 460-10 Spring - Washer M8 2 Johnston 600/605/625/700/705
2218 420-14 Nut M8c 2 Johnston 600/605/625/700/705
2219 281372-1 42429-1 Water Valve Assembly 12v   Johnston 600/605/625/700/705
2220 281372-2 42429-2 Water Valve Assembly 24v   Johnston 600/605/625/700/705
2221 13170 < Filter 1 Johnston 600/605/625/700/705
2222 2 N.S.S. < Base 1 Johnston 600/605/625/700/705
2223 281372-5 - Lock Nut 1 Johnston 600/605/625/700/705
2224 40664-13 < Lever Kit comprising:   Johnston 600/605/625/700/705
2225 281372-12 12910 Coil 12v 1 Johnston 600/605/625/700/705
2226 281372-24 42429-217 Coil 24v 1 Johnston 600/605/625/700/705
2227 6 N.S.S. < Armature 1 Johnston 600/605/625/700/705
2228 7 N.S.S. < ‘O’ Ring 1 Johnston 600/605/625/700/705
2229 8 N.S.S. - Armature Housing   Johnston 600/605/625/700/705
2230 9 N.S.S. - Setscrews   Johnston 600/605/625/700/705
2231 46382-3 < Adaptor 1 Johnston 600/605/625/700/705
2232 281372-3 - Type ‘A’ Overhaul Kit comprising:   Johnston 600/605/625/700/705
2233 281372-4 42429-125 Seal Kit comprising:   Johnston 600/605/625/700/705
2234 42584-1 Manifold - Relief Valve 1 Johnston 600/605/625/700/705
2235 6127 Nipple 1 Johnston 600/605/625/700/705
2236 89-1 Ball Valve 1 Johnston 600/605/625/700/705
2237 3698-11 Valve - Relief 1 Johnston 600/605/625/700/705
2238 231-19 Adaptor As Req'd Johnston 600/605/625/700/705
2239 39444 Hose - 3/8" Bore As Req'd Johnston 600/605/625/700/705
2240 501-2 Clip 1 Johnston 600/605/625/700/705
2241 497-H12 Hose - 3/4" Bore As Req'd Johnston 600/605/625/700/705
2242 501-3 Clip 2 Johnston 600/605/625/700/705
2243 41006-3 Adaptor 1 Johnston 600/605/625/700/705
2244 3698-11 Relief Valve Assembly. Comp:- 1 Johnston 600/605/625/700/705
2245 3698-2 Body 1 Johnston 600/605/625/700/705
2246 3698-12 Seat 1 Johnston 600/605/625/700/705
2247 3698-4 Valve 1 Johnston 600/605/625/700/705
2248 3698-5 Spindle 1 Johnston 600/605/625/700/705
2249 3698-6 Spring 1 Johnston 600/605/625/700/705
2250 3698-7 Spring End Plate 2 Johnston 600/605/625/700/705
2251 3698-8 Adjusting Screw 1 Johnston 600/605/625/700/705
2252 3698-9 Locknut 1 Johnston 600/605/625/700/705
2253 3698-10 Dome 1 Johnston 600/605/625/700/705
2254 22-1 Ball 1 Johnston 600/605/625/700/705
2255 501-6 Clip 4 Johnston 600/605/625/700/705
2256 42213-1 Hose - Flushing Valve 1 Johnston 600/605/625/700/705
2257 42088-1 Tube - Flushing Valve 1 Johnston 600/605/625/700/705
2258 22773-1 Spacer ] 600/605 3 Johnston 600/605/625/700/705
2259 124-139 Setscrew M8c x 30mm ] Series 3 Johnston 600/605/625/700/705
2260 22773-1 Spacer ] 625/700/705 6 Johnston 600/605/625/700/705
2261 124-141 Setscrew M8c x 35mm ] Series 3 Johnston 600/605/625/700/705
2262 420-14 Nut M8c 3 Johnston 600/605/625/700/705
2263 460-10 Washer - Spring M8 3 Johnston 600/605/625/700/705
2264 15656-1 Sight Glass Tube 1 Johnston 600/605/625/700/705
2265 18684-1 Adaptor 1 Johnston 600/605/625/700/705
2266 42119-1 Body - Hydrant Filler 1 Johnston 600/605/625/700/705
2267 39402 Filter Element 1 Johnston 600/605/625/700/705
2268 39253 Valve - Ball   Johnston 600/605/625/700/705
2269 40242-1 Adaptor 1 Johnston 600/605/625/700/705
2270 501-2 Hose Clip 2 Johnston 600/605/625/700/705
2271 22-7 Ball 1 Johnston 600/605/625/700/705
2272 18459-1 Hydrant Hose Assembly 1 Johnston 600/605/625/700/705
2273 6975 Plug 1¼" BSPT 4 Johnston 600/605/625/700/705
2274 3836 Plug 3/8" BSPT 1 Johnston 600/605/625/700/705
2275 6974-1 Filter Element 1 Johnston 600/605/625/700/705
2276 80-143 ‘O’ Ring 1 Johnston 600/605/625/700/705
2277 40098-1 Flange - Suction Filter 1 Johnston 600/605/625/700/705
2278 40600-1 Elbow 1 Johnston 600/605/625/700/705
2279 124-135 Setscrew M8c x 20mm 4 Johnston 600/605/625/700/705
2280 460-10 Washer - Spring M8 4 Johnston 600/605/625/700/705
2281 40656-1 Elbow 1 Johnston 600/605/625/700/705
2282 41776-2 Cap - ‘Johnston’ 4 Johnston 600/605/625/700/705
2283 40650-1 Cap - ‘Jobro’   Johnston 600/605/625/700/705
2284 40643-1 Washer - Seal 4 Johnston 600/605/625/700/705
2285 280874-1 Water Level Switch with Deutsch Connector - Current 1 Johnston 600/605/625/700/705
2286 48-120 Water Level Switch with no Plug - Superseded 1 Johnston 600/605/625/700/705
2287 49946-1 Adaptor 1 Johnston 600/605/625/700/705
2288 802255-1 Drain Nozzle 1 Johnston 600/605/625/700/705
2289 13432 Ball Valve 2" BSP 1 Johnston 600/605/625/700/705
2290 18650 Elbow 2" BSP 1 Johnston 600/605/625/700/705
2291 61008-1 Mount - Filter, 625/700/705 Series 1 Johnston 600/605/625/700/705
2292 42368-1 Mount - Filter, 600/605 Series 1 Johnston 600/605/625/700/705
2293 41017-1 Nipple 1 Johnston 600/605/625/700/705
2294 6117 1" Bore Hose 1m Johnston 600/605/625/700/705
2295 41261-1 'U' Bend 1 Johnston 600/605/625/700/705
2296 13095-1 Valve - Ball 3/4" 1 Johnston 600/605/625/700/705
2297 15960-1 Filter Unit Comprising Items 7 - 16 1 Johnston 600/605/625/700/705
2298 15960-2 Filter Element 1 Johnston 600/605/625/700/705
2299 15960-3 Seal - Nut To Bowl 1 Johnston 600/605/625/700/705
2300 15960-4 Seal - Element To Spring 1 Johnston 600/605/625/700/705
2301 15960-5 Seal - Element To Head 1 Johnston 600/605/625/700/705
2302 15960-6 Gasket - Bowl To Head 1 Johnston 600/605/625/700/705
2303 15960-7 Spring 1 Johnston 600/605/625/700/705
2304 408-19 Nut - Domed 1 Johnston 600/605/625/700/705
2305 15960-9 Stem 1 Johnston 600/605/625/700/705
2306 15 N.S.S. Head N.S.S.   Johnston 600/605/625/700/705
2307 15960-12 Bowl 1 Johnston 600/605/625/700/705
2308 88-11 Ball Valve 1/4" BSP 1 Johnston 600/605/625/700/705
2309 40629-7 Spraybar 1 Johnston 600/605/625/700/705
2310 60688-1 Spraybar Nozzle No.3 4 Johnston 600/605/625/700/705
2311 60689-1 Union Nut 4 Johnston 600/605/625/700/705
2312 45573-1 Hanger 2 Johnston 600/605/625/700/705
2313 124-135 Setscrew M8c x 20mm 2 Johnston 600/605/625/700/705
2314 460-10 Washer - Spring 2 Johnston 600/605/625/700/705
2315 420-14 Nut M8c 2 Johnston 600/605/625/700/705
2316 26728-14 Assembly (Items 2 - 6)   Johnston 600/605/625/700/705
2317 26728-15 Assembly (With 146mm Deep Support Bracket)   Johnston 600/605/625/700/705
2318 60689-1 Union Nut 1/4" BSP 2 Johnston 600/605/625/700/705
2319 60688-1 Spray Nozzle No.3 1 Johnston 600/605/625/700/705
2320 60690-1 Spray Nozzle No.10 1 Johnston 600/605/625/700/705
2321 41011-1 Bend 2 Johnston 600/605/625/700/705
2322 410-11 Locknut 1/4" BSP 2 Johnston 600/605/625/700/705
2323 41010-7 Tee Connector 1 Johnston 600/605/625/700/705
2324 124-103 Setscrew M6c x 20mm 1 Johnston 600/605/625/700/705
2325 455-8 Washer - Plain M6 1 Johnston 600/605/625/700/705
2326 460-8 Washer - Spring M6 1 Johnston 600/605/625/700/705
2327 420-13 Nut M6c 1 Johnston 600/605/625/700/705
2328 50710-1 Support Bracket - Iveco Eurocargo 1 Johnston 600/605/625/700/705
2329 15614-1 Support Bracket 70mm Deep 1 Johnston 600/605/625/700/705
2330 15614-2 Support Bracket 146mm Deep 1 Johnston 600/605/625/700/705
2331 124-103 Setscrew M6c x 20mm 2 Johnston 600/605/625/700/705
2332 460-8 Washer - Spring M6 2 Johnston 600/605/625/700/705
2333 420-13 Nut M6c 2 Johnston 600/605/625/700/705
2334 6148-1 Pricker For Spray Jet   Johnston 600/605/625/700/705
2335 6137 Spray Nozzle 1 Johnston 600/605/625/700/705
2336 6111 Hose 1/2" Bore 6m Johnston 600/605/625/700/705
2337 501-2 Hose Clip - Worm Drive 2 Johnston 600/605/625/700/705
2338 3786 Strap And Buckle 1 Johnston 600/605/625/700/705
2339 41006-1 Hose Adaptor 2 Johnston 600/605/625/700/705
2340 89-1 Valve 3/8" BSP 1 Johnston 600/605/625/700/705
2341 6105-1 'U' Bolt 2 Johnston 600/605/625/700/705
2342 460-8 Washer - Spring M6 4 Johnston 600/605/625/700/705
2343 420-13 Nut M6c 4 Johnston 600/605/625/700/705
2344 6104-1 Support Plate 1 Johnston 600/605/625/700/705
2345 6111 Hose 1/2" Bore As Req’d   Johnston 600/605/625/700/705
2346 501-2 Hose Clip - Worm Drive 2 Johnston 600/605/625/700/705
2347 223-7 Water Pump 1 Johnston 600/605/625/700/705
2348 2 - Hydraulic Motor and Drive - See Fig. 12 - 15 Current,   Johnston 600/605/625/700/705
2349 49884-2 Mounting Cradle - 600/605 1 Johnston 600/605/625/700/705
2350 95406-1 Mounting Cradle - 625/700/705 1 Johnston 600/605/625/700/705
2351 137-37 Screw Button Hd. M8c x 20mm 4 Johnston 600/605/625/700/705
2352 425-14 Nut - Nyloc M8c 4 Johnston 600/605/625/700/705
2353 49874-1 Elbow 1 Johnston 600/605/625/700/705
2354 89-1 Ball Valve 1 Johnston 600/605/625/700/705
2355 263-3 Adaptor 3/8” BSP 1 Johnston 600/605/625/700/705
2356 264-3 Adaptor - Bulkhead 3/8” BSP 1 Johnston 600/605/625/700/705
2357 451-18 Washer - Sealing 3/8” BSP 1 Johnston 600/605/625/700/705
2358 410-3 Locknut 1 Johnston 600/605/625/700/705
2359 3701 Elbow 3/4" BSP 1 Johnston 600/605/625/700/705
2360 231-19 Adaptor 3/4" Hose x 3/4" BSPT 1 Johnston 600/605/625/700/705
2361 50516-1 Regulator (including test point) 1 Johnston 600/605/625/700/705
2362 252-2 Adaptor - Swivel 1/2" x 3/8" BSP 1 Johnston 600/605/625/700/705
2363 255-12 Tee ] Quantities Vary   Johnston 600/605/625/700/705
2364 263-3 Adaptor ] with   Johnston 600/605/625/700/705
2365 451-18 Washer - Sealing 3/8" BSP ] Spray Bar Options   Johnston 600/605/625/700/705
2366 6756-1 Ball Valve 1 Johnston 600/605/625/700/705
2367 49933-1 Bulkhead Adaptor 3/8" x 1/2" BSP 1 Johnston 600/605/625/700/705
2368 451-19 Washer - Sealing 1/2" BSP 1 Johnston 600/605/625/700/705
2369 410-3 Locknut 3/8" BSP 1 Johnston 600/605/625/700/705
2370 265-4 Adaptor 3/8" x 1/2" BSP 1 Johnston 600/605/625/700/705
2371 451-19 Washer - Sealing 1/2" BSP 1 Johnston 600/605/625/700/705
2372 93220-1 Valve Plate 1 Johnston 600/605/625/700/705
2373 252-2 Adaptor 3/8" BSP 1 Johnston 600/605/625/700/705
2374 451-18 Washer - Sealing 3/8" BSP 1 Johnston 600/605/625/700/705
2375 667-49 Hose Reel Assembly 1 Johnston 600/605/625/700/705
2376 21-306 Hand Lance Assembly comprising:   Johnston 600/605/625/700/705
2377 21-304 Spray Gun (with swivel) 1 Johnston 600/605/625/700/705
2378 21-305 Lance 1 Johnston 600/605/625/700/705
2379 71362-2 Holder - Twin Nozzle 1 Johnston 600/605/625/700/705
2380 21-26 Jet - Round 1 Johnston 600/605/625/700/705
2381 21-27 Jet - Fan 1 Johnston 600/605/625/700/705
2382 262-3 Elbow - Swivel 3/8" BSP 1 Johnston 600/605/625/700/705
2383 451-18 Washer - Sealing 3/8" BSP 1 Johnston 600/605/625/700/705
2384 486-8 Probe 1 Johnston 600/605/625/700/705
2385 486-18 Carrier 1 Johnston 600/605/625/700/705
2386 49942-1 Tee 1 Johnston 600/605/625/700/705
2387 501--3 Clip 2 Johnston 600/605/625/700/705
2388 501-4 Clip 2 Johnston 600/605/625/700/705
2389 49871-1 Filter Mount - 600 Series 1 Johnston 600/605/625/700/705
2390 67158-1 Filter Mount - 625/700 Series 1 Johnston 600/605/625/700/705
2391 48399-1 Spraybar 1 Johnston 600/605/625/700/705
2392 21-31 Water Jets 6 Johnston 600/605/625/700/705
2393 6756-1 Ball Valve 1 Johnston 600/605/625/700/705
2394 49998-1 ‘U’ Clamp 2 Johnston 600/605/625/700/705
2395 48362-1 Clamp 2 Johnston 600/605/625/700/705
2396 425-14 Nut - M8c Nyloc 4 Johnston 600/605/625/700/705
2397 263-4 Adaptor 1/2" BSP 1 Johnston 600/605/625/700/705
2398 451-19 Washer - Sealing 1/2" BSP 1 Johnston 600/605/625/700/705
2399 265-4 Adaptor 3/8"x 1/2" BSP 1 Johnston 600/605/625/700/705
2400 48362-1 Clamp 2 Johnston 600/605/625/700/705
2401 124-143 Setscrew M8c x 40mm 4 Johnston 600/605/625/700/705
2402 460-10 Washer - Spring M8 4 Johnston 600/605/625/700/705
2403 497-H12 Hose 3/4" Bore x 240cm 1 Johnston 600/605/625/700/705
2404 6117 Hose 1" Bore x 245cm 1 Johnston 600/605/625/700/705
2405 501-4 Hose Clip 2 Johnston 600/605/625/700/705
2406 38 HC06000-38 3/8" BSP Hydraulic Hose 1 Johnston 600/605/625/700/705
2407 39 - 3/8" BSP Hydraulic Hose - Varies with chassis 1 Johnston 600/605/625/700/705
2408 40 HC06063-340-180 3/8" BSP Hydraulic Hose 1 Johnston 600/605/625/700/705
2409 41 HC06063-560 3/8" BSP Hydraulic Hose 1 Johnston 600/605/625/700/705
2410 42 HC08003-45 1/2" BSP Hydraulic Hose 1 Johnston 600/605/625/700/705
2411 1 - Hydraulic Tank - See Chapter 10 Johnston 600/605/625/700/705
2412 2 - Tandem PTO Pump - See Chapter 10 Johnston 600/605/625/700/705
2413 3 - See Tandem Pump Installation See Chapter 10 Johnston 600/605/625/700/705
2414 4 - Return Adaptor - See Chapter 10 Johnston 600/605/625/700/705
2415 239-6 Hydraulic Motor - Cassapa 1 Johnston 600/605/625/700/705
2416 239-506 Motor Seal Kit - Cassapa   Johnston 600/605/625/700/705
2417 124-173 Setscrew M10c x 35mm 2 Johnston 600/605/625/700/705
2418 425-15 Nut - Nyloc M10c 2 Johnston 600/605/625/700/705
2419 265-2 Adaptor 1/4" x 3/8" BSP 1 Johnston 600/605/625/700/705
2420 451-17 Washer - Sealing 1/4" BSP 1 Johnston 600/605/625/700/705
2421 265-4 Adaptor 1/2" BSP x 3/8" BSP ) Motor 1 Johnston 600/605/625/700/705
2422 451-19 Seal 1/2" BSP ) Feed 1 Johnston 600/605/625/700/705
2423 50256-1 Plate - Motor Mounting 1 Johnston 600/605/625/700/705
2424 62847-1 Drive Coupling Assembly 1 Johnston 600/605/625/700/705
2425 41910-1 Tab Washer ) Used with 1 Johnston 600/605/625/700/705
2426 42816-1 Nut - Special ) Coupling 1 Johnston 600/605/625/700/705
2427 90749-1 Spacer 4 Johnston 600/605/625/700/705
2428 124-167 Setscrew M10c x 20mm 12 Johnston 600/605/625/700/705
2429 460-11 Washer - Spring M10 12 Johnston 600/605/625/700/705
2430 50257-1 Guard 1 Johnston 600/605/625/700/705
2431 134-54 Screw Round Hd. M5c x 6mm 4 Johnston 600/605/625/700/705
2432 460-7 Washer - Spring M5 4 Johnston 600/605/625/700/705
2433 90748-1 Plate - Pump Mounting 1 Johnston 600/605/625/700/705
2434 16 - Valve Block Assembly - See next page   Johnston 600/605/625/700/705
2435 521-8 Elbow 1 Johnston 600/605/625/700/705
2436 12870 Tubing 1 Johnston 600/605/625/700/705
2437 510-4 Tubing Nut 1 Johnston 600/605/625/700/705
2438 511-4 Olive 1 Johnston 600/605/625/700/705
2439 265-7 Adaptor 3/4" BSP x 1/2" BSP ) Motor 1 Johnston 600/605/625/700/705
2440 451-21 Washer - Sealing 13/4" BSP ) Return 1 Johnston 600/605/625/700/705
2441 90874-1 Valve Block Assembly 24v comprising 1 to 3 Johnston 600/605/625/700/705
2442 90874-2 Valve Block Assembly 12v comprising 1 to 3 Johnston 600/605/625/700/705
2443 66099-1 Block N.S.S. 1 Johnston 600/605/625/700/705
2444 241-153 Valve - Cartridge (NO-S2600) (Seal Kit 241-164) 1 Johnston 600/605/625/700/705
2445 241-01 Coil 12v As Req’d   Johnston 600/605/625/700/705
2446 241-02 Coil 24v As Req’d   Johnston 600/605/625/700/705
2447 241-152 Relief Valve Cartridge (Seal Kit 241-164) 1 Johnston 600/605/625/700/705
2448 263-4 Adaptor 1/2" x 1/2" BSP 3 Johnston 600/605/625/700/705
2449 451-17 Washer - Sealing 1/2" BSP 3 Johnston 600/605/625/700/705
2450 265-4 Adaptor 1/2" x 3/8" BSP 2 Johnston 600/605/625/700/705
2451 451-19 Washer - Sealing 1/2" BSP 2 Johnston 600/605/625/700/705
2452 665-18 Test Point Valve 1/4" BSP (T9) 1 Johnston 600/605/625/700/705
2453 451-17 Washer - Sealing 1/4" 1 Johnston 600/605/625/700/705
2454 124-132 Setscrew M8c x 16mm 2 Johnston 600/605/625/700/705
2455 460-10 Washer - Spring M8 2 Johnston 600/605/625/700/705
2456 90262-1 Solenoid Valve NO - 24v 1 Johnston 600/605/625/700/705
2457 254-3 Coil - 24v   Johnston 600/605/625/700/705
2458 90262-2 Solenoid Valve NO - 12v 1 Johnston 600/605/625/700/705
2459 254-4 Coil - 12v   Johnston 600/605/625/700/705
2460 90264-1 Relief Valve Cartridge   Johnston 600/605/625/700/705
2461 63584-1 Spraybar 1 2 Johnston 600/605/625/700/705
2462 68-18 Blanking Cap 1 2 Johnston 600/605/625/700/705
2463 21-29 Water Jets 3 6 Johnston 600/605/625/700/705
2464 124-167 Bolt M10c x 20mm 2 4 Johnston 600/605/625/700/705
2465 460-11 Washer - Spring M10 2 4 Johnston 600/605/625/700/705
2466 63585-1 Plate - Outer ) L.H. 1 Johnston 600/605/625/700/705
2467 63586-1 Plate - Inner ) Nozzle 1 Johnston 600/605/625/700/705
2468 63585-2 Plate - Outer ) R.H. 1 Johnston 600/605/625/700/705
2469 63586-2 Plate - Inner ) Nozzle 1 Johnston 600/605/625/700/705
2470 50044-1 Mount 1 2 Johnston 600/605/625/700/705
2471 124-103 Setscrew M6c x 20mm 2 4 Johnston 600/605/625/700/705
2472 425-13 Nut - Nyloc M6c 2 4 Johnston 600/605/625/700/705
2473 6756-1 Ball Valve 1 2 Johnston 600/605/625/700/705
2474 49933-1 Adaptor 1/2" x 3/8" BSP 1 2 Johnston 600/605/625/700/705
2475 410-3 Locknut 1 2 Johnston 600/605/625/700/705
2476 265-4 Adaptor 1/2" x 3/8" BSP 1 2 Johnston 600/605/625/700/705
2477 451-19 Washer - Sealing 1/2" BSP 2 2 Johnston 600/605/625/700/705
2478 255-12 Tee As Req’d   Johnston 600/605/625/700/705
2479 17 HC06063-55-270 Hydraulic Hose 3/8" BSP - L.H. Nozzle 1 2 Johnston 600/605/625/700/705
2480 18 HC06044-195-180 Hydraulic Hose 3/8" BSP - L.H. Nozzle 1 1 Johnston 600/605/625/700/705
2481 19 HC06044-240-270 Hydraulic Hose 3/8" BSP - R.H. Nozzle 1 1 Johnston 600/605/625/700/705
2482 20 HC06063-55-90 Hydraulic Hose 3/8" BSP - R.H. Nozzle   Johnston 600/605/625/700/705
2483 21 HC06044-34-30 Hydraulic Hose 3/8" BSP 1 Johnston 600/605/625/700/705
2484 22 - Hydraulic Hose - See Fig. 12 - 14 Johnston 600/605/625/700/705
2485 223-402 Valve Kit   Johnston 600/605/625/700/705
2486 1 NSS ‘O’ Ring 6 6 Johnston 600/605/625/700/705
2487 2 NSS Valve Guide 6 6 Johnston 600/605/625/700/705
2488 3 NSS Spring 6 6 Johnston 600/605/625/700/705
2489 4 NSS Seal 6 6 Johnston 600/605/625/700/705
2490 5 NSS Valve Seal 6 6 Johnston 600/605/625/700/705
2491 6 NSS ‘O’ Ring 6 6 Johnston 600/605/625/700/705
2492 223-411 Water Seal Kit   Johnston 600/605/625/700/705
2493 7 NSS Head Ring 3 3 Johnston 600/605/625/700/705
2494 8 NSS Packing Seal 3 3 Johnston 600/605/625/700/705
2495 9 NSS Restop 3 3 Johnston 600/605/625/700/705
2496 10 NSS Intermediate Ring 3 3 Johnston 600/605/625/700/705
2497 11 NSS Packing Retainer 3 3 Johnston 600/605/625/700/705
2498 223-410 Piston Repair Kit   Johnston 600/605/625/700/705
2499 12 NSS Piston Bolt 3 3 Johnston 600/605/625/700/705
2500 13 NSS Seal 3 3 Johnston 600/605/625/700/705
2501 14 NSS Anti Extrusion Ring 3 3 Johnston 600/605/625/700/705
2502 15 NSS Washer 3 3 Johnston 600/605/625/700/705
2503 16 NSS Washer 3 3 Johnston 600/605/625/700/705
2504 223-406 Piston 1 3 Johnston 600/605/625/700/705
2505 223-409 Crankshaft Oil Seal Kit 1 1 Johnston 600/605/625/700/705
2506 223-408 Sump Gasket 1 1 Johnston 600/605/625/700/705
2507 223-407 Oil Seal 3 3 Johnston 600/605/625/700/705
2508 223-412 Crankshaft 1 1 Johnston 600/605/625/700/705
2509 223-415 Crankshaft Key 1 1 Johnston 600/605/625/700/705
2510 223-417 Crankshaft Circlip 1 1 Johnston 600/605/625/700/705
2511 223-413 Piston Guide 1 3 Johnston 600/605/625/700/705
2512 223-414 Connecting Rod 1 3 Johnston 600/605/625/700/705
2513 223-416 Piston Pin 1 3 Johnston 600/605/625/700/705
2514 223-418 Dip Stick 1 1 Johnston 600/605/625/700/705
2515 800909-1 Main Loom 1 Johnston 600/605/625/700/705
2516 42708-1 Auxiliary Loom - Dual Sweep [ Connects 1 Johnston 600/605/625/700/705
2517 42708-2 Auxiliary Loom - Single Sweep [ to 1 Johnston 600/605/625/700/705
2518 200840-1 Engine Loom 12v Perkins 1004.40 and 40T As Fitted   Johnston 600/605/625/700/705
2519 800580-1 Engine Loom 24v Perkins 1004.40 and 40T As Fitted   Johnston 600/605/625/700/705
2520 280663-1 Systems Locker Loom 1 Johnston 600/605/625/700/705
2521 280664-1 Subframe Loom 1 Johnston 600/605/625/700/705
2522 280665-1 Intake Duct Flap Control Loom - Dual Sweep 1 Johnston 600/605/625/700/705
2523 280665-2 Intake Duct Flap Control Loom - LH Single 1 Johnston 600/605/625/700/705
2524 280665-3 Intake Duct Flap Control Loom - RH Single 1 Johnston 600/605/625/700/705
2525 48-34 Starter Relay 12v (Green) 1 Johnston 600/605/625/700/705
2526 48-36 Starter Relay 24v (Blue) 1 Johnston 600/605/625/700/705
2527 181-3 Screw - Pan Hd M5c x 16mm 2 Johnston 600/605/625/700/705
2528 455-7 Washer - Plain M5 2 Johnston 600/605/625/700/705
2529 425-12 Nut - Nyloc M5c 2 Johnston 600/605/625/700/705
2530 800908-2 Discharge Valve Loom 1 Johnston 600/605/625/700/705
2531 801012-1 Discharge Loom 1 Johnston 600/605/625/700/705
2532 200830-1 Body Discharge (In Cab Option)   Johnston 600/605/625/700/705
2533 201362-1 Supawash Option   Johnston 600/605/625/700/705
2534 12 Rear Subframe Loom - Single 1 Johnston 600/605/625/700/705
2535 13 - Fuseable Link - See over page   Johnston 600/605/625/700/705
2536 30-184 Reverse Alarm 1 Johnston 600/605/625/700/705
2537 281096-1 Spacer 1 Johnston 600/605/625/700/705
2538 425-14 Nut - Nyloc M8c 1 Johnston 600/605/625/700/705
2539 94149-1 Fusible Link Assembly 12v   Johnston 600/605/625/700/705
2540 94149-2 Fusible Link Assembly 24v   Johnston 600/605/625/700/705
2541 651-12 Fuse - 32 Amp for 24v Systems 1 Johnston 600/605/625/700/705
2542 651-13 Fuse - 50 Amp for 12v Systems 1 <   Johnston 600/605/625/700/705
2543 135-89 Setscrew - Brass M5c x 10mm 2 <   Johnston 600/605/625/700/705
2544 93529-2 Adaptor 1 <   Johnston 600/605/625/700/705
2545 93529-1 Adaptor 1 <   Johnston 600/605/625/700/705
2546 457-5 Washer - Large 3 <   Johnston 600/605/625/700/705
2547 42661-1 Washer - Special 3 <   Johnston 600/605/625/700/705
2548 94150-1 Spacer 2 <   Johnston 600/605/625/700/705
2549 135-88 Locknut M10c 3 <   Johnston 600/605/625/700/705
2550 222-43 Cap 1 <   Johnston 600/605/625/700/705
2551 92105-40 Cable - Link 1 <   Johnston 600/605/625/700/705
2552 92105-60 Cable - Starter 1 <   Johnston 600/605/625/700/705
2553 12 - Live Terminal - Part of Item 10 Johnston 600/605/625/700/705
2554 13 - Earth Terminal   Johnston 600/605/625/700/705
2555 42660-1 Spacer 1 <   Johnston 600/605/625/700/705
2556 16569 < Heat Start Switch 1 1 Johnston 600/605/625/700/705
2557 17047 < Index Plate 1 1 Johnston 600/605/625/700/705
2558 453-3 N/A Washer - Red 1 1 Johnston 600/605/625/700/705
2559 16569-2 < Key 1 1 Johnston 600/605/625/700/705
2560 48-22 < Insert - Incr. Speed 1 1 Johnston 600/605/625/700/705
2561 48-23 < (i) Insert - Lub. Oil 1 1 Johnston 600/605/625/700/705
2562 48-26 < (i) Insert - W.L.I. 1 1 Johnston 600/605/625/700/705
2563 48-27 < Insert - Water Temp. 1 1 Johnston 600/605/625/700/705
2564 48-20 < Insert - Battery 1 1 Johnston 600/605/625/700/705
2565 48-21 < Insert - Beacon 1 1 Johnston 600/605/625/700/705
2566 48-1 < Switch - Inlet Flap 1 2 Johnston 600/605/625/700/705
2567 48-1 < Switch - Powathrust 1 2 Johnston 600/605/625/700/705
2568 48-1 < Switch - Gutter Spray 1 2 Johnston 600/605/625/700/705
2569 48-1 < Switch - Worklight 1 2 Johnston 600/605/625/700/705
2570 48-25 < Insert - Nozzle 1 1 Johnston 600/605/625/700/705
2571 48-24 < Insert - Channel Brush 1 2 Johnston 600/605/625/700/705
2572 48-214 < Insert - W.S.B. 1 2 Johnston 600/605/625/700/705
2573 13 - - Cover See Fig. 14 - 2 - -   Johnston 600/605/625/700/705
2574 42435-2 Cover Panel - Single 1 -   Johnston 600/605/625/700/705
2575 2435-1 Cover Panel - Dual - 1 Johnston 600/605/625/700/705
2576 42434-1 Box 1 1 Johnston 600/605/625/700/705
2577 13981 Timer Relay 12V 2 2 Johnston 600/605/625/700/705
2578 13982 Timer Relay 24V 2 2 Johnston 600/605/625/700/705
2579 13983 Relay Base 2 2 Johnston 600/605/625/700/705
2580 12904 Relay 11 Pin 12V 1 1 Johnston 600/605/625/700/705
2581 13867 Relay 11 Pin 24V 1 1 Johnston 600/605/625/700/705
2582 39353 Relay Base 1 1 Johnston 600/605/625/700/705
2583 13984 Diode 10 16 Johnston 600/605/625/700/705
2584 13193 Relay 12V 1 4 Johnston 600/605/625/700/705
2585 13194 Relay 24V 1 4 Johnston 600/605/625/700/705
2586 39353 Relay Base 4 4 Johnston 600/605/625/700/705
2587 40669-6 Terminal Block 2 1 Johnston 600/605/625/700/705
2588 40669-11 Terminal Block - 1 Johnston 600/605/625/700/705
2589 48726-1 Insulation Sheet 2 2 Johnston 600/605/625/700/705
2590 30-94 In Line Fuse 7.5 amp 1 1 Johnston 600/605/625/700/705
2591 30-72 Holder 1 1 Johnston 600/605/625/700/705
2592 13545 Fuse Box 1 Johnston 600/605/625/700/705
2593 181-3 Screw - Pan Hd M5c x 16mm 2 Johnston 600/605/625/700/705
2594 460-7 Washer - Spring M5 2 Johnston 600/605/625/700/705
2595 420-12 Nut M5c 2 Johnston 600/605/625/700/705
2596 30-23 Fuse 1 - 16 Amp 1 Johnston 600/605/625/700/705
2597 30-11 Fuses 2 to 6 - 8 Amp 5 Johnston 600/605/625/700/705
2598 42450 Hinge 1 Johnston 600/605/625/700/705
2599 134-41 Screw - Pan Hd M4c x 10mm 8 Johnston 600/605/625/700/705
2600 460-5 Washer - Spring M4 8 Johnston 600/605/625/700/705
2601 420-11 Nut M4c 8 Johnston 600/605/625/700/705
2602 181-4 Screw - Pan Hd M5c x 12mm 8 Johnston 600/605/625/700/705
2603 460-7 Washer - Spring 8 Johnston 600/605/625/700/705
2604 420-12 Nut M5c 8 Johnston 600/605/625/700/705
2605 13557 Terminal 3 Johnston 600/605/625/700/705
2606 42774-1 Spacer 6 Johnston 600/605/625/700/705
2607 124-100 Setscrew M6c x 12mm 12 Johnston 600/605/625/700/705
2608 460-8 Washer - Spacer M6 12 Johnston 600/605/625/700/705
2609 41647-1 Relay Bracket 1 Johnston 600/605/625/700/705
2610 181-1 Screw - Pan Hd M5c x 10mm 2 Johnston 600/605/625/700/705
2611 460-7 Washer - Spring M5 2 Johnston 600/605/625/700/705
2612 420-12 Nut M5c 2 Johnston 600/605/625/700/705
2613 134-13 Screw - Pan Hd M3c x 12mm 4 Johnston 600/605/625/700/705
2614 460-3 Washer - Spring M3 4 Johnston 600/605/625/700/705
2615 420-10 Nut M3c 4 Johnston 600/605/625/700/705
2616 42795-1 Angle Fastener 1 Johnston 600/605/625/700/705
2617 181-1 Screw - Pan Hd M5c x 10mm 2 Johnston 600/605/625/700/705
2618 460-7 Washer - Spring M5 2 Johnston 600/605/625/700/705
2619 420-12 Nut - M5c 2 Johnston 600/605/625/700/705
2620 42389-1 Fastener Screw 1 Johnston 600/605/625/700/705
2621 42942-1 Plug Mounting Bracket 1 Johnston 600/605/625/700/705
2622 42775-1 L.H. Mounting Plate 1 Johnston 600/605/625/700/705
2623 42776-1 R.H. Mounting Plate 1 Johnston 600/605/625/700/705
2624 56-31 ‘Ergo’ Control 1 2 Johnston 600/605/625/700/705
2625 3730-1 Flow Control Valve Comprising:- 1 Johnston 600/605/625/700/705
2626 26106-1 Body 1 Johnston 600/605/625/700/705
2627 26107-1 Spindle 1 Johnston 600/605/625/700/705
2628 26108-1 Gland 1 Johnston 600/605/625/700/705
2629 79-52 ‘O’ Ring 2 Johnston 600/605/625/700/705
2630 41045-2 Handwheel 1 Johnston 600/605/625/700/705
2631 135-9 Grub Screw M6c x 8mm 1 Johnston 600/605/625/700/705
2632 410-18 Nut - Mounting 3/4" BSP 1 Johnston 600/605/625/700/705
2633 265-2 Adaptor - Reducing 3/8" x 1/4" BSP 1 Johnston 600/605/625/700/705
2634 451-17 Washer - Sealing 1/4" BSP 1 Johnston 600/605/625/700/705
2635 40685-1 Label 1 Johnston 600/605/625/700/705
2636 450-16 Washer - Plain, for Mounting Valve 2 Johnston 600/605/625/700/705
2637 56739-1 Extension Spindle ] Eurocargo 1 Johnston 600/605/625/700/705
2638 135-9 Grubscrew M6c x 8mm ] Only 1 Johnston 600/605/625/700/705
2639 200314-1 Control Box Assembly 1 Johnston 600/605/625/700/705
2640 134-44 Setscrew Pan Head M4c x 20mm 2 Johnston 600/605/625/700/705
2641 425-11 Nut - Nyloc M4c 2 Johnston 600/605/625/700/705
2642 801245-1 Bracket 1 Johnston 600/605/625/700/705
2643 124-135 Setscrew M8c x 20mm 2 Johnston 600/605/625/700/705
2644 460-10 Washer - Spring M8c 2 Johnston 600/605/625/700/705
2645 420-14 Nut M8c 2 Johnston 600/605/625/700/705
2646 5 - Plate - See Chapter 10 Johnston 600/605/625/700/705
2647 48-293 Switch - Push Button   Johnston 600/605/625/700/705
2648 48-338 Switch - Contact   Johnston 600/605/625/700/705
2649 91028-1 Pod - Body Discharge without Autoprop -   Johnston 600/605/625/700/705
2650 91258-1 Pod - Body Discharge with Autoprop 1 Johnston 600/605/625/700/705
2651 48-88 Switch - Self Centring 3 Johnston 600/605/625/700/705
2652 47-13 Bulb 24v As Req’d   Johnston 600/605/625/700/705
2653 47-14 Bulb 12v As Req’d   Johnston 600/605/625/700/705
2654 48-81 Insert - Body Discharge 1 Johnston 600/605/625/700/705
2655 48-49 Insert - Rear Door 1 Johnston 600/605/625/700/705
2656 48-154 Insert - Body Prop 1 Johnston 600/605/625/700/705
2657 29609-1 Labels 1 Johnston 600/605/625/700/705
2658 134-44 Setscrew M4c x 20mm 4 Johnston 600/605/625/700/705
2659 91031-1 Mount 2 Johnston 600/605/625/700/705
2660 201202-1 External Control Box and Loom - Rear Door Close 1 Johnston 600/605/625/700/705
2661 13528 Cable - 3 Core As Req’d   Johnston 600/605/625/700/705
2662 50977-1 Mounting Strip 1 Johnston 600/605/625/700/705
2663 95228-1 Bracket 1 Johnston 600/605/625/700/705
2664 127-38 Setscrew Csk M4c x 16mm 2 Johnston 600/605/625/700/705
2665 425-11 Nut M4c 2 Johnston 600/605/625/700/705
2666 124-102 Setscrew M6c x 16mm 2 Johnston 600/605/625/700/705
2667 425-13 Nut M6c 2 Johnston 600/605/625/700/705
2668 20724 Weight Load Indicator Assembly   Johnston 600/605/625/700/705
2669 281745-1 Arm 1 Johnston 600/605/625/700/705
2670 281731-1 Contact Bracket 1 Johnston 600/605/625/700/705
2671 281739-1 Stop Plate 1 Johnston 600/605/625/700/705
2672 281738-1 Support Bracket 1 Johnston 600/605/625/700/705
2673 124-103 Setscrew M6c x 20mm 5 Johnston 600/605/625/700/705
2674 460-8 Washer - Spring M6 5 Johnston 600/605/625/700/705
2675 420-13 Nut M6c 5 Johnston 600/605/625/700/705
2676 281742-1 Pin 1 Johnston 600/605/625/700/705
2677 455-10 Washer - Plain M8 4 Johnston 600/605/625/700/705
2678 500-70 Split Pin 2 Johnston 600/605/625/700/705
2679 6275-1 Spring 1 Johnston 600/605/625/700/705
2680 20723-1 Support Link 1 Johnston 600/605/625/700/705
2681 20722-1 Support Bracket 1 Johnston 600/605/625/700/705
2682 124-105 Setscrew M6c x 25mm 2 Johnston 600/605/625/700/705
2683 460-8 Washer - Spring M6 2 Johnston 600/605/625/700/705
2684 420-13 Nut M6c 2 Johnston 600/605/625/700/705
2685 455-8 Washer - Plain M6 2 Johnston 600/605/625/700/705
2686 124-113 Setscrew M6c x 50mm 1 Johnston 600/605/625/700/705
2687 420-13 Nut M6c 2 Johnston 600/605/625/700/705
2688 124-113 Setscrew - M6c x 50mm 1 Johnston 600/605/625/700/705
2689 410-27 Nut - Brass M6c 3 Johnston 600/605/625/700/705
2690 6272-10 Washer - Fibre 2 Johnston 600/605/625/700/705
2691 425-13 Nut - Nyloc M6c 1 Johnston 600/605/625/700/705
2692 17369 Insulator - Nylon Tube x 10mm 1 Johnston 600/605/625/700/705
2693 50-43 Ring Terminal 1 Johnston 600/605/625/700/705
2694 457-2 Washer - Large M6 2 Johnston 600/605/625/700/705
Bu Ürün Sizden Önce 0 Kişi Tarafından İncelenmiştir.
